39
STR-DE485/DE485E
SECTION 6
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
1-683-761-11 AC SELECT BOARD (E)
****************
< CONNECTOR >
* CNP910 1-564-687-11 PIN, CONNECTOR 3P (E)
< SWITCH >
0 S901 1-571-437-21 SWITCH, POWER VOLTAGE CHANGE
(VOLTAGE SELECTOR) (E)
*************************************************************
A-4727-818-A DIGITAL BOARD, COMPLETE (US)
A-4727-843-A DIGITAL BOARD, COMPLETE (CND)
A-4727-851-A DIGITAL BOARD, COMPLETE (AEP,UK)
A-4727-996-A DIGITAL BOARD, COMPLETE (E,MX)
A-4728-002-A DIGITAL BOARD, COMPLETE (CH,AR)
A-4728-862-A DIGITAL BOARD, COMPLETE (AUS)
A-4728-866-A DIGITAL BOARD, COMPLETE (SP)
A-4728-870-A DIGITAL BOARD, COMPLETE (TW)
***********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C1101 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1102 1-126-947-11 ELECT 47uF 20% 16V
C1103 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1104 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1105 1-126-947-11 ELECT 47uF 20% 16V
C1106 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1107 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1108 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1109 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C1110 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C1111 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1112 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1113 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1114 1-162-905-11 CERAMIC CHIP 1PF 0.25PF 50V
C1115 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C1116 1-126-935-11 ELECT 470uF 20% 16V
C1117 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1118 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C1119 1-126-965-11 ELECT 22uF 20% 50V
C1121 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1124 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1126 1-126-964-11 ELECT 10uF 20% 50V
C1127 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1129 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C1130 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1131 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1201 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1202 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1203 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1204 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1205 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1206 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1207 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1208 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1209 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1210 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1211 1-126-935-11 ELECT 470uF 20% 10V
C1212 1-126-935-11 ELECT 470uF 20% 10V
C1213 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1214 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1216 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1218 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1219 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1220 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1221 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(AEP,UK)
C1227 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1229 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1230 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1231 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1309 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1310 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1311 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1312 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1501 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C1502 1-124-234-00 ELECT 22uF 20% 16V
C1503 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1504 1-126-964-11 ELECT 10uF 20% 50V
C1505 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1506 1-126-935-11 ELECT 470uF 20% 16V
C1507 1-126-964-11 ELECT 10uF 20% 50V
C1508 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1509 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1510 1-126-947-11 ELECT 47uF 20% 16V
C1511 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1512 1-162-995-11 CERAMIC CHIP 0.022uF 50V
DIGITAL
• Abbreviation
CND : Canadian model
AR : Argentina model
AUS : Australian model
CH : Chinese model
MX : Mexican model
SP : Singapore model
TW : Taiwan model
When indicating parts by reference
number, please include the board.
AC SELECT
The components identified by mark 0 or
dotted line with mark 0 are critical for
safety.
Replace only with part number specified.
Les composants identifiés par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une piéce portant
le numéro spécifié.
