Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 80 —
R712 1-249-439-11 CARBON 68K 5% 1/4W
R720 1-249-429-11 CARBON 10K 5% 1/4W
R721 1-249-422-11 CARBON 2.7K 5% 1/4W F
R722 1-249-433-11 CARBON 22K 5% 1/4W
R723 1-249-442-11 CARBON 510 5% 1/4W
! R724 1-249-408-11 CARBON 180 5% 1/4W F
! R725 1-249-408-11 CARBON 180 5% 1/4W F
! R726 1-234-182-11 ENCAPSULATED COMPONENT
R727 1-240-855-91 CARBON 6.2K 5% 1/4W
R728 1-249-425-11 CARBON 4.7K 5% 1/4W F
R729 1-247-866-11 CARBON 30K 5% 1/4W
R730 1-249-421-11 CARBON 2.2K 5% 1/4W F
R731 1-249-433-11 CARBON 22K 5% 1/4W
R732 1-249-437-11 CARBON 47K 5% 1/4W
! R733 1-249-393-11 CARBON 10 5% 1/4W F
R735 1-249-431-11 CARBON 15K 5% 1/4W
! R749 1-249-393-11 CARBON 10 5% 1/4W F
R751 1-249-417-11 CARBON 1K 5% 1/4W F
R752 1-247-881-00 CARBON 120K 5% 1/4W
R753 1-249-439-11 CARBON 68K 5% 1/4W
R754 1-249-418-11 CARBON 1.2K 5% 1/4W F
R755 1-247-807-31 CARBON 100 5% 1/4W
R762 1-249-439-11 CARBON 68K 5% 1/4W
R770 1-249-429-11 CARBON 10K 5% 1/4W
R771 1-249-422-11 CARBON 2.7K 5% 1/4W F
R772 1-249-433-11 CARBON 22K 5% 1/4W
R773 1-249-442-11 CARBON 510 5% 1/4W
! R774 1-249-408-11 CARBON 180 5% 1/4W F
! R775 1-249-408-11 CARBON 180 5% 1/4W F
! R776 1-234-182-11 ENCAPSULATED COMPONENT
R777 1-240-855-91 CARBON 6.2K 5% 1/4W
R778 1-249-425-11 CARBON 4.7K 5% 1/4W F
R782 1-249-437-11 CARBON 47K 5% 1/4W
! R783 1-249-393-11 CARBON 10 5% 1/4W F
R790 1-249-433-11 CARBON 22K 5% 1/4W
R795 1-249-419-11 CARBON 1.5K 5% 1/4W F
R796 1-249-431-11 CARBON 15K 5% 1/4W
R798 1-249-419-11 CARBON 1.5K 5% 1/4W F
R799 1-249-431-11 CARBON 15K 5% 1/4W
< RELAY >
RY701 1-515-920-11 RELAY (24V)
< TEST PIN >
* TP701 1-560-060-00 PIN, CONNECTOR 2P
* TP751 1-560-060-00 PIN, CONNECTOR 2P
************************************************************
* 1-673-348-11 ROTARY BOARD
*************
< CONNECTOR >
* CNP155 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
< VARIABLE RESISTOR >
RV101 1-467-808-11 ENCODER, ROTARY (JOG DIAL)
(EXCEPT DE835:SP,MY/SE591)
************************************************************
* 1-673-355-11 SP BOARD
********
< CAPACITOR >
CC41 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
(EXCEPT DE835:SP,MY/V828)
CC42 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
(EXCEPT DE835:SP,MY/V828)
CC43 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
CC47 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
CC97 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
CC251 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
< JACK >
JJ103 1-774-819-11 JACK, PIN 2P (AUDIO OUT,WOOFER)
< COIL >
L601 1-420-872-00 COIL, AIR-CORE
L601 1-411-906-11 COIL, AIR-CORE (EXCEPT DE835:SP,MY/SE591)
L701 1-420-872-00 COIL, AIR-CORE
L701 1-411-906-11 COIL, AIR-CORE (EXCEPT DE835:SP,MY/SE591)
L751 1-420-872-00 COIL, AIR-CORE
L751 1-411-906-11 COIL, AIR-CORE (EXCEPT DE835:SP,MY/SE591)
< RESISTOR >
R634 1-249-389-11 CARBON 4.7 5% 1/4W F
R734 1-249-389-11 CARBON 4.7 5% 1/4W F
R784 1-249-389-11 CARBON 4.7 5% 1/4W F
RR251 1-216-049-91 RES,CHIP 1K 5% 1/10W
< TERMINAL >
* TM501 1-694-454-21 TERMINAL BOARD (SP)(FRONT SPEAKERS)
TM701 1-694-528-11 TERMINAL BOARD (SPEAKER)(6P)
(CENTER,REAR)
************************************************************
* 1-673-347-11 SP-SW BOARD
************
< SWITCH >
S150 1-771-349-21 SWITCH, KEYBOARD (POWER)
(EXCEPT DE835:SP,MY/SE591)
S151 1-762-268-11 SWITCH, ROTARY (SPEAKERS)
(EXCEPT DE835:SP,MY/SE591)
************************************************************
SP-SWSPREAR-AMP ROTARY
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
