STR-DE400
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C712 1-162-815-11 CERAMIC 47PF 5% 500V
C713 1-128-813-11 CERAMIC 220PF 5% 50V
C714 1-127-876-11 CERAMIC 0.01uF 10% 50V
C715 1-126-964-11 ELECT 10uF 20% 50V
C716 1-136-157-00 FILM 0.022uF 5% 50V
C801 1-135-798-11 CERAMIC 0.22uF 50V
C802 1-135-798-11 CERAMIC 0.22uF 50V
C803 1-126-936-11 ELECT 3300uF 20% 16V
C806 1-126-947-11 ELECT 47uF 20% 35V
C807 1-126-947-11 ELECT 47uF 20% 35V
C808 1-126-947-11 ELECT 47uF 20% 35V
C811 1-135-851-21 MYLAR 0.22uF 100V
C812 1-135-851-21 MYLAR 0.22uF 100V
C813 1-100-968-11 ELECT 4700uF 20% 63V
C814 1-100-968-11 ELECT 4700uF 20% 63V
C815 1-128-582-11 ELECT 10uF 20% 100V
C816 1-128-582-11 ELECT 10uF 20% 100V
C821 1-127-888-11 CERAMIC 0.1uF 10% 50V
C822 1-127-888-11 CERAMIC 0.1uF 10% 50V
C823 1-126-947-11 ELECT 47uF 20% 35V
C824 1-126-947-11 ELECT 47uF 20% 35V
C851 1-127-888-11 CERAMIC 0.1uF 10% 50V
C881 1-126-934-11 ELECT 220uF 20% 16V
C882 1-126-964-11 ELECT 10uF 20% 50V
CC01 1-128-809-11 CERAMIC 100PF 5% 50V
CC02 1-128-809-11 CERAMIC 100PF 5% 50V
CC03 1-128-809-11 CERAMIC 100PF 5% 50V
CC04 1-128-809-11 CERAMIC 100PF 5% 50V
CC11 1-127-876-11 CERAMIC 0.01uF 10% 50V
CC12 1-127-876-11 CERAMIC 0.01uF 10% 50V
CC13 1-127-876-11 CERAMIC 0.01uF 10% 50V
CC14 1-127-876-11 CERAMIC 0.01uF 10% 50V
CC15 1-127-876-11 CERAMIC 0.01uF 10% 50V
CC51 1-128-809-11 CERAMIC 100PF 5% 50V
CC52 1-128-809-11 CERAMIC 100PF 5% 50V
CC53 1-128-809-11 CERAMIC 100PF 5% 50V
CC54 1-128-809-11 CERAMIC 100PF 5% 50V
< CONNECTOR >
CN504 1-779-978-11 PIN, CONNECTOR 3P
CNP501 1-573-847-11 CONNECTOR, BOARD TO BOARD 15P
* CNP502 1-766-715-11 CONNECTOR, BOARD TO BOARD 10P
CNP503 1-779-799-11 PIN, CONNECTOR 9P
* CNP901 1-564-104-00 PIN, CONNECTOR (3.96mm PITCH) 3P
CNP902 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
CNP916 1-766-200-11 SOCKET, CONNECTOR PIN 5P
< DIODE >
D501 8-719-991-33 DIODE 1SS133T-72
D502 8-719-991-33 DIODE 1SS133T-72
D503 8-719-991-33 DIODE 1SS133T-72
D551 8-719-991-33 DIODE 1SS133T-72
D552 8-719-991-33 DIODE 1SS133T-72
D601 8-719-991-33 DIODE 1SS133T-72
D602 8-719-991-33 DIODE 1SS133T-72
D603 8-719-991-33 DIODE 1SS133T-72
D651 8-719-991-33 DIODE 1SS133T-72
D652 8-719-991-33 DIODE 1SS133T-72
D701 8-719-991-33 DIODE 1SS133T-72
D702 8-719-991-33 DIODE 1SS133T-72
D703 8-719-991-33 DIODE 1SS133T-72
D752 8-719-991-33 DIODE 1SS133T-72
D791 8-719-991-33 DIODE 1SS133T-72
D801 8-719-933-95 DIODE HZS20-1LTA
D802 8-719-068-28 DIODE HZ6.8BP-TK
D804 6-500-522-11 DIODE 10EDB40-TA2B5
D805 6-500-522-11 DIODE 10EDB40-TA2B5
D806 6-500-522-11 DIODE 10EDB40-TA2B5
D807 6-500-522-11 DIODE 10EDB40-TA2B5
D811 8-719-072-05 DIODE RBV-602LF-A
D821 8-719-043-76 DIODE AK04V1
D851 8-719-991-33 DIODE 1SS133T-72
D881 8-719-991-33 DIODE 1SS133T-72
D882 8-719-991-33 DIODE 1SS133T-72
D883 8-719-991-33 DIODE 1SS133T-72
< IC >
IC400 6-707-169-01 IC M61542FP
IC501 6-600-450-01 IC STK350-530-E (TYPE1)
IC501 6-710-828-01 IC STK350-530T-E (TYPE2)
IC601 6-600-450-01 IC STK350-530-E (TYPE1)
IC601 6-710-828-01 IC STK350-530T-E (TYPE2)
IC701 6-600-450-01 IC STK350-530-E (TYPE1)
IC701 6-710-828-01 IC STK350-530T-E (TYPE2)
IC821 8-759-071-48 IC TA7807S
IC822 8-759-071-47 IC TA79007S
IC850 8-759-167-88 IC NJM4565D
< JACK >
J400 1-774-411-11 JACK, PIN 6P
(AUDIO IN//VIDEO 2/DVD/SA-CD/CD)
J401 1-794-981-11 JACK, PIN 4P (AUDIO IN/AUDIO OUT//VIDEO 1)
J403 1-770-377-21 JACK, PIN 1P (AUDIO OUT/SUB WOOFER)
< JUMPER RESISTOR >
JW753 1-247-873-91 CARBON 56K 5% 1/4W
< TRANSISTOR >
Q471 8-729-922-37 TRANSISTOR 2SD2144S-TP-UVW
Q501 8-729-119-76 TRANSISTOR 2SA1115TP-EF
Q502 8-729-141-30 TRANSISTOR 2SC3623ATP-LK
Q505 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q506 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q507 8-729-281-53 TRANSISTOR 2SC1815GR-TPE2
Q508 8-729-119-78 TRANSISTOR 2SC1740S-QRT
Q509 8-729-119-78 TRANSISTOR 2SC1740S-QRT
Q551 8-729-119-76 TRANSISTOR 2SA1115TP-EF
Q552 8-729-141-30 TRANSISTOR 2SC3623ATP-LK
Q555 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q556 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q557 8-729-281-53 TRANSISTOR 2SC1815GR-TPE2
Q560 8-729-119-78 TRANSISTOR 2SC1740S-QRT
Q601 8-729-119-76 TRANSISTOR 2SA1115TP-EF
Q602 8-729-141-30 TRANSISTOR 2SC3623ATP-LK
Q605 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q606 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q607 8-729-281-53 TRANSISTOR 2SC1815GR-TPE2
Q608 8-729-119-78 TRANSISTOR 2SC1740S-QRT
MAIN
Ver. 1.2
When replacing the POWER AMPLIFIER IC (IC501, 601, 701), refer to SERVICE
NOTE “Note on replacement POWER AMPLIFIER IC” (page3).
