Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 65 —
< EARTH TERMINAL >
* EB801 1-537-738-21 TERMINAL, EARTH
< FUSE >
!F801 1-533-311-11 FUSE, GLASS CYLINDRICAL (DIA.5) 8A/125V
!F802 1-533-311-11 FUSE, GLASS CYLINDRICAL (DIA.5) 8A/125V
!F803 1-533-419-11 FUSE, GLASS CYLINDRICAL (DIA.5) 4A/125V
(US,CND)
< TRANSISTOR >
Q801 8-729-048-78 TRANSISTOR 2SD1733-TL-QR
< RESISTOR >
!R801 1-247-727-11 CARBON 10 5% 1/2W F
R802 1-249-401-11 CARBON 47 5% 1/4W F
R803 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R804 1-216-081-00 METAL CHIP 22K 5% 1/10W
************************************************************
* A-4419-439-A DIGITAL BOARD, COMPLETE (US,CND)
***********************
A-4426-045-A DIGITAL BOARD, COMPLETE (AEP)
***********************
< CAPACITOR >
C1001 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1005 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1006 1-126-935-11 ELECT 470uF 20% 6.3V
(US,CND)
C1006 1-128-834-11 ELECT 470uF 20% 10V
(AEP)
C1007 1-126-965-11 ELECT 22uF 20% 50V
C1008 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1009 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1010 1-163-217-11 CERAMIC CHIP 1PF 0.25PF 50V
C1011 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1012 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1013 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1014 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1015 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1016 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1017 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C1018 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C1019 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C1020 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C1031 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C1101 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1102 1-104-664-11 ELECT 47uF 20% 16V
C1103 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1104 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C1105 1-104-664-11 ELECT 47uF 20% 16V
C1106 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1107 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C1108 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1109 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1110 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C1111 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1156 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C1157 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1201 1-119-824-11 ELECT MELF 10uF 20% 50V
C1202 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1203 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1204 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1205 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1206 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C1207 1-104-664-11 ELECT 47uF 20% 16V
C1208 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1209 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1210 1-104-664-11 ELECT 47uF 20% 16V
C1211 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1212 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1213 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1214 1-104-664-11 ELECT 47uF 20% 16V
C1215 1-126-935-11 ELECT 470uF 20% 16V
C1216 1-126-935-11 ELECT 470uF 20% 16V
C1217 1-126-935-11 ELECT 470uF 20% 16V
C1218 1-126-959-11 ELECT 0.47uF 20% 50V
C1219 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1220 1-126-957-11 ELECT 0.22uF 20% 50V
C1221 1-119-824-11 ELECT MELF 10uF 20% 50V
C1222 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1223 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1224 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1225 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1226 1-126-960-11 ELECT 1uF 20% 50V
C1227 1-104-664-11 ELECT 47uF 20% 16V
C1228 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C1229 1-126-935-11 ELECT 470uF 20% 16V
(US,CND)(SUFFIX-12)
C1229 1-127-720-91 ELECT 470uF 20% 16V
(AEP)(SUFFIX-12)
C1230 1-165-319-11 CERAMIC CHIP 0.1uF 50V
(SUFFIX-12)
C1301 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1303 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1304 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1305 1-104-664-11 ELECT 47uF 20% 16V
C1306 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C1307 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1309 1-126-935-11 ELECT 470uF 20% 6.3V
(US,CND)
C1309 1-128-834-11 ELECT 470uF 20% 10V
(AEP)
C1310 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1311 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1312 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1313 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1314 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1315 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C1401 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1402 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1403 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
DC DIGITAL
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
Ver 1.1 2002. 02
