– 19 –
• Circuit Boards Location
POWER SWITCH
board
PRIMARY board
SECONDARY board
VOL SEL board
(DE335:E)
STANDBY board
REAR AMP board
DISPLAY board
VIDEO board
PHONO board
(SE391)
VOLUME board
TONE board
KEY board
SP SW
board
MAIN board
