Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
44
STR-DE675
< DIODE >
D1801 8-719-070-30 DIODE PTZ-TE25-5.6A
D1802 8-719-016-74 DIODE 1SS352-TPH3
D1803 8-719-016-74 DIODE 1SS352-TPH3
< IC >
IC1801 8-759-333-84 IC NJM2279D
IC1802 8-759-333-84 IC NJM2279D
< JACK >
J1801 1-563-330-11 JACK (CTRL A1 II)(US,CND,MX)
J1802 1-764-676-11 CONNECTOR (ROUND TYPE)
(TV/SAT IN,DVD/LD IN)
J1803 1-764-676-11 CONNECTOR (ROUND TYPE)
(VIDEO1 IN,VIDEO1 OUT)
J1804 1-537-943-11 TERMINAL, S (MONITOR OUT)
< JUMPER RESISTOR >
JR1804 1-216-295-11 SHORT 0
JR1805 1-216-295-11 SHORT 0
JR1806 1-216-295-11 SHORT 0
JR1807 1-216-295-11 SHORT 0
JR1808 1-216-295-11 SHORT 0
JR1810 1-216-295-11 SHORT 0
< RESISTOR >
R1801 1-216-022-00 METAL CHIP 75 5% 1/10W
R1802 1-216-022-00 METAL CHIP 75 5% 1/10W
R1803 1-216-022-00 METAL CHIP 75 5% 1/10W
R1804 1-216-022-00 METAL CHIP 75 5% 1/10W
R1805 1-216-022-00 METAL CHIP 75 5% 1/10W
R1806 1-216-022-00 METAL CHIP 75 5% 1/10W
R1807 1-216-022-00 METAL CHIP 75 5% 1/10W
R1808 1-216-022-00 METAL CHIP 75 5% 1/10W
R1809 1-216-022-00 METAL CHIP 75 5% 1/10W
R1810 1-216-022-00 METAL CHIP 75 5% 1/10W
************************************************************
1-680-533-11 VIDEO BOARD
***********
< CAPACITOR >
C200 1-128-805-11 CERAMIC 47PF 5% 50V
C201 1-128-805-11 CERAMIC 47PF 5% 50V
C206 1-126-960-11 ELECT 1uF 20.00% 50V
C207 1-126-960-11 ELECT 1uF 20.00% 50V
C208 1-126-960-11 ELECT 1uF 20.00% 50V
C209 1-126-960-11 ELECT 1uF 20.00% 50V
C210 1-126-964-11 ELECT 10uF 20.00% 50V
C213 1-126-964-11 ELECT 10uF 20.00% 50V
C214 1-164-159-11 CERAMIC 0.1uF 50V
C215 1-164-159-11 CERAMIC 0.1uF 50V
C248 1-128-825-11 CERAMIC 2200PF 5% 50V
C249 1-128-825-11 CERAMIC 2200PF 5% 50V
< CONNECTOR >
CNS150 1-568-439-11 SOCKET, CONNECTOR 7P
CNS151 1-569-315-11 SOCKET, CONNECTOR 5P
CNS152 1-568-442-11 SOCKET, CONNECTOR 9P
< DIODE >
D203 8-719-911-19 DIODE 1SS133T-72
D204 8-719-911-19 DIODE 1SS133T-72
< IC >
IC103 8-759-529-20 IC NJM2296D
< JACK >
J201 1-770-337-11 JACK, PIN 3P (VIDEO2 IN,DVD/LD IN,TV/SAT,IN)
J202 1-770-337-11 JACK, PIN 3P (MONITOR OUT,VIDEO1 IN,
VIDEO1 OUT)
< RESISTOR >
R200 1-247-804-11 CARBON 75 5% 1/4W
R201 1-247-804-11 CARBON 75 5% 1/4W
R218 1-247-804-11 CARBON 75 5% 1/4W
R219 1-247-804-11 CARBON 75 5% 1/4W
R220 1-247-804-11 CARBON 75 5% 1/4W
R221 1-247-804-11 CARBON 75 5% 1/4W
************************************************************
MISCELLANEOUS
**************
7 1-773-250-11 WIRE (FLAT TYPE) (27 CORE)
55 1-769-844-11 WIRE (FLAT TYPE) (5 CORE)
57 1-765-314-11 WIRE (FLAT TYPE) (7 CORE)
59 1-693-539-11 TUNER (US,CND,E,TW,MX,AR)
59 1-693-540-11 TUNER (AEP,UK,MY,SP,KR,AUS,CH)
60 1-773-004-11 WIRE (FLAT TYPE) (15 CORE)
61 1-769-905-11 WIRE (FLAT TYPE) (9 CORE)
068 1-696-847-11 CORD, POWER (AUS)
068 1-769-079-21 CORD, POWER (KR
068 1-777-071-21 CORD, POWER (AEP,UK,E,MY,SP,TW,AR)
068 1-783-205-11 CORD, POWER (CH)
068 1-783-820-11 CORD, POWER (US,CND,MX)
0T901 1-435-897-11 POWER TRANSFORMER (US)
0T901 1-435-898-11 POWER TRANSFORMER (CND)
0T901 1-435-899-11 POWER TRANSFORMER (TW)
0T901 1-435-900-11 POWER TRANSFORMER (KR,AR)
0T901 1-435-901-11 POWER TRANSFORMER (E)
0T901 1-435-902-11 POWER TRANSFORMER (AUS)
0T901 1-435-903-11 POWER TRANSFORMER (AEP,UK,MY,SP,CH)
FL101 1-518-718-11 INDICATOR TUBE, FLUORESCENT
S-VIDEO VIDEO
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
