47
STR-DE485/DE485E
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
D804 8-719-118-63 DIODE RD5.6F-T7B2
D896 8-719-043-76 DIODE AK04V0
D902 8-719-024-99 DIODE 11ES2-NTA2B
D903 8-719-024-99 DIODE 11ES2-NTA2B
D904 8-719-024-99 DIODE 11ES2-NTA2B
D905 8-719-024-99 DIODE 11ES2-NTA2B
< IC >
IC201 8-759-827-92 IC M61511FP
IC401 8-759-636-74 IC M5218AP-22
IC501 8-749-011-16 IC STK350-230
IC601 8-759-636-74 IC M5218AP-22
IC701 6-700-943-01 IC uPC2581V-S
IC702 6-700-943-01 IC uPC2581V-S
IC801 8-759-649-68 IC uPC78M07AHF
IC802 8-759-604-95 IC M5F79M07L
< JACK >
J401 1-779-380-11 JACK, PIN 6P (MULTI CH IN FRONT/
SURROUND/CENTER/SUB WOOFER)
J402 1-770-614-11 JACK, PIN 4P (CD IN,MD/TAPE OUT)
J403 1-770-614-11 JACK, PIN 4P (MD/TAPE IN,DVD/LD AUDIO IN)
J404 1-779-380-11 JACK, PIN 6P (VIDEO 2 AUDIO IN,
VIDEO 1 AUDIO OUT/AUDIO IN)
J405 1-774-843-11 JACK, PIN 1P (SUB WOOFER AUDIO OUT)
< COIL >
L521 1-422-009-13 COIL, AIR-CORE
L601 1-422-009-13 COIL, AIR-CORE
L651 1-422-009-13 COIL, AIR-CORE
L701 1-422-009-13 COIL, AIR-CORE
L751 1-422-009-13 COIL, AIR-CORE
< TRANSISTOR >
Q361 8-729-823-22 TRANSISTOR 2SC3576
Q362 8-729-823-22 TRANSISTOR 2SC3576
Q363 8-729-823-22 TRANSISTOR 2SC3576
Q364 8-729-823-22 TRANSISTOR 2SC3576
Q365 8-729-823-22 TRANSISTOR 2SC3576
Q366 8-729-823-22 TRANSISTOR 2SC3576
Q379 8-729-900-63 TRANSISTOR DTA124ES
Q471 8-729-823-22 TRANSISTOR 2SC3576
Q501 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q502 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q505 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q506 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q540 8-729-281-53 TRANSISTOR 2SC1815-GR
Q550 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q560 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q601 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q602 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q605 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q606 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q610 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q640 8-729-281-53 TRANSISTOR 2SC1815-GR
Q651 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q652 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q655 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q656 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q680 8-729-281-53 TRANSISTOR 2SC1815-GR
Q691 8-729-281-53 TRANSISTOR 2SC1815-GR
Q692 8-729-900-63 TRANSISTOR DTA124ES
Q701 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q702 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q705 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q706 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q710 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q722 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q723 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q725 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q740 8-729-281-53 TRANSISTOR 2SC1815-GR
Q747 8-729-900-63 TRANSISTOR DTA124ES
Q748 8-729-900-36 TRANSISTOR DTC124ES
Q750 8-729-281-53 TRANSISTOR 2SC1815-GR
Q751 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q752 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q755 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q756 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q790 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q801 8-729-140-97 TRANSISTOR 2SB734-34
< RESISTOR >
R360 1-249-441-11 CARBON 100K 5% 1/4W
R361 1-249-425-11 CARBON 4.7K 5% 1/4W
R362 1-249-425-11 CARBON 4.7K 5% 1/4W
R363 1-249-441-11 CARBON 100K 5% 1/4W
R366 1-249-429-11 CARBON 10K 5% 1/4W
R367 1-249-441-11 CARBON 100K 5% 1/4W
R368 1-249-437-11 CARBON 47K 5% 1/4W
R369 1-249-425-11 CARBON 4.7K 5% 1/4W
R370 1-249-425-11 CARBON 4.7K 5% 1/4W
R371 1-249-441-11 CARBON 100K 5% 1/4W
R372 1-249-441-11 CARBON 100K 5% 1/4W
R373 1-249-417-11 CARBON 1K 5% 1/4W
R374 1-249-417-11 CARBON 1K 5% 1/4W
R375 1-249-417-11 CARBON 1K 5% 1/4W
R376 1-249-417-11 CARBON 1K 5% 1/4W
R377 1-249-417-11 CARBON 1K 5% 1/4W
R378 1-249-417-11 CARBON 1K 5% 1/4W
R379 1-249-425-11 CARBON 4.7K 5% 1/4W
R380 1-249-441-11 CARBON 100K 5% 1/4W
R381 1-249-429-11 CARBON 10K 5% 1/4W
R402 1-249-417-11 CARBON 1K 5% 1/4W
R404 1-249-417-11 CARBON 1K 5% 1/4W
R405 1-249-417-11 CARBON 1K 5% 1/4W
R406 1-249-417-11 CARBON 1K 5% 1/4W
R407 1-249-417-11 CARBON 1K 5% 1/4W
MAIN
