Main unit
A.F.D. (button/indicator) qs (28,
29, 30, 43)
DIMMER 4 (26)
DISPLAY 3 (25, 26, 44)
Display 7 (25, 26)
DVD wk (21)
ENTER 9 (17, 18, 35)
FM MODE wd (22)
Input buttons ql (21, 31, 34, 35)
INPUT MODE qh (31)
IR (receptor) 5 (38, 44)
MAIN MENU 8 (18, 31, 33, 35)
MASTER VOLUME –/+ qg (17,
20, 21, 43)
MD/TAPE wj (21)
MEMORY ws (23)
MOVIE (button/indicator) qd
(29, 43)
MULTI CH IN q; (21)
MULTI CHANNEL DECODING
(indicator) 6 (21)
MUSIC (button/indicator) qf (30,
43)
PHONES (jack) wf (21, 43)
PRESET TUNING –/+ w; (23,
47)
SA-CD/CD wh (21)
SPEAKERS (OFF/A/B/A+B) 2
(16, 36, 43)
TUNER FM/AM wg (21, 22, 23,
24, 35)
TUNING –/+ wa (22, 47)
VIDEO 1 e; (21)
VIDEO 2 wl (21)
2CH (button/indicator) qa (28,
30, 32)
+/– qj (18, 31, 33, 35)
</> qk (18, 31, 33, 35)
?/1 (power) 1 (17, 18, 23, 32,
47)
List of button locations and reference pages
How to use page 48 and 49
Use this page to find the location of buttons that are
mentioned in the text.
Ill
us
t
ra
ti
on num
b
er
r
DISPLAY 3 (25, 26, 44)
RR
Name of button/part Reference page
ALPHABETICAL ORDER
A - L
M - Z
NUMBERS AND SYMBOLS
