Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 30 —
R228 1-249-412-11 CARBON 390 5% 1/4W F
R229 1-249-410-11 CARBON 270 5% 1/4W F
(DE515:E,SP,AUS,EA,PX,MY/V505)
R230 1-249-410-11 CARBON 270 5% 1/4W F
R231 1-249-427-11 CARBON 6.8K 5% 1/4W F
R262 1-247-839-11 CARBON 2.2K 5% 1/4W
R283 1-249-427-11 CARBON 6.8K 5% 1/4W F
R284 1-249-427-11 CARBON 6.8K 5% 1/4W F
R285 1-249-399-11 CARBON 33 5% 1/4W F
R286 1-249-437-11 CARBON 47K 5% 1/4W
R270 1-247-807-31 CARBON 100 5% 1/4W
< SWITCH >
S200 1-762-751-11 SWITCH, TACTILE (POWER)
(D460Z/DE515:US,Canadian,E,EA,PX,AUS)
S201 1-762-751-11 SWITCH, TACTILE (CENTER LEVEL –)
S202 1-762-751-11 SWITCH, TACTILE (CENTER LEVEL +)
S203 1-762-751-11 SWITCH, TACTILE (REAR LEVEL –)
S204 1-762-751-11 SWITCH, TACTILE (REAR LEVEL +)
S209 1-762-751-11 SWITCH, TACTILE (TUNING LEVEL –)
S210 1-762-751-11 SWITCH, TACTILE (TUNING LEVEL +)
S211 1-762-751-11 SWITCH, TACTILE (PRESET TUNING –)
S212 1-762-751-11 SWITCH, TACTILE (PRESET TUNING +)
S213 1-762-751-11 SWITCH, TACTILE (FM MODE)
S214 1-762-751-11 SWITCH, TACTILE (FM)
S215 1-762-751-11 SWITCH, TACTILE (AM)
S216 1-762-751-11 SWITCH, TACTILE (MEMORY)
SW200 1-771-054-11 SWITCH, PUSH (1 KEY) (POWER)
(DE515:SP,MY/V505)
< VIBRATOR >
X201 1-577-101-11 VIBRATOR, CERAMIC 4.19MHz
************************************************************
* A-4392-781-A KEY BOARD, COMPLETE
********************
< CONNECTOR >
CNS205 1-770-397-11 HOUSING, CONNECTOR(PC BOARD)4P
< RESISTOR >
R232 1-249-411-11 CARBON 330 5% 1/4W
R233 1-249-413-11 CARBON 470 5% 1/4W F
R234 1-249-415-11 CARBON 680 5% 1/4W F
R235 1-249-417-11 CARBON 1K 5% 1/4W F
R236 1-249-419-11 CARBON 1.5K 5% 1/4W F
R237 1-249-421-11 CARBON 2.2K 5% 1/4W F
R238 1-247-843-11 CARBON 3.3K 5% 1/4W
R239 1-249-411-11 CARBON 330 5% 1/4W
R240 1-249-413-11 CARBON 470 5% 1/4W F
R241 1-249-415-11 CARBON 680 5% 1/4W F
R242 1-249-417-11 CARBON 1K 5% 1/4W F
R243 1-249-419-11 CARBON 1.5K 5% 1/4W F
R244 1-249-421-11 CARBON 2.2K 5% 1/4W F
R245 1-247-843-11 CARBON 3.3K 5% 1/4W
R246 1-249-411-11 CARBON 330 5% 1/4W
R247 1-249-413-11 CARBON 470 5% 1/4W F
R248 1-249-415-11 CARBON 680 5% 1/4W F
R249 1-249-417-11 CARBON 1K 5% 1/4W F
R280 1-249-419-11 CARBON 1.5K 5% 1/4W F
R281 1-249-421-11 CARBON 2.2K 5% 1/4W F
R282 1-247-843-11 CARBON 3.3K 5% 1/4W
< SWITCH >
S217 1-762-751-11 SWITCH, TACTILE (SURROUND ON/OFF)
S218 1-762-751-11 SWITCH, TACTILE (SET UP)
S219 1-762-751-11 SWITCH, TACTILE (EFFECT/DELAY TIME)
S220 1-762-751-11 SWITCH, TACTILE (TV/DBS)
S221 1-762-751-11 SWITCH, TACTILE (TUNER)
S222 1-762-751-11 SWITCH, TACTILE (PHONE)
S223 1-762-751-11 SWITCH, TACTILE (VIDEO)
S224 1-762-751-11 SWITCH, TACTILE (6)
S225 1-762-751-11 SWITCH, TACTILE (7)
S226 1-762-751-11 SWITCH, TACTILE (8)
S227 1-762-751-11 SWITCH, TACTILE (9)
S228 1-762-751-11 SWITCH, TACTILE (0)
S229 1-762-751-11 SWITCH, TACTILE (SHIFT)
S230 1-762-751-11 SWITCH, TACTILE (5.1/DVD INPUT)
S231 1-762-751-11 SWITCH, TACTILE (TAPE/MD)
S232 1-762-751-11 SWITCH, TACTILE (1)
S233 1-762-751-11 SWITCH, TACTILE (2)
S234 1-762-751-11 SWITCH, TACTILE (3)
S235 1-762-751-11 SWITCH, TACTILE (4)
S236 1-762-751-11 SWITCH, TACTILE (5)
S237 1-762-751-11 SWITCH, TACTILE (DIRECT)
S238 1-762-751-11 SWITCH, TACTILE (MODE)
S239 1-762-751-11 SWITCH, TACTILE (CD)
************************************************************
* A-4398-839-A MAIN BOARD, COMPLETE (V505)
*********************
* A-4392-976-A MAIN BOARD, COMPLETE (DE515:AUS)
*********************
* A-4392-979-A MAIN BOARD, COMPLETE (DE515:SP,MY)
*********************
* A-4392-984-A MAIN BOARD, COMPLETE (D460Z)
*********************
* A-4392-785-A MAIN BOARD, COMPLETE (DE515:US)
*********************
* A-4392-973-A MAIN BOARD, COMPLETE (DE515:Canadian)
*********************
* A-4392-983-A MAIN BOARD, COMPLETE (DE515:E,EA,PX)
*********************
3-905-609-01 SCREW (TRANSISTOR)
4-812-134-00 RIVET (DIA. 3.5), NYLON
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
7-685-872-09 SCREW +BVTT 3X8 (S)
< CAPACITOR >
C302 1-126-934-11 ELECT 220uF 20% 16V
C303 1-130-494-11 MYLAR 0.082uF 5% 50V
C304 1-137-367-11 FILM 0.0033uF 5% 50V
C305 1-130-494-11 MYLAR 0.082uF 5% 50V
C306 1-126-959-11 ELECT 0.47uF 20% 50V
C307 1-126-964-11 ELECT 10uF 20% 50V
C308 1-126-964-11 ELECT 10uF 20% 50V
C309 1-162-291-31 CERAMIC 560PF 10% 50V
C310 1-126-962-11 ELECT 3.3uF 20% 50V
C311 1-126-961-11 ELECT 2.2uF 20% 50V
C312 1-126-934-11 ELECT 220uF 20% 16V
C313 1-126-934-11 ELECT 220uF 20% 16V
C314 1-136-165-00 FILM 0.1uF 5% 50V
C316 1-124-252-00 ELECT 0.33uF 20% 50V
C317 1-126-933-11 ELECT 100uF 20% 16V
DISPLAY KEY MAIN
