Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 78 —
S138 1-771-349-21 SWITCH, KEYBOARD (NAME)
S139 1-771-349-21 SWITCH, KEYBOARD (ENTER)
S140 1-771-349-21 SWITCH, KEYBOARD (SHIFT)
S141 1-771-349-21 SWITCH, KEYBOARD (TUNING CHAR –)
S142 1-771-349-21 SWITCH, KEYBOARD (TUNING CHAR +)
S143 1-771-349-21 SWITCH, KEYBOARD (PRESET/PTY SELECT –)
S144 1-771-349-21 SWITCH, KEYBOARD (LEVEL)
************************************************************
* 1-673-357-11 S-VIDEO BOARD
*************
< CAPACITOR >
C214 1-104-664-11 ELECT 47uF 20% 16V
C264 1-165-319-11 CERAMIC CHIP 0.1uF 50V
< CONNECTOR >
CNS211 1-695-094-11 SOCKET, CONNECTOR 11P
CNS215 1-784-776-11 CONNECTOR, FFC 15P
< IC >
IC202 8-759-245-79 IC M5F7905L
************************************************************
* 1-673-358-11 TUNER BOARD
************
< CAPACITOR >
C1 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
(AEP)
C2 1-126-961-11 ELECT 2.2uF 20% 50V
(AEP)
C3 1-126-964-11 ELECT 10uF 20% 50V
(AEP)
C4 1-165-319-11 CERAMIC CHIP 0.1uF 50V (AEP)
C5 1-163-135-00 CERAMIC CHIP 560PF 5% 50V
(AEP)
C6 1-163-249-11 CERAMIC CHIP 82PF 5% 50V
(AEP)
C7 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
(AEP)
C381 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C382 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C399 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CNS303 1-569-306-11 SOCKET, CONNECTOR (L TYRE) 15P
CNS305 1-774-289-11 PIN, CONNECTOR (PC BOARD) 15P
< IC >
IC1 8-759-557-36 IC BU1924F-E2 (AEP)
IC399 8-759-708-12 IC NJM78L12A-T3
< COIL >
L1 1-408-982-11 INDUCTOR 100uH (AEP)
< RESISTOR >
R1 1-216-025-91 RES,CHIP 100 5% 1/10W
(AEP)
R2 1-216-025-91 RES,CHIP 100 5% 1/10W
(AEP)
R3 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
(AEP)
< VIBRATOR >
X1 1-579-900-21 VIBRATOR, CRYSTAL (4.33MHz)(AEP)
************************************************************
* 1-673-356-11 VIDEO BOARD
***********
< CAPACITOR >
C201 1-126-964-11 ELECT 10uF 20% 50V
C202 1-126-964-11 ELECT 10uF 20% 50V
C203 1-126-964-11 ELECT 10uF 20% 50V
C204 1-126-964-11 ELECT 10uF 20% 50V
C205 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C206 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C207 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C208 1-126-964-11 ELECT 10uF 20% 50V
C209 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C210 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C211 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C212 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C213 1-104-664-11 ELECT 47uF 20% 16V
C215 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C216 1-104-664-11 ELECT 47uF 20% 16V
< CONNECTOR >
CNS212 1-695-094-11 SOCKET, CONNECTOR 11P
< DIODE >
D201 8-719-801-78 DIODE 1SS184-TE85L
< IC >
IC201 8-759-536-24 IC NJM-2296M-TE2
< JACK >
J201 1-785-867-11 JACK, PIN 1P (MONITOR)
J202 1-785-866-11 JACK, PIN 3P (DVD/VIDEO2)
J203 1-785-866-11 JACK, PIN 3P (VIDEO 2/VIDEO 1)
J204 1-563-330-11 JACK (S-LINK)
< RESISTOR >
R201 1-216-022-00 METAL CHIP 75 5% 1/10W
R202 1-216-022-00 METAL CHIP 75 5% 1/10W
R203 1-216-022-00 METAL CHIP 75 5% 1/10W
R204 1-216-022-00 METAL CHIP 75 5% 1/10W
R205 1-216-022-00 METAL CHIP 75 5% 1/10W
R206 1-216-022-00 METAL CHIP 75 5% 1/10W
R207 1-216-022-00 METAL CHIP 75 5% 1/10W
R208 1-216-022-00 METAL CHIP 75 5% 1/10W
************************************************************
VIDEOTUNERS-VIDEOSW
