Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
42
STR-DE675
R696 1-249-429-11 CARBON 10K 5% 1/4W
R697 1-249-441-11 CARBON 100K 5% 1/4W
R698 1-249-429-11 CARBON 10K 5% 1/4W
R701 1-249-417-11 CARBON 1K 5% 1/4W F
R702 1-249-439-11 CARBON 68K 5% 1/4W
R703 1-249-418-11 CARBON 1.2K 5% 1/4W F
R704 1-249-439-11 CARBON 68K 5% 1/4W
R710 1-249-421-11 CARBON 2.2K 5% 1/4W F
R711 1-249-440-11 CARBON 82K 5% 1/4W
R713 1-249-414-11 CARBON 560 5% 1/4W F
0R714 1-249-409-11 CARBON 220 5% 1/4W F
0R715 1-249-409-11 CARBON 220 5% 1/4W F
0R716 1-234-182-11 ENCAPSULATED COMPONENT
0R717 1-249-393-11 CARBON 10 5% 1/4W F
0R718 1-249-389-11 CARBON 4.7 5% 1/4W F
R719 1-249-425-11 CARBON 4.7K 5% 1/4W F
R721 1-247-850-11 CARBON 6.2K 5% 1/4W
R722 1-249-419-11 CARBON 1.5K 5% 1/4W F
R723 1-249-437-11 CARBON 47K 5% 1/4W
R724 1-249-431-11 CARBON 15K 5% 1/4W
R725 1-247-881-00 CARBON 120K 5% 1/4W
R731 1-249-425-11 CARBON 4.7K 5% 1/4W F
0R732 1-249-381-11 CARBON 1 5% 1/4W F
0R733 1-249-381-11 CARBON 1 5% 1/4W F
0R734 1-249-389-11 CARBON 4.7 5% 1/4W F
R735 1-249-427-11 CARBON 6.8K 5% 1/4W F
R736 1-249-417-11 CARBON 1K 5% 1/4W F
R737 1-249-436-11 CARBON 39K 5% 1/4W
R740 1-247-866-11 CARBON 30K 5% 1/4W
R742 1-249-437-11 CARBON 47K 5% 1/4W
R743 1-249-433-11 CARBON 22K 5% 1/4W
R744 1-249-433-11 CARBON 22K 5% 1/4W
R745 1-249-433-11 CARBON 22K 5% 1/4W
R746 1-249-433-11 CARBON 22K 5% 1/4W
R747 1-249-431-11 CARBON 15K 5% 1/4W
R750 1-247-866-11 CARBON 30K 5% 1/4W
R751 1-249-417-11 CARBON 1K 5% 1/4W F
R752 1-249-439-11 CARBON 68K 5% 1/4W
R753 1-249-418-11 CARBON 1.2K 5% 1/4W F
R754 1-249-439-11 CARBON 68K 5% 1/4W
R755 1-249-433-11 CARBON 22K 5% 1/4W
R756 1-249-433-11 CARBON 22K 5% 1/4W
R757 1-249-431-11 CARBON 15K 5% 1/4W
R760 1-249-421-11 CARBON 2.2K 5% 1/4W F
R761 1-249-440-11 CARBON 82K 5% 1/4W
R763 1-249-414-11 CARBON 560 5% 1/4W F
0R764 1-249-409-11 CARBON 220 5% 1/4W F
0R765 1-249-409-11 CARBON 220 5% 1/4W F
0R766 1-234-182-11 ENCAPSULATED COMPONENT
0R767 1-249-393-11 CARBON 10 5% 1/4W F
0R768 1-249-389-11 CARBON 4.7 5% 1/4W F
R769 1-249-425-11 CARBON 4.7K 5% 1/4W F
R771 1-247-850-11 CARBON 6.2K 5% 1/4W
R772 1-249-419-11 CARBON 1.5K 5% 1/4W F
R773 1-249-437-11 CARBON 47K 5% 1/4W
R775 1-247-881-00 CARBON 120K 5% 1/4W
R778 1-249-431-11 CARBON 15K 5% 1/4W
R791 1-249-425-11 CARBON 4.7K 5% 1/4W F
R792 1-215-868-00 METAL OXIDE 680 5% 1W
0R793 1-249-389-11 CARBON 4.7 5% 1/4W F
R794 1-215-868-00 METAL OXIDE 680 5% 1W
R801 1-240-877-11 FUSIBLE 0.15 5% 1/2W
0R802 1-249-381-11 CARBON 1 5% 1/4W F
0R803 1-249-389-11 CARBON 4.7 5% 1/4W F
R804 1-249-426-11 CARBON 5.6K 5% 1/4W
0RR11 1-249-393-11 CARBON 10 5% 1/4W F
(EXCEPT US,CND)
0RR12 1-249-393-11 CARBON 10 5% 1/4W F
(EXCEPT US,CND)
0RR13 1-249-393-11 CARBON 10 5% 1/4W F
(EXCEPT US,CND)
0RR14 1-249-393-11 CARBON 10 5% 1/4W F
(EXCEPT US,CND)
0RR15 1-249-393-11 CARBON 10 5% 1/4W F
(EXCEPT US,CND)
< RELAY >
RY501 1-755-170-11 RELAY (12V)
RY560 1-755-267-11 RELAY
RY601 1-755-170-11 RELAY (12V)
RY701 1-755-170-11 RELAY (12V)
RY791 1-755-170-11 RELAY (12V)
< TERMINAL >
TM601 1-694-431-21 TERMINAL BOARD(SPEAKER SURROUND,CENTER)
TM602 1-694-791-11 TERMINAL BOARD (SPEAKER FRONT)
************************************************************
1-680-528-11 POWER SWITCH BOARD
********************
1-533-293-11 FUSE HOLDER
< CONNECTOR >
* CN104 1-564-519-11 PLUG, CONNECTOR 4P
< RESISTOR >
R132 1-249-433-11 CARBON 22K 5% 1/4W
R133 1-249-437-11 CARBON 47K 5% 1/4W
< SWITCH >
S136 1-762-875-21 SWITCH, TACTILE (DISPLAY)
S137 1-762-875-21 SWITCH, TACTILE (DIMMER)
S138 1-762-875-21 SWITCH, TACTILE (?/1)
S139 1-762-875-21 SWITCH, TACTILE (SPEAKER)
************************************************************
MAIN POWER SWITCH
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
