Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 79 —
< RELAY >
RY301 1-515-793-11 RELAY (DE935)
RY501 1-515-920-11 RELAY (24V)
RY502 1-515-920-11 RELAY (24V)
RY601 1-515-920-11 RELAY (24V)
RY602 1-515-793-11 RELAY
RY681 1-515-793-11 RELAY
************************************************************
* 1-673-346-11 MUTING BOARD
*************
< LED >
D101 8-719-313-45 LED SEL6810A-TH10 (MUTING)
< RESISTOR >
R134 1-216-041-00 METAL CHIP 470 5% 1/10W
R135 1-216-045-00 METAL CHIP 680 5% 1/10W
R136 1-216-049-91 RES,CHIP 1K 5% 1/10W
< SWITCH >
S145 1-771-349-21 SWITCH, KEYBOARD (EQUALIZER)
(EXCEPT DE835:SP,MY/V828)
S146 1-771-349-21 SWITCH, KEYBOARD (BASS BOOST)
(EXCEPT DE835:SP,MY/V828)
S147 1-771-349-21 SWITCH, KEYBOARD (MUTING)
(EXCEPT DE835:SP,MY/V828)
************************************************************
* A-4419-391-A REAR-AMP BOARD, COMPLETE
*************************
< CAPACITOR >
C701 1-128-858-11 ELECT 22uF 20% 50V
C702 1-128-811-11 CERAMIC 150PF 5% 50V
C703 1-102-233-00 CERAMIC 33PF 10% 500V
C704 1-107-586-11 CERAMIC 6PF 0.5PF 500V
C705 1-128-832-11 ELECT 220uF 20% 10V
C706 1-106-351-00 MYLAR 2200PF 5% 200V
C707 1-106-351-00 MYLAR 2200PF 5% 200V
C708 1-109-876-11 FILM 0.033uF 10% 250V
C720 1-104-664-11 ELECT 47uF 20% 16V
C721 1-107-597-11 CERAMIC 22PF 10% 500V
C722 1-107-597-11 CERAMIC 22PF 10% 500V
C723 1-162-286-31 CERAMIC 220PF 10% 50V
C724 1-119-824-11 ELECT MELF 10uF 20% 50V
C725 1-136-157-00 FILM 0.022uF 5% 50V
C726 1-136-153-00 FILM 0.01uF 5% 50V
C739 1-162-288-31 CERAMIC 330PF 10% 50V
C749 1-102-934-00 CERAMIC 1.0PF +-0.25PF 50V
C751 1-128-858-11 ELECT 22uF 20% 50V
C752 1-128-811-11 CERAMIC 150PF 5% 50V
C753 1-102-233-00 CERAMIC 33PF 10% 500V
C754 1-107-586-11 CERAMIC 6PF 0.5PF 500V
C755 1-128-832-11 ELECT 220uF 20% 10V
C756 1-106-351-00 MYLAR 2200PF 5% 200V
C757 1-106-351-00 MYLAR 2200PF 5% 200V
C758 1-109-876-11 FILM 0.033uF 10% 250V
C770 1-104-664-11 ELECT 47uF 20% 16V
C771 1-107-597-11 CERAMIC 22PF 10% 500V
C772 1-107-597-11 CERAMIC 22PF 10% 500V
C773 1-162-286-31 CERAMIC 220PF 10% 50V
C775 1-136-157-00 FILM 0.022uF 5% 50V
C779 1-102-934-00 CERAMIC 1.0PF +-0.25PF 50V
C780 1-128-809-11 CERAMIC 100PF 5% 50V
C789 1-162-288-31 CERAMIC 330PF 10% 50V
C798 1-128-883-11 ELECT 22uF 20% 100V
C799 1-128-883-11 ELECT 22uF 20% 100V
< CONNECTOR >
CNP701 1-785-102-11 PIN, CONNECTOR 4P
CNP711 1-784-923-11 PIN, CONNECTOR 7P
CNP712 1-785-102-21 PIN, CONNECTOR 4P
CNP713 1-784-924-11 PIN, CONNECTOR 8P
< DIODE >
D701 8-719-911-19 DIODE 1SS133T-72
D702 8-719-109-51 DIODE MTZJ-T-72-2.2
D703 8-719-109-51 DIODE MTZJ-T-72-2.2
D704 8-719-911-19 DIODE 1SS133T-72
D705 8-719-911-19 DIODE 1SS133T-72
D706 8-719-911-19 DIODE 1SS133T-72
D749 8-719-911-19 DIODE 1SS133T-72
D751 8-719-911-19 DIODE 1SS133T-72
D752 8-719-109-51 DIODE MTZJ-T-72-2.2
D753 8-719-109-51 DIODE MTZJ-T-72-2.2
D754 8-719-911-19 DIODE 1SS133T-72
D798 8-719-911-19 DIODE 1SS133T-72
D799 8-719-911-19 DIODE 1SS133T-72
< IC >
IC701 8-759-326-52 IC uPC2581V
< TRANSISTOR >
Q704 8-729-119-76 TRANSISTOR 2SA1115TP-EF
Q705 8-729-026-08 TRANSISTOR 2SC4495
Q706 8-749-010-25 TRANSISTOR MN2488-OPY-M
Q707 8-749-010-26 TRANSISTOR MP1620-OPY-M
Q708 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q709 8-729-281-53 TRANSISTOR 2SC1815GR-TPE2
Q710 8-729-900-63 TRANSISTOR BN1F4M-TP
Q754 8-729-119-76 TRANSISTOR 2SA1115TP-EF
Q755 8-729-026-08 TRANSISTOR 2SC4495
Q756 8-749-010-25 TRANSISTOR MN2488-OPY-M
Q757 8-749-010-26 TRANSISTOR MP1620-OPY-M
Q758 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q798 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q799 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
< RESISTOR >
R701 1-249-417-11 CARBON 1K 5% 1/4W F
R702 1-247-881-00 CARBON 120K 5% 1/4W
R703 1-249-439-11 CARBON 68K 5% 1/4W
R704 1-249-418-11 CARBON 1.2K 5% 1/4W F
R705 1-247-807-31 CARBON 100 5% 1/4W
