Sony STR-DE400 - Headphone Board Components

46
STR-DE400
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HEADPHONE BOARD
*****************
< CONNECTOR >
CNP701 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
< JACK >
J700 1-815-314-21 JACK (PHONES)
*************************************************************
A-1179-811-A MAIN BOARD, COMPLETE (EXCEPT TW)
A-1187-012-A MAIN BOARD, COMPLETE (TW)
*********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C400 1-127-888-11 CERAMIC 0.1uF 10% 50V
C402 1-126-964-11 ELECT 10uF 20% 50V
C403 1-162-294-31 CERAMIC 0.001uF 10% 50V
C404 1-162-294-31 CERAMIC 0.001uF 10% 50V
C405 1-126-963-11 ELECT 4.7uF 20% 50V
C421 1-126-963-11 ELECT 4.7uF 20% 50V
C422 1-126-963-11 ELECT 4.7uF 20% 50V
C423 1-126-963-11 ELECT 4.7uF 20% 50V
C424 1-126-963-11 ELECT 4.7uF 20% 50V
C425 1-126-963-11 ELECT 4.7uF 20% 50V
C426 1-126-963-11 ELECT 4.7uF 20% 50V
C431 1-126-961-11 ELECT 2.2uF 20% 50V
C432 1-126-961-11 ELECT 2.2uF 20% 50V
C433 1-126-961-11 ELECT 2.2uF 20% 50V
C434 1-126-961-11 ELECT 2.2uF 20% 50V
C435 1-126-961-11 ELECT 2.2uF 20% 50V
C436 1-126-961-11 ELECT 2.2uF 20% 50V
C446 1-126-963-11 ELECT 4.7uF 20% 50V
C452 1-126-964-11 ELECT 10uF 20% 50V
C455 1-126-963-11 ELECT 4.7uF 20% 50V
C471 1-104-658-91 ELECT 100uF 20% 10V
C472 1-127-888-11 CERAMIC 0.1uF 10% 50V
C482 1-127-888-11 CERAMIC 0.1uF 10% 50V
C484 1-127-888-11 CERAMIC 0.1uF 10% 50V
C500 1-128-579-11 ELECT 2.2uF 20% 100V
(TW)
C501 1-126-963-11 ELECT 4.7uF 20% 50V
C502 1-128-809-11 CERAMIC 100PF 5% 50V
C503 1-128-809-11 CERAMIC 100PF 5% 50V
C504 1-101-810-00 CERAMIC 100PF 5% 500V
(TYPE2)
C504 1-102-233-00 CERAMIC 33PF 10% 500V
(TYPE1)
C506 1-107-583-11 CERAMIC 3PF 0.25PF 500V
C507 1-104-658-91 ELECT 100uF 20% 10V
C508 1-126-947-11 ELECT 47uF 20% 35V
C511 1-162-815-11 CERAMIC 47PF 5% 500V
C512 1-162-815-11 CERAMIC 47PF 5% 500V
C513 1-128-813-11 CERAMIC 220PF 5% 50V
C514 1-127-876-11 CERAMIC 0.01uF 10% 50V
C515 1-126-964-11 ELECT 10uF 20% 50V
C516 1-136-157-00 FILM 0.022uF 5% 50V
C551 1-126-963-11 ELECT 4.7uF 20% 50V
C552 1-128-809-11 CERAMIC 100PF 5% 50V
C553 1-128-809-11 CERAMIC 100PF 5% 50V
C554 1-101-810-00 CERAMIC 100PF 5% 500V
(TYPE2)
C554 1-102-233-00 CERAMIC 33PF 10% 500V
(TYPE1)
C556 1-107-583-11 CERAMIC 3PF 0.25PF 500V
C557 1-104-658-91 ELECT 100uF 20% 10V
C558 1-126-947-11 ELECT 47uF 20% 35V
C561 1-162-815-11 CERAMIC 47PF 5% 500V
C562 1-162-815-11 CERAMIC 47PF 5% 500V
C563 1-128-813-11 CERAMIC 220PF 5% 50V
C564 1-127-876-11 CERAMIC 0.01uF 10% 50V
C565 1-126-964-11 ELECT 10uF 20% 50V
C566 1-136-157-00 FILM 0.022uF 5% 50V
C600 1-128-579-11 ELECT 2.2uF 20% 100V
(TW)
C601 1-126-963-11 ELECT 4.7uF 20% 50V
C602 1-128-809-11 CERAMIC 100PF 5% 50V
C603 1-128-809-11 CERAMIC 100PF 5% 50V
C604 1-101-810-00 CERAMIC 100PF 5% 500V
(TYPE2)
C604 1-102-233-00 CERAMIC 33PF 10% 500V
(TYPE1)
C606 1-107-583-11 CERAMIC 3PF 0.25PF 500V
C607 1-104-658-91 ELECT 100uF 20% 10V
C608 1-126-947-11 ELECT 47uF 20% 35V
C611 1-162-815-11 CERAMIC 47PF 5% 500V
C612 1-162-815-11 CERAMIC 47PF 5% 500V
C613 1-128-813-11 CERAMIC 220PF 5% 50V
C614 1-127-876-11 CERAMIC 0.01uF 10% 50V
C615 1-126-964-11 ELECT 10uF 20% 50V
C616 1-136-157-00 FILM 0.022uF 5% 50V
C651 1-126-963-11 ELECT 4.7uF 20% 50V
C652 1-128-809-11 CERAMIC 100PF 5% 50V
C653 1-128-809-11 CERAMIC 100PF 5% 50V
C654 1-101-810-00 CERAMIC 100PF 5% 500V
(TYPE2)
C654 1-102-233-00 CERAMIC 33PF 10% 500V
(TYPE1)
C656 1-107-583-11 CERAMIC 3PF 0.25PF 500V
C657 1-104-658-91 ELECT 100uF 20% 10V
C658 1-126-947-11 ELECT 47uF 20% 35V
C661 1-162-815-11 CERAMIC 47PF 5% 500V
C662 1-162-815-11 CERAMIC 47PF 5% 500V
C663 1-128-813-11 CERAMIC 220PF 5% 50V
C664 1-127-876-11 CERAMIC 0.01uF 10% 50V
C665 1-126-964-11 ELECT 10uF 20% 50V
C666 1-136-157-00 FILM 0.022uF 5% 50V
C700 1-128-579-11 ELECT 2.2uF 20% 100V
(TW)
C701 1-126-963-11 ELECT 4.7uF 20% 50V
C702 1-128-809-11 CERAMIC 100PF 5% 50V
C703 1-128-809-11 CERAMIC 100PF 5% 50V
C704 1-101-810-00 CERAMIC 100PF 5% 500V
(TYPE2)
C704 1-102-233-00 CERAMIC 33PF 10% 500V
(TYPE1)
C706 1-107-583-11 CERAMIC 3PF 0.25PF 500V
C707 1-104-658-91 ELECT 100uF 20% 10V
C708 1-126-947-11 ELECT 47uF 20% 35V
C711 1-162-815-11 CERAMIC 47PF 5% 500V
HEADPHONE MAIN
Ver. 1.2
As for the display of type1 and type2, refer to the SERVICE NOTE
“Note on replacement POWER AMPLIFIER IC (page3)”.
