STR-DE485/DE485E
A-4727-815-A VIDEO BOARD, COMPLETE (US)
A-4727-840-A VIDEO BOARD, COMPLETE (CND,MX)
A-4727-849-A VIDEO BOARD, COMPLETE (AEP,UK,E,CH,AR)
A-4727-968-A VIDEO BOARD, COMPLETE (AUS,SP,TW)
**********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C200 1-128-805-11 CERAMIC 47PF 5% 50V
C201 1-128-805-11 CERAMIC 47PF 5% 50V
C206 1-126-964-11 ELECT 10uF 20% 50V
C207 1-126-964-11 ELECT 10uF 20% 50V
C208 1-126-964-11 ELECT 10uF 20% 50V
C209 1-126-960-11 ELECT 1uF 20% 50V
C210 1-126-964-11 ELECT 10uF 20% 50V
C213 1-126-964-11 ELECT 10uF 20% 50V
C214 1-164-159-11 CERAMIC 0.1uF 50V
C215 1-164-159-11 CERAMIC 0.1uF 50V
C248 1-128-825-11 CERAMIC 0.0022uF 5% 50V
C249 1-128-825-11 CERAMIC 0.0022uF 5% 50V
C809 1-104-665-11 ELECT 100uF 20% 10V
C824 1-164-159-11 CERAMIC 0.1uF 50V
C825 1-164-159-11 CERAMIC 0.1uF 50V
C827 1-126-947-11 ELECT 47uF 20% 25V
< CONNECTOR >
CNP156 1-779-978-11 PIN, CONNECTOR 3P
CNS150 1-569-315-11 SOCKET, CONNECTOR 5P
< DIODE >
D203 8-719-911-19 DIODE 1SS119-25
D204 8-719-911-19 DIODE 1SS119-25
< IC >
IC103 6-701-890-01 IC NJM2595D
IC804 8-759-701-65 IC NJM79M05FA
IC807 8-759-701-75 IC NJM7805FA
< JACK >
J200 1-770-337-11 JACK, PIN 3P (DVD/LD VIDEO IN,
VIDEO 2 VIDEO IN,VIDEO 1 VIDEO OUT)
J201 1-695-317-11 JACK, PIN 2P (VIDEO 1 VIDEO IN,
MONITOR VIDEO OUT)
< RESISTOR >
R200 1-247-804-11 CARBON 75 5% 1/4W
R201 1-247-804-11 CARBON 75 5% 1/4W
R218 1-247-804-11 CARBON 75 5% 1/4W
R219 1-247-804-11 CARBON 75 5% 1/4W
R220 1-247-804-11 CARBON 75 5% 1/4W
R221 1-247-804-11 CARBON 75 5% 1/4W
*************************************************************
MISCELLANEOUS
***************
53 1-773-250-11 WIRE (FLAT TYPE) (27 CORE)
0 105 1-696-847-11 CORD, POWER (AUS)
0 105 1-769-744-11 CORD, POWER (AEP,UK)
0 105 1-777-071-21 CORD, POWER (E,SP,TW)
0 105 1-783-205-11 CORD, POWER (CH)
0 105 1-783-820-11 CORD, POWER (US,CND,MX)
0 105 1-783-941-12 CORD, POWER (AR)
106 1-769-940-11 WIRE (FLAT TYPE) (11 CORE) (EXCEPT AEP,UK)
106 1-773-004-11 WIRE (FLAT TYPE) (15 CORE) (AEP,UK)
107 1-575-662-31 WIRE (FLAT TYPE) (5 CORE) (AUS,SP,TW)
107 1-769-844-11 WIRE (FLAT TYPE) (5 CORE)
(EXCEPT AUS,SP,TW)
0 F901 1-532-464-31 FUSE (T2.5A/250V) (EXCEPT US,CND,MX,TW)
0 F901 1-576-109-11 FUSE (5A/125V) (TW)
0 F901 1-576-193-11 FUSE (6.3A/125V) (US,CND,MX)
Q503 8-749-010-25 TRANSISTOR MN2488-OPY-M
Q504 8-749-010-26 TRANSISTOR MP1620-OPY-M
Q603 8-749-010-25 TRANSISTOR MN2488-OPY-M
Q604 8-749-010-26 TRANSISTOR MP1620-OPY-M
Q653 8-749-010-25 TRANSISTOR MN2488-OPY-M
Q654 8-749-010-26 TRANSISTOR MP1620-OPY-M
Q703 8-749-010-25 TRANSISTOR MN2488-OPY-M
Q704 8-749-010-26 TRANSISTOR MP1620-OPY-M
Q753 8-749-010-25 TRANSISTOR MN2488-OPY-M
Q754 8-749-010-26 TRANSISTOR MP1620-OPY-M
0 T901 1-437-632-11 TRANSFORMER, POWER (US,MX)
0 T901 1-437-633-11 TRANSFORMER, POWER (AEP,UK,CH,SP,AR)
0 T901 1-437-634-11 TRANSFORMER, POWER (CND)
0 T901 1-437-635-11 TRANSFORMER, POWER (E)
0 T901 1-437-637-11 TRANSFORMER, POWER (AUS)
0 T901 1-437-638-11 TRANSFORMER, POWER (TW)
TM301 1-693-577-11 TUNER PACK (FM/AM) (ANTENNA) (E)
TM301 1-693-577-21 TUNER PACK (FM/AM) (ANTENNA)
(US,CND,MX,TW)
TM301 1-693-578-21 TUNER PACK (FM/AM) (ANTENNA) (AEP,UK)
TM301 1-693-580-21 TUNER PACK (FM/AM) (ANTENNA)
(AUS,CH,SP,AR)
*************************************************************
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
VIDEO
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
