Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 73 —
R111 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R112 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R113 1-216-073-00 METAL CHIP 10K 5% 1/10W
R114 1-216-073-00 METAL CHIP 10K 5% 1/10W
R115 1-216-117-00 METAL CHIP 680K 5% 1/10W
R116 1-216-049-91 RES,CHIP 1K 5% 1/10W
R117 1-216-049-91 RES,CHIP 1K 5% 1/10W
R118 1-216-049-91 RES,CHIP 1K 5% 1/10W
R119 1-216-049-91 RES,CHIP 1K 5% 1/10W
R120 1-216-049-91 RES,CHIP 1K 5% 1/10W
R121 1-216-081-00 METAL CHIP 22K 5% 1/10W
R122 1-216-081-00 METAL CHIP 22K 5% 1/10W
R123 1-216-001-00 METAL CHIP 10 5% 1/10W
R124 1-216-073-00 METAL CHIP 10K 5% 1/10W
R125 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R126 1-216-073-00 METAL CHIP 10K 5% 1/10W
R127 1-216-037-00 METAL CHIP 330 5% 1/10W
R129 1-216-025-91 RES,CHIP 100 5% 1/10W
R130 1-216-097-91 RES,CHIP 100K 5% 1/10W
R137 1-216-073-00 METAL CHIP 10K 5% 1/10W
R138 1-216-049-91 RES,CHIP 1K 5% 1/10W
R141 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R143 1-216-073-00 METAL CHIP 10K 5% 1/10W
R144 1-216-001-00 METAL CHIP 10 5% 1/10W
R145 1-216-089-91 RES,CHIP 47K 5% 1/10W
R146 1-216-081-00 METAL CHIP 22K 5% 1/10W
R147 1-216-089-91 RES,CHIP 47K 5% 1/10W
R148 1-249-385-11 CARBON 2.2 5% 1/6W F
R149 1-249-385-11 CARBON 2.2 5% 1/6W F
R189 1-216-049-91 RES,CHIP 1K 5% 1/10W
(DE935)
R190 1-216-097-91 RES,CHIP 100K 5% 1/10W
R191 1-216-097-91 RES,CHIP 100K 5% 1/10W
R192 1-216-097-91 RES,CHIP 100K 5% 1/10W
R193 1-216-049-91 RES,CHIP 1K 5% 1/10W
R194 1-216-049-91 RES,CHIP 1K 5% 1/10W
RR1 1-216-073-00 METAL CHIP 10K 5% 1/10W
(DE835:US,CND/SE591)
RR11 1-216-025-91 RES,CHIP 100 5% 1/10W
(DE835:US,CND/DE935/SE591)
RR12 1-216-025-91 RES,CHIP 100 5% 1/10W
(DE835:US,CND/DE935/SE591)
RR13 1-216-025-91 RES,CHIP 100 5% 1/10W
(DE835:US,CND/DE935/SE591)
RR14 1-216-025-91 RES,CHIP 100 5% 1/10W
(DE835:US,CND/DE935/SE591)
RR15 1-216-073-00 METAL CHIP 10K 5% 1/10W
(DE935)
RR16 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
(DE935)
RR17 1-216-073-00 METAL CHIP 10K 5% 1/10W
(DE935)
RR18 1-216-073-00 METAL CHIP 10K 5% 1/10W
(DE935)
RR19 1-216-309-00 METAL CHIP 5.6 5% 1/10W
(DE935)
RR20 1-216-309-00 METAL CHIP 5.6 5% 1/10W
(DE935)
RR21 1-216-298-00 METAL CHIP 2.2 5% 1/10W
(DE935)
RR22 1-216-298-00 METAL CHIP 2.2 5% 1/10W
(DE935)
RR23 1-216-097-91 RES,CHIP 100K 5% 1/10W
(DE935)
RR24 1-216-089-91 RES,CHIP 47K 5% 1/10W
RR25 1-216-089-91 RES,CHIP 47K 5% 1/10W
RR26 1-216-089-91 RES,CHIP 47K 5% 1/10W
RR27 1-216-089-91 RES,CHIP 47K 5% 1/10W
RR28 1-216-089-91 RES,CHIP 47K 5% 1/10W
RR29 1-216-001-00 METAL CHIP 10 5% 1/10W
(DE935)
RR30 1-216-001-00 METAL CHIP 10 5% 1/10W
(DE935)
RR51 1-216-029-00 METAL CHIP 150 5% 1/10W
RR52 1-216-029-00 METAL CHIP 150 5% 1/10W
RR53 1-216-029-00 METAL CHIP 150 5% 1/10W
RR54 1-216-037-00 METAL CHIP 330 5% 1/10W
RR55 1-216-037-00 METAL CHIP 330 5% 1/10W
RR56 1-216-037-00 METAL CHIP 330 5% 1/10W
< SWITCH >
S148 1-771-349-21 SWITCH, KEYBOARD (DISPLAY)
(DE835:US,CND/DE935,E,PX,AUS/V828)
S149 1-771-349-21 SWITCH, KEYBOARD (DIMMER)
(DE835:US,CND/DE935,E,PX,AUS/V828)
< VIBRATOR >
X11 1-767-938-21 VIBRATOR, CERAMIC 7.28MHz (DE935)
X101 1-781-356-21 VIBRATOR, CERAMIC 16MHz
(DE935/DE835/V828)
************************************************************
1-673-351-11 F-VIDEO BOARD (DE935)
*************
< CAPACITOR >
C299 1-165-319-11 CERAMIC CHIP 0.1uF 50V
CC40 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
CC90 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
CNP307 1-564-721-11 PIN, CONNECTOR (SMALL TYPE) 5P
< DIODE >
D120 8-719-016-74 DIODE 1SS352-TPH3
D121 8-719-016-74 DIODE 1SS352-TPH3
< EARTH >
* EB201 1-537-738-21 TERMINAL, EARTH
< JACK >
J299 1-770-571-11 JACK BLOCK, PIN (L TYPE) 3P (VIDEO3 INPUT)
< RESISTOR >
R321 1-216-049-91 RES,CHIP 1K 5% 1/10W
R371 1-216-049-91 RES,CHIP 1K 5% 1/10W
************************************************************
DISPLAY F-VIDEO
