STR-DE485/DE485E
7
MAIN board
1
CNP801
2
CNP802
5
screw
(BVTP3 x 8)
3
two screws
(BVTP3 x 8)
4
two screws
(BVTP3 x 8)
6
two screws
(BVTP3 x 8)
2-6. MAIN BOARD
