Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 33 —
Q723 8-729-119-78 TRANSISTOR 2SC403SP-51
Q751 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q752 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q753 8-749-010-25 IC MN2488-OPY-M
Q754 8-749-010-26 IC MP1620-OPY-M
Q770 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q801 8-729-140-97 TRANSISTOR 2SB734-34
Q802 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q808 8-729-030-18 TRANSISTOR 2SD809-K
Q809 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q951 8-729-030-18 TRANSISTOR 2SD809-K
< RESISTOR >
R300 1-247-903-00 CARBON 1M 5% 1/4W
R301 1-249-421-11 CARBON 2.2K 5% 1/4W F
R302 1-249-421-11 CARBON 2.2K 5% 1/4W F
R303 1-249-439-11 CARBON 68K 5% 1/4W
R304 1-249-411-11 CARBON 330 5% 1/4W
R306 1-249-436-11 CARBON 39K 5% 1/4W
R307 1-247-862-11 CARBON 20K 5% 1/4W
R308 1-249-421-11 CARBON 2.2K 5% 1/4W F
R309 1-249-421-11 CARBON 2.2K 5% 1/4W F
R357 1-249-441-11 CARBON 100K 5% 1/4W
R358 1-249-441-11 CARBON 100K 5% 1/4W
R359 1-249-425-11 CARBON 4.7K 5% 1/4W F
R360 1-249-425-11 CARBON 4.7K 5% 1/4W F
R363 1-249-411-11 CARBON 330 5% 1/4W
(DE515:SP,MY/V505)
R372 1-249-425-11 CARBON 4.7K 5% 1/4W F
R373 1-249-417-11 CARBON 1K 5% 1/4W F
R374 1-249-429-11 CARBON 10K 5% 1/4W
R375 1-249-429-11 CARBON 10K 5% 1/4W
R401 1-249-411-11 CARBON 330 5% 1/4W
R402 1-249-421-11 CARBON 2.2K 5% 1/4W F
R403 1-249-417-11 CARBON 1K 5% 1/4W F
R404 1-249-417-11 CARBON 1K 5% 1/4W F
R405 1-249-417-11 CARBON 1K 5% 1/4W F
R406 1-249-417-11 CARBON 1K 5% 1/4W F
R407 1-249-417-11 CARBON 1K 5% 1/4W F
R408 1-249-429-11 CARBON 10K 5% 1/4W
R409 1-249-437-11 CARBON 47K 5% 1/4W
R410 1-247-897-11 CARBON 560K 5% 1/4W
R411 1-249-416-11 CARBON 820 5% 1/4W F
R412 1-247-897-11 CARBON 560K 5% 1/4W
R413 1-249-437-11 CARBON 47K 5% 1/4W
R414 1-249-425-11 CARBON 4.7K 5% 1/4W F
R415 1-249-417-11 CARBON 1K 5% 1/4W F
R416 1-249-417-11 CARBON 1K 5% 1/4W F
R417 1-247-897-11 CARBON 560K 5% 1/4W
R420 1-249-441-11 CARBON 100K 5% 1/4W
R435 1-249-418-11 CARBON 1.2K 5% 1/4W F
R442 1-249-418-11 CARBON 1.2K 5% 1/4W F
R443 1-249-418-11 CARBON 1.2K 5% 1/4W F
R447 1-249-416-11 CARBON 820 5% 1/4W F
R448 1-249-429-11 CARBON 10K 5% 1/4W
R449 1-249-433-11 CARBON 22K 5% 1/4W
R450 1-249-400-11 CARBON 39 5% 1/4W F
R451 1-249-411-11 CARBON 330 5% 1/4W
R452 1-249-421-11 CARBON 2.2K 5% 1/4W F
R453 1-249-417-11 CARBON 1K 5% 1/4W F
R454 1-249-417-11 CARBON 1K 5% 1/4W F
R455 1-249-417-11 CARBON 1K 5% 1/4W F
R456 1-249-417-11 CARBON 1K 5% 1/4W F
R457 1-249-417-11 CARBON 1K 5% 1/4W F
R458 1-249-429-11 CARBON 10K 5% 1/4W
R459 1-249-437-11 CARBON 47K 5% 1/4W
R460 1-247-897-11 CARBON 560K 5% 1/4W
R461 1-249-416-11 CARBON 820 5% 1/4W F
R462 1-247-897-11 CARBON 560K 5% 1/4W
R463 1-249-437-11 CARBON 47K 5% 1/4W
R465 1-249-417-11 CARBON 1K 5% 1/4W F
R466 1-249-417-11 CARBON 1K 5% 1/4W F
R467 1-247-897-11 CARBON 560K 5% 1/4W
R470 1-249-441-11 CARBON 100K 5% 1/4W
R513 1-249-429-11 CARBON 10K 5% 1/4W
R514 1-249-429-11 CARBON 10K 5% 1/4W
R515 1-249-419-11 CARBON 1.5K 5% 1/4W F
R516 1-249-419-11 CARBON 1.5K 5% 1/4W F
R517 1-249-429-11 CARBON 10K 5% 1/4W
R518 1-249-429-11 CARBON 10K 5% 1/4W
R551 1-249-417-11 CARBON 1K 5% 1/4W F
R552 1-249-438-11 CARBON 56K 5% 1/4W
R553 1-249-412-11 CARBON 390 5% 1/4W F
(DE515:SP,MY/V505)
R553 1-249-411-11 CARBON 330 5% 1/4W
(D460Z/DE515:US,Canadian,E,EA,PX)
R554 1-249-438-11 CARBON 56K 5% 1/4W
R555 1-249-413-11 CARBON 470 5% 1/4W F
R560 1-249-421-11 CARBON 2.2K 5% 1/4W F
R561 1-249-437-11 CARBON 47K 5% 1/4W
R562 1-249-431-11 CARBON 15K 5% 1/4W
R563 1-249-414-11 CARBON 560 5% 1/4W F
! R564 1-249-409-11 CARBON 220 5% 1/4W F
(DE515:SP,MY/V505)
! R564 1-249-408-11 CARBON 180 5% 1/4W F
(D460Z/DE515:US,Canadian,E,EA,PX,AUS)
! R565 1-249-409-11 CARBON 220 5% 1/4W F
(DE515:SP,MY/V505)
! R565 1-249-408-11 CARBON 180 5% 1/4W F
(D460Z/DE515:US,Canadian,E,EA,PX,AUS)
! R566 1-233-352-21 ENCAPSULATED COMPONENT
! R567 1-249-393-11 CARBON 10 5% 1/4W F
R568 1-249-389-11 CARBON 4.7 5% 1/4W F
! R569 1-249-413-11 CARBON 470 5% 1/4W F
R570 1-249-419-11 CARBON 1.5K 5% 1/4W F
R571 1-249-427-11 CARBON 6.8K 5% 1/4W F
R573 1-249-437-11 CARBON 47K 5% 1/4W
R580 1-249-426-11 CARBON 5.6K 5% 1/4W
R581 1-247-887-00 CARBON 220K 5% 1/4W
R582 1-249-426-11 CARBON 5.6K 5% 1/4W
R601 1-249-417-11 CARBON 1K 5% 1/4W F
R602 1-249-438-11 CARBON 56K 5% 1/4W
R603 1-249-438-11 CARBON 56K 5% 1/4W
MAIN
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifie.
