– 50 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
DISPLAY
A-4419-129-A DISPLAY BOARD, COMPLETE (DE335: AUS)
A-4419-135-A DISPLAY BOARD, COMPLETE (DE335: E)
A-4419-182-A DISPLAY BOARD, COMPLETE (SE391)
A-4419-472-A DISPLAY BOARD, COMPLETE
(DE335: US, CND)
A-4419-744-A DISPLAY BOARD, COMPLETE (DE335: AEP)
A-4419-752-A DISPLAY BOARD, COMPLETE
(DE335: MY, SP/V323)
************************
* 4-921-941-01 CUSHION (FL)
* 4-943-107-11 HOLDER (FL TUBE)
< CAPACITOR >
C201 1-125-486-11 DOUBLE LAYERS 0.22F 5.5V
C202 1-164-159-11 CERAMIC 0.1uF 50V
C203 1-124-465-00 ELECT 0.47uF 20% 50V
C204 1-164-159-11 CERAMIC 0.1uF 50V
C205 1-162-294-31 CERAMIC 0.001uF 10% 50V
C206 1-164-159-11 CERAMIC 0.1uF 50V
C207 1-126-096-11 ELECT 10uF 20% 35V
C208 1-126-096-11 ELECT 10uF 20% 35V
< CONNECTOR >
* CNP203 1-573-107-11 CONNECTOR, PC BOARD (PLUG) 4P
CNP205 1-785-821-11 CONNECTOR, BOARD TO BOARD 6P
CNP206 1-779-366-11 CONNECTOR, BOARD TO BOARD 4P
CNP207 1-779-366-11 CONNECTOR, BOARD TO BOARD 4P
CNS201 1-568-844-11 CONNECTOR, FFC 29P
CNS202 1-770-397-11 HOUSING, CONNECTOR (PC BOARD) 4P
< DIODE >
D201 8-719-991-33 DIODE 1SS133T-77
D202 8-719-991-33 DIODE 1SS133T-77
D203 8-719-991-33 DIODE 1SS133T-77
D204 8-719-991-33 DIODE 1SS133T-77
D221 8-719-991-33 DIODE 1SS133T-77 (DE335: MY, SP/V323)
D222 8-719-991-33 DIODE 1SS133T-77
(DE335: E, MY, SP, AUS/V323)
D223 8-719-991-33 DIODE 1SS133T-77 (DE335: AEP, AUS)
D224 8-719-991-33 DIODE 1SS133T-77 (SE391)
D225 8-719-991-33 DIODE 1SS133T-77 (SE391)
D230 8-719-046-39 LED SEL5821A-TH15 (CINEMA)
D231 8-719-046-39 LED SEL5821A-TH15 (VIRTUAL)
D232 8-719-046-39 LED SEL5821A-TH15 (MUSIC)
< FLUORESCENT INDICATOR TUBE >
FL201 1-517-662-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC201 8-759-577-78 IC uPD78045FGF-082-3B9
IC202 8-759-962-08 IC BA6208
IC203 8-759-332-18 IC GP1U27XB (REMOTE CONTROL
RECEIVER)
< COIL >
L401 1-410-509-11 INDUCTOR 10uH
< TRANSISTOR >
Q201 8-729-900-63 TRANSISTOR DTA124ES
Q202 8-729-900-36 TRANSISTOR DTC124ES
Q230 8-729-900-36 TRANSISTOR DTC124ES
Q231 8-729-900-36 TRANSISTOR DTC124ES
Q232 8-729-900-36 TRANSISTOR DTC124ES
< RESISTOR >
R200 1-249-433-11 CARBON 22K 5% 1/4W
R201 1-247-903-00 CARBON 1M 5% 1/4W
R202 1-249-429-11 CARBON 10K 5% 1/4W
R203 1-249-429-11 CARBON 10K 5% 1/4W
R204 1-249-425-11 CARBON 4.7K 5% 1/4W
R205 1-249-441-11 CARBON 100K 5% 1/4W
R206 1-249-433-11 CARBON 22K 5% 1/4W
R207 1-249-433-11 CARBON 22K 5% 1/4W
R209 1-249-429-11 CARBON 10K 5% 1/4W
(EXCEPT DE335: AEP)
R216 1-249-433-11 CARBON 22K 5% 1/4W
R221 1-247-807-31 CARBON 100 5% 1/4W
R222 1-247-807-31 CARBON 100 5% 1/4W
R223 1-247-807-31 CARBON 100 5% 1/4W
R224 1-247-807-31 CARBON 100 5% 1/4W
R225 1-247-807-31 CARBON 100 5% 1/4W
R226 1-249-421-11 CARBON 2.2K 5% 1/4W
SECTION 7
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
Les composants identifiés par une
marque ! sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
• Abbreviation
CND : Canadian model
MY : Malaysia model
SP : Singapore model
AUS : Australian model
