43
STR-DE485/DE485E
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-4727-822-A DISPLAY BOARD, COMPLETE (US,AUS,SP,TW)
A-4727-847-A DISPLAY BOARD, COMPLETE
(EXCEPT US,AUS,SP,TW)
************************
* 3-386-245-13 HOLDER (FL) (US,AUS,SP,TW)
3-386-245-21 HOLDER (FL) (EXCEPT US,AUS,SP,TW)
* 4-921-941-01 CUSHION (FL)
< CAPACITOR >
C100 1-164-159-11 CERAMIC 0.1uF 50V
C101 1-164-159-11 CERAMIC 0.1uF 50V
C104 1-164-159-11 CERAMIC 0.1uF 50V
C105 1-126-795-11 ELECT 10uF 20% 50V
C108 1-164-159-11 CERAMIC 0.1uF 50V
C109 1-164-159-11 CERAMIC 0.1uF 50V
C110 1-128-809-11 CERAMIC 100PF 5% 50V
C111 1-128-809-11 CERAMIC 100PF 5% 50V
C112 1-128-809-11 CERAMIC 100PF 5% 50V
C114 1-164-159-11 CERAMIC 0.1uF 50V
C115 1-126-795-11 ELECT 10uF 20% 50V
C132 1-128-813-11 CERAMIC 220PF 5% 50V
C133 1-128-813-11 CERAMIC 220PF 5% 50V
C134 1-128-813-11 CERAMIC 220PF 5% 50V
C135 1-128-813-11 CERAMIC 220PF 5% 50V
C136 1-128-813-11 CERAMIC 220PF 5% 50V
C137 1-128-813-11 CERAMIC 220PF 5% 50V
C138 1-128-813-11 CERAMIC 220PF 5% 50V
C139 1-128-813-11 CERAMIC 220PF 5% 50V
C140 1-128-813-11 CERAMIC 220PF 5% 50V
C141 1-128-813-11 CERAMIC 220PF 5% 50V
C142 1-128-813-11 CERAMIC 220PF 5% 50V
C143 1-128-813-11 CERAMIC 220PF 5% 50V
C144 1-164-159-11 CERAMIC 0.1uF 50V
C145 1-164-159-11 CERAMIC 0.1uF 50V
C150 1-164-159-11 CERAMIC 0.1uF 50V
C151 1-126-795-11 ELECT 10uF 20% 50V
C155 1-164-159-11 CERAMIC 0.1uF 50V
C156 1-164-159-11 CERAMIC 0.1uF 50V
C157 1-164-159-11 CERAMIC 0.1uF 50V
C158 1-128-809-11 CERAMIC 100PF 5% 50V
C159 1-128-809-11 CERAMIC 100PF 5% 50V
C160 1-128-809-11 CERAMIC 100PF 5% 50V
< DIODE >
D100 8-719-075-59 LED SELS5B23C-TP15 (Digital Cinema Sound)
D102 8-719-072-82 LED SELU5E20C-STP15
(MULTI CHANNEL DECODING)
D103 8-719-046-39 LED SEL5821A-TP15 (SOUND FIELD A.F.D.)
D104 8-719-046-39 LED SEL5821A-TP15 (SOUND FIELD 2CH)
D105 8-719-046-39 LED SEL5821A-TP15 (SOUND FIELD MODE)
D111 8-719-046-39 LED SEL5821A-TP15
(SOUND CONTROL LEVEL)
D112 8-719-046-39 LED SEL5821A-TP15 (SOUND CONTROL SURR)
D113 8-719-046-39 LED SEL5821A-TP15 (SET UP)
D114 8-719-046-39 LED SEL5821A-TP15 (NAME)
< FLUORESCENT INDICATOR >
FL101 1-518-718-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC100 8-759-643-83 IC uPD16315GB-3BS
IC101 8-759-036-90 IC MC74ACT08N
IC102 6-600-055-01 IC GP1UD27SXK
< COIL >
L102 1-408-088-00 INDUCTOR 220uH
< TRANSISTOR >
Q100 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q101 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q102 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q103 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q104 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q107 8-729-900-36 TRANSISTOR DTC124ES
Q108 8-729-900-36 TRANSISTOR DTC124ES
Q109 8-729-900-36 TRANSISTOR DTC124ES
Q110 8-729-900-63 TRANSISTOR DTA124ES
Q111 8-729-900-63 TRANSISTOR DTA124ES
< RESISTOR >
R101 1-249-409-11 CARBON 220 5% 1/4W
(US,AUS,SP,TW)
R101 1-249-413-11 CARBON 470 5% 1/4W
(EXCEPT US,AUS,SP,TW)
R102 1-249-411-11 CARBON 330 5% 1/4W
R103 1-249-413-11 CARBON 470 5% 1/4W
R104 1-249-415-11 CARBON 680 5% 1/4W
R105 1-249-417-11 CARBON 1K 5% 1/4W
R106 1-249-419-11 CARBON 1.5K 5% 1/4W
R107 1-249-421-11 CARBON 2.2K 5% 1/4W
R108 1-249-425-11 CARBON 4.7K 5% 1/4W
R109 1-249-429-11 CARBON 10K 5% 1/4W
R111 1-249-409-11 CARBON 220 5% 1/4W
(US,AUS,SP,TW)
R111 1-249-413-11 CARBON 470 5% 1/4W
(EXCEPT US,AUS,SP,TW)
R112 1-249-411-11 CARBON 330 5% 1/4W
R113 1-249-413-11 CARBON 470 5% 1/4W
R114 1-249-415-11 CARBON 680 5% 1/4W
R115 1-249-417-11 CARBON 1K 5% 1/4W
R116 1-249-419-11 CARBON 1.5K 5% 1/4W
R117 1-249-421-11 CARBON 2.2K 5% 1/4W
R118 1-249-425-11 CARBON 4.7K 5% 1/4W
R119 1-249-429-11 CARBON 10K 5% 1/4W
R121 1-249-409-11 CARBON 220 5% 1/4W
R122 1-249-411-11 CARBON 330 5% 1/4W
DISPLAY
