Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 72 —
A-4419-398-A DISPLAY BOARD, COMPLETE (DE835:AUS)
***********************
A-4419-402-A DISPLAY BOARD, COMPLETE (DE835:E,PX)
***********************
A-4419-397-A DISPLAY BOARD, COMPLETE
(DE835:SP,MY/V828)
***********************
A-4419-396-A DISPLAY BOARD, COMPLETE (DE835:US,CND)
***********************
A-4419-403-A DISPLAY BOARD, COMPLETE (DE935)
***********************
A-4419-961-A DISPLAY BOARD, COMPLETE (SE591)
***********************
* 4-921-941-01 CUSHION (FL)
* 4-990-797-01 HOLDER (FL)
< CAPACITOR >
C101 1-126-786-11 ELECT 47uF 20% 16V
C102 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C103 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C104 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C105 1-104-905-11 CAPACITOR 0.22F 5.5V
C106 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C107 1-126-786-11 ELECT 47uF 20% 16V
C108 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C109 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C110 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C111 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C113 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C114 1-126-795-11 ELECT 10uF 20% 50V
C115 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C116 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C117 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C118 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C119 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C120 1-126-786-11 ELECT 47uF 20% 16V
C121 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C122 1-165-319-11 CERAMIC CHIP 0.1uF 50V
CC11 1-165-319-11 CERAMIC CHIP 0.1uF 50V
(DE935)
CC13 1-165-319-11 CERAMIC CHIP 0.1uF 50V
(DE935)
CC14 1-104-942-11 ELECT 1uF 20% 50V
(DE935)
CC15 1-104-942-11 ELECT 1uF 20% 50V
(DE935)
CC16 1-126-916-11 ELECT 1000uF 20% 6.3V
(DE935)
< CONNECTOR >
CNN1 1-564-718-11 PIN, CONNECTOR (SMALL TYPE) 2P
(DE835:US,CND/SE591)
CNP104 1-784-919-11 CONNECTOR, PC BOARD (PLUG) 5P
* CNP105 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
CNP106 1-784-919-11 CONNECTOR, PC BOARD (PLUG) 5P
CNP110 1-785-821-11 CONNECTOR, BOARD TO BOARD 6P
CNP111 1-785-821-11 CONNECTOR, BOARD TO BOARD 6P
CNS101 1-568-741-11 SOCKET, CONNECTOR 23P
(DE835:US,CND/DE935/SE591)
CNS101 1-569-308-11 SOCKET, CONNECTOR (L TYRE) 19P
(DE835:E,PX,SP,MY,AUS/V828)
CNS103 1-770-397-11 HOUSING, CONNECTOR(PC BOARD)4P
< DIODE >
D102 8-719-053-18 DIODE 1SR154-400TE-25
D103 8-719-016-74 DIODE 1SS352-TPH3
D104 8-719-075-59 DIODE SELS5B23CTP15
D105 8-719-313-45 DIODE SEL6810A-TH10 (EQUALIZER)
D106 8-719-313-45 DIODE SEL6810A-TH10 (BASS BOOST)
D107 8-719-016-74 DIODE 1SS352-TPH3
D109 8-719-016-74 DIODE 1SS352-TPH3 (DE935)
D112 8-719-016-74 DIODE 1SS352-TPH3 (SE591)
D115 8-719-016-74 DIODE 1SS352-TPH3 (DE835:AUS)
D116 8-719-016-74 DIODE 1SS352-TPH3 (DE835:SP,MY/V828)
D118 8-719-016-74 DIODE 1SS352-TPH3 (DE835:SP,MY/V828)
D180 8-719-016-74 DIODE 1SS352-TPH3
< DIODE >
DD11 8-719-016-74 DIODE 1SS352-TPH3 (DE935)
DD12 8-719-016-74 DIODE 1SS352-TPH3 (DE935)
DD13 8-719-016-74 DIODE 1SS352-TPH3 (DE935)
DD14 8-719-064-57 DIODE SID5K23CTP15 (DE935)
DD15 8-719-059-14 DIODE SID313BP-TP19 (DE935)
DD16 8-719-059-14 DIODE SID313BP-TP19 (DE935)
< FILTER >
FL101 1-517-781-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC11 8-759-925-76 IC SN74HC08ANSR (DE935)
IC12 8-759-545-07 IC TMP87C447U-4A06 (DE935)
IC101 8-759-459-85 IC NJL63H400A
IC102 8-759-577-32 IC MB90553APF-G-138-BND
IC103 8-759-075-35 IC TD62C950RF
IC104 8-759-389-51 IC MSC1164GS-KR1
IC105 8-759-589-67 IC BA6208F-E2
< COIL >
L150 1-408-982-11 INDUCTOR 100uH (DE935)
< TRANSISTOR >
Q101 8-729-216-22 TRANSISTOR 2SA1162-YG-TE85L
Q102 8-729-027-23 TRANSISTOR RT1P141C-TP-1
Q108 8-729-027-43 TRANSISTOR RT1N141C-TP-1
Q109 8-729-230-49 TRANSISTOR 2SC2712-YG-TE85L
QQ1 8-729-216-22 TRANSISTOR 2SA1162-YG-TE85L
(DE835:US,CND/DE835:US,CND/SE591)
QQ11 8-729-230-49 TRANSISTOR 2SC2712-YG-TE85L (DE935)
QQ13 8-729-801-93 TRANSISTOR 2SD1387-34-TP (DE935)
QQ14 8-729-801-93 TRANSISTOR 2SD1387-34-TP (DE935)
< RESISTOR >
R101 1-216-049-91 RES,CHIP 1K 5% 1/10W
R102 1-216-049-91 RES,CHIP 1K 5% 1/10W
R103 1-216-049-91 RES,CHIP 1K 5% 1/10W
R104 1-216-037-00 METAL CHIP 330 5% 1/10W
R105 1-216-049-91 RES,CHIP 1K 5% 1/10W
R106 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R107 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R108 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R109 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R110 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
DISPLAY
