Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
43
STR-DE675
A-4475-803-A STBY BOARD, COMPLETE (US,CND)
*********************
A-4475-887-A STBY BOARD, COMPLETE (AEP,UK,MY,SP)
*********************
A-4475-947-A STBY BOARD, COMPLETE (AUS)
*********************
A-4475-946-A STBY BOARD, COMPLETE (CH)
*********************
A-4475-881-A STBY BOARD, COMPLETE (E)
********************
A-4476-951-A STBY BOARD, COMPLETE (MX)
********************
A-4476-954-A STBY BOARD, COMPLETE (AR)
********************
A-4476-944-A STBY BOARD, COMPLETE (KR)
********************
A-4475-942-A STBY BOARD, COMPLETE (TW)
********************
< CAPACITOR >
C813 1-164-159-11 CERAMIC 0.1uF 50V
C814 1-164-159-11 CERAMIC 0.1uF 50V
C815 1-126-943-11 ELECT 2200uF 20.00% 25V
C816 1-126-941-11 ELECT 470uF 20.00% 25V
C898 1-126-949-11 ELECT 220uF 20.00% 35V
C899 1-126-948-11 ELECT 100uF 20.00% 35V
(EXCEPT TW)
C920 1-164-159-11 CERAMIC 0.1uF 50V
C921 1-164-159-11 CERAMIC 0.1uF 50V
C950 1-126-936-11 ELECT 3300uF 20.00% 16V
< CONNECTOR >
CNP901 1-564-321-00 PIN, CONNECTOR 2P
* CNP902 1-565-792-11 PIN, CONNECTOR 2P
CNP903 1-564-506-11 PLUG, CONNECTOR 3P
CNP905 1-766-203-11 PLUG,CONNECTOR PIN(PC BOARD)5P
CNP912 1-784-921-11 PIN, CONNECTOR 4P
< DIODE >
D820 8-719-024-99 DIODE 11ES2-NTA2B
D821 8-719-024-99 DIODE 11ES2-NTA2B
D822 8-719-024-99 DIODE 11ES2-NTA2B
D823 8-719-024-99 DIODE 11ES2-NTA2B
D898 8-719-024-99 DIODE 11ES2-NTA2B
D899 8-719-024-99 DIODE 11ES2-NTA2B
D901 8-719-911-19 DIODE 1SS133T-72
D910 8-719-024-99 DIODE 11ES2-NTA2B
D911 8-719-024-99 DIODE 11ES2-NTA2B
D912 8-719-024-99 DIODE 11ES2-NTA2B
D913 8-719-024-99 DIODE 11ES2-NTA2B
D914 8-719-911-19 DIODE 1SS133T-72
D915 8-719-911-19 DIODE 1SS133T-72
< FUSE >
0F901 1-576-193-11 FUSE (6.3A/125V) (US,CND,TW,MX)
0F901 1-533-464-11 FUSE, TIME-LUG (T2.5AL/250V)
(EXCEPT US,CND,TW,MX)
0F902 1-532-464-31 FUSE, TIME-LUG (T2.5AL/250V)
(AEP,UK,MY,SP,AR,AUS)
< EARTH >
* G901 1-537-738-21 TERMINAL, EARTH (US,CND)
< JACK >
0J911 1-785-834-11 OUTLET (1P)(AC OUTLET)(EXCEPT KR,AUS)
0J911 1-251-417-11 OUTLET, A.C. (AC OUTLET) (AUS)
< TRANSISTOR >
Q901 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
< RESISTOR >
0R810 1-240-877-11 FUSIBLE 0.15 5% 1/2W
0R811 1-240-877-11 FUSIBLE 0.15 5% 1/2W
0R812 1-240-877-11 FUSIBLE 0.15 5% 1/2W
0R901 1-202-725-00 SOLID 3.3M 10% 1/2W
(US,CND)
R902 1-249-437-11 CARBON 47K 5% 1/4W
R903 1-249-425-11 CARBON 4.7K 5% 1/4W F
0R904 1-249-381-11 CARBON 1 5% 1/4W F
< RELAY >
0RY901 1-755-298-11 RELAY
< TRANSFORMER >
0T902 1-435-436-11 TRANSFORMER, POWER (US,CND,MX)
0T902 1-435-435-11 TRANSFORMER, POWER
(AEP,UK,MY,SP,KR,AR,CH,AUS)
0T902 1-435-563-11 TRANSFORMER, POWER (TW)
0T902 1-435-283-11 TRANSFORMER, POWER (E)
************************************************************
1-680-538-11 S-VIDEO BOARD
*************
< CAPACITOR >
C1801 1-163-038-11 CERAMIC CHIP 0.1uF 25V
(US,CND,MX)
C1802 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C1803 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C1804 1-126-964-11 ELECT 10uF 20.00% 50V
C1805 1-126-964-11 ELECT 10uF 20.00% 50V
C1806 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C1807 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C1808 1-126-960-11 ELECT 1uF 20.00% 50V
C1809 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C1810 1-126-960-11 ELECT 1uF 20.00% 50V
C1811 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C1812 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C1813 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C1814 1-126-960-11 ELECT 1uF 20.00% 50V
C1815 1-163-038-11 CERAMIC CHIP 0.1uF 25V
(US,CND,MX)
C1816 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C1817 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C1818 1-162-971-11 CERAMIC CHIP 0.001uF 10.00% 50V
C1819 1-162-971-11 CERAMIC CHIP 0.001uF 10.00% 50V
< CONNECTOR >
CNS59 1-568-442-11 SOCKET, CONNECTOR 9P
STBY S-VIDEO
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
