Inputs (Digital) DVD/LD (coaxial):
Sensitivity: –
Impedance: 75Ω
S/N: 100dB (A, 20kHz LPF)
DVD/LD (Optical):
Sensitivity: –
Impedance: –
S/N: 100dB (A, 20kHz LPF)
Outputs MD/TAPE, (REC OUT);
VIDEO1,2 (AUDIO OUT):
Voltage: 150mV,
Impedance: 10kΩ
SUB WOOFER:
Voltage:2V
Impedance: 1kΩ
PHONES:
Accepts low-and high-impedance headphones
BASS BOOST +6dB at 70Hz
Sampling Frequency 48kHz
EQ BASS: 100Hz – 1.0kHz (21steps)
MID: 500Hz – 5.0kHz (21steps)
TABLE: 1.0kHz – 10kHz (21steps)
Gain levels: ±10dB, 1dB step
FM tuner section
Tuning range 87.5 – 108.0MHz
Antenna terminals 75Ω, unbalanced
Sensitivity Mono: 18.3dBf, 2.2µV/75Ω
Stereo: 38.3dBf, 22.5µV/75Ω
Usable sensitivity 11.2dBf, 1µV/75Ω
S/N Mono: 76dB
Stereo: 70dB
Harmonic destortion at 1kHz
Mono: 0.3%
Stereo: 0.5%
Separetion 45dB at 1kHz
Frequency response 30Hz – 15kHz + 0.5/–2dB
Selectivity 60dB at 400kHz
AM tuner section
Tuning range USA, Canadian models:
With 10-kHz tuning scale:
530 – 1,710kHz
d)
With 9-kHz tuning scale:
531 – 1,710kHz
d)
AEP model
531 – 1,602kHz
Antenna Loop antenna
Usable sensitivity 50dB/m (at 1,000kHz or 999kHz)
S/N 54dB (at 50mV/m)
Harmonic destortion 0.5% (50mV/m, 400kHz)
Selectivity At 9kHz: 35dB
At 10kHz: 40dB
d) You can change the AM tuning scale to 9kHz. After tuning in any AM
station, turn off the receiver. Hold down the TUNING+ button and
press the 1/u button. All preset stations will be erased when you
change the tuning scale. To reset the scale to 10kHz, repeat the
procedure.
Video section
Inputs 1Vp-p 75Ω
Outputs 1Vp-p 75Ω
General
System Tuner section:
PLL quartz-locked digital synthesizer system
Preamplifier section:
Low-noise NF type equalizer
Power amplifier section:
Pure-complementary SEPP
Power requirements USA, Canadian models:
120V AC, 60Hz
AEP model
230V AC, 50/60Hz
Power consumption USA: 270W
Canada: 285VA
AEP: 200W
AC outlets USA, Canadian models:
2switched, total 100W
AEP model
1switched, max 100W
Dimensions 430 × 364 × 157.5mm
(17 × 14
5
/16 × 6
1
/4 in.)
including projecting parts and controls
Mass (Approx.) USA, Canadian models:
9.5kg (20 lbs. 15 oz.)
AEP model
10.1kg
Supplied accessories FM wire antenna (1)
AM loop antenna (1)
Remote commander RM-PP402 (remote) (1)
R6 (size-AA) batteries (2)
FM antenna adapter (1)
Design and specifications are subject to change without notice.
