Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 35 —
D817 8-719-933-61 DIODE HZS9C3LTD
D818 8-719-911-19 DIODE 1SS119
D901 8-719-911-19 DIODE 1SS119
< EARTH >
* G200 1-537-738-21 TERMINAL, EARTH
* G201 1-537-738-21 TERMINAL, EARTH
* G202 1-537-738-21 TERMINAL, EARTH
* G203 1-537-738-21 TERMINAL, EARTH
< IC >
IC1 8-759-450-86 IC BU1922 (AEP,UK,G,EE)
IC300 8-759-527-00 IC LV1035M
IC302 8-759-636-74 IC M5218AP-22
IC401 8-759-805-14 IC LC7822
IC402 8-759-636-74 IC M5218AP-22 (AEP,UK,G,EE)
IC404 8-759-636-74 IC M5218AP-22
IC500 8-759-805-14 IC LC7822
IC501 8-759-636-74 IC M5218AP-22
IC502 8-759-636-74 IC M5218AP-22
IC551 8-749-011-16 IC STK350-230
IC601 8-759-085-89 IC LM3875-S
IC651 8-759-085-89 IC LM3875-S
IC701 8-759-326-52 IC uPC2581V
IC801 8-759-604-40 IC M5F78M15
IC802 8-759-604-46 IC M5F79M15
IC950 8-759-333-83 IC NJM2103D
< JACK >
J401 1-770-614-11 JACK,PIN4P(PHONO/CD) (AEP,UK,G,EE)
J402 1-580-825-11 JACK,PIN6P(TAPE MD/TV/LD)
J403 1-770-613-11 JACK,PIN4P(VIDEO)(AEP,UK,G,EE)
J403 1-580-825-11 JACK,PIN6P(VIDEO)(US,CND,AUS,E,SP,MY,CH)
< COIL >
L1 1-410-521-11 INDUCTOR 100uH (AEP,UK,G,EE)
L301 1-410-509-11 INDUCTOR 10uH
L551 1-420-872-00 COIL, AIR-CORE
L601 1-420-872-00 COIL, AIR-CORE
L651 1-420-872-00 COIL, AIR-CORE
L701 1-420-872-00 COIL, AIR-CORE
L751 1-420-872-00 COIL, AIR-CORE
< IC LINK >
! PS800 1-533-588-31 LINK, IC (AEP,UK,G,EE,E,SP,MY,CH)
< TRANSISTOR >
Q367 8-729-119-78 TRANSISTOR 2SC403SP
Q401 8-729-202-67 TRANSISTOR 2SK246-GR3
Q402 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q451 8-729-202-67 TRANSISTOR 2SK246-GR3
Q452 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q551 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q552 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q553 8-749-010-25 IC MN2488-OPY-M
Q554 8-749-010-26 IC MP1620-OPY-M
Q560 8-729-119-78 TRANSISTOR 2SC403SP-51
Q570 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q610 8-729-119-78 TRANSISTOR 2SC403SP-51
Q701 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q702 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q703 8-749-010-25 IC MN2488-OPY-M
Q704 8-749-010-26 IC MP1620-OPY-M
Q710 8-729-119-78 TRANSISTOR 2SC403SP-51
Q720 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q721 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q722 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q723 8-729-119-78 TRANSISTOR 2SC403SP-51
Q751 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q752 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q753 8-749-010-25 IC MN2488-OPY-M
Q754 8-749-010-26 IC MP1620-OPY-M
Q770 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q801 8-729-140-97 TRANSISTOR 2SB734-34
Q802 8-729-119-78 TRANSISTOR 2SC403SP-51
Q808 8-729-209-15 TRANSISTOR 2SD2012
Q809 8-729-119-78 TRANSISTOR 2SC403SP-51
Q951 8-729-209-15 TRANSISTOR 2SD2012
< RESISTOR >
R5 1-249-421-11 CARBON 2.2K 5% 1/4W F
(AEP,UK,G,EE)
R6 1-247-807-31 CARBON 100 5% 1/4W
(AEP,UK,G,EE)
R7 1-247-807-31 CARBON 100 5% 1/4W
(AEP,UK,G,EE)
R300 1-247-903-00 CARBON 1M 5% 1/4W
R303 1-249-439-11 CARBON 68K 5% 1/4W
R304 1-249-411-11 CARBON 330 5% 1/4W
R306 1-249-436-11 CARBON 39K 5% 1/4W
R307 1-247-862-11 CARBON 20K 5% 1/4W
R308 1-249-421-11 CARBON 2.2K 5% 1/4W F
R309 1-249-421-11 CARBON 2.2K 5% 1/4W F
R357 1-249-441-11 CARBON 100K 5% 1/4W
R358 1-249-441-11 CARBON 100K 5% 1/4W
R359 1-249-425-11 CARBON 4.7K 5% 1/4W F
R360 1-249-425-11 CARBON 4.7K 5% 1/4W F
R374 1-249-429-11 CARBON 10K 5% 1/4W
R375 1-249-429-11 CARBON 10K 5% 1/4W
R397 1-249-419-11 CARBON 1.5K 5% 1/4W F
R399 1-249-426-11 CARBON 5.6K 5% 1/4W
R401 1-249-411-11 CARBON 330 5% 1/4W
(AEP,UK,G,EE)
R402 1-249-421-11 CARBON 2.2K 5% 1/4W F
R403 1-249-417-11 CARBON 1K 5% 1/4W F
R404 1-249-417-11 CARBON 1K 5% 1/4W F
R405 1-249-417-11 CARBON 1K 5% 1/4W F
R406 1-249-417-11 CARBON 1K 5% 1/4W F
R407 1-249-417-11 CARBON 1K 5% 1/4W F
R408 1-249-429-11 CARBON 10K 5% 1/4W
R409 1-249-437-11 CARBON 47K 5% 1/4W
(AEP,UK,G,EE)
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
MAIN
