Sony STR-DE485E - DISASSEMBLY; Component Removal Procedures

7
STR-DE485/DE485E
Note : This set can be disassemble according to the following sequence.
SECTION 2
DISASSEMBLY
2-1. CASE
2-1. CASE
(Page 7)
2-2. FRONT PANEL SECTION
(Page 8)
2-3. BACK PANEL
(Page 8)
SET
2-4. DIGITAL BOARD
(Page 9)
2-5. STANDBY BOARD
(Page 9)
2-6. MAIN BOARD
(Page 10)
Note : Follow the disassembly procedure in the numerical order given.
1 two screws
(case 3 TP2)
2 two screws
(case 3 TP2)
3 two screws
(case 3 TP2)
4 cas
e
