Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DH720/DH720HP
72
FB2892 1-400-862-11 BEAD, FERRITE
< IC >
IC2005 6-715-078-01 IC KIA7809AF/API
IC2006 6-716-745-01 IC PCM9211PTR
IC2009 8-759-698-31 IC TC7WH74FK
IC2010 6-712-613-01 IC SI-3010KM-TLS
IC2020 6-702-913-01 IC S-80929CNMC-G8ZT2G
IC2032 6-707-870-01 IC TC74VHC157FT (EKJ)
IC2105 A-1796-475-A IC MB90F058PF-G-JNE1 (for SERVICE)
IC2106 (Not supplied) IC CAT24C64WI-GT3
IC2107 6-705-468-01 IC BA33BC0FP-E2
IC2303 8-759-591-61 IC TC7WHU04FU (TE12R)
IC2351 6-600-466-01 IC TORX147L (SONY)
(DIGITAL (ASSIGNABLE) OPTICAL SAT/CATV IN)
IC2352 6-600-466-01 IC TORX147L (SONY) (TV OPTICAL IN)
IC2421 6-705-337-01 IC TK11150CSCL-G
IC2501 6-711-874-01 IC WM8768GEDS/R
IC2801 6-716-694-01 IC ADSST-AVR-3010
IC2802 A-1818-608-A IC W25Q16BVSSIG (for SERVICE)
IC2803 6-714-889-01 IC MP2301ENE-LF-Z
IC2804 6-707-870-01 IC TC74VHC157FT (EKJ)
IC2805 8-759-523-81 IC TC74VHC08FT (EL)
< JACK >
J2301 1-784-431-11 JACK, PIN 1P
(DIGITAL (ASSIGNABLE) COAXIAL BD/DVD IN)
< COIL >
L2007 1-457-874-11 INDUCTOR 10UH
L2008 1-400-791-21 INDUCTOR 10UH
< TRANSISTOR >
Q2006 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q2702 6-551-696-01 TR ISA1235AC1-T112-1EF
Q2703 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q2704 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q2705 8-729-038-23 TRANSISTOR RT1N141C-TP-1
Q2706 8-729-038-23 TRANSISTOR RT1N141C-TP-1
< RESISTOR >
R2005 1-218-989-11 METAL CHIP 1M 5% 1/16W
R2007 1-218-989-11 METAL CHIP 1M 5% 1/16W
R2011 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2015 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2050 1-208-883-81 METAL CHIP 680 0.5% 1/16W
R2052 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2053 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R2054 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2058 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2059 1-218-941-81 METAL CHIP 100 5% 1/16W
R2099 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2100 1-218-955-11 METAL CHIP 1.5K 5% 1/16W
R2103 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2104 1-218-953-11 METAL CHIP 1K 5% 1/16W
R2108 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2111 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2112 1-218-941-81 METAL CHIP 100 5% 1/16W
R2114 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R2116 1-218-989-11 METAL CHIP 1M 5% 1/16W
C2881 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2882 1-100-669-11 ELECT CHIP 100uF 20% 10V
C2883 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C2884 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C2899 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2905 1-126-210-21 ELECT CHIP 220uF 20% 4V
C2909 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2910 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C2912 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2913 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2917 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2918 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
< CONNECTOR >
CN2002 1-568-830-11 CONNECTOR, FFC 11P (ECE)
CN2003 1-784-770-11 CONNECTOR, FFC 9P (US, CND)
CN2103 1-573-846-11 CONNECTOR, BOARD TO BOARD 14P
CN2105 1-784-040-11 CONNECTOR, BOARD TO BOARD 19P
CN2114 1-784-040-11 CONNECTOR, BOARD TO BOARD 19P
CN2116 1-820-123-41 CONNECTOR, FFC/FPC 25P
CN2501 1-764-250-21 PIN, CONNECTOR (PC BOARD) 4P
CN2513 1-573-852-11 CONNECTOR, BOARD TO BOARD 20P
CN2602 1-784-861-51 CONNECTOR, FFC (LIF (NON-ZIF)) 9P
*
CN2603 1-774-876-21 CONNECTOR, BOARD TO BOARD 8P
< DIODE >
D2003 8-719-049-09 DIODE 1SS367-T3SONY
D2004 8-719-049-09 DIODE 1SS367-T3SONY
D2018 8-719-049-09 DIODE 1SS367-T3SONY
D2019 6-502-961-01 DI DA2J10100L
D2104 6-502-961-01 DI DA2J10100L
D2110 6-502-961-01 DI DA2J10100L
D2302 6-500-335-01 DIODE MC2838-T112-1
D2303 6-500-335-01 DIODE MC2838-T112-1
D2701 8-719-060-48 DIODE RB751V-40TE-17
D2713 6-502-961-01 DI DA2J10100L
D2714 8-719-053-18 DIODE 1SR154-400TE-25
D2717 6-502-961-01 DI DA2J10100L
< FERRITE BEAD >
FB2007 1-400-862-11 BEAD, FERRITE
FB2031 1-216-864-11 SHORT CHIP 0
FB2032 1-216-864-11 SHORT CHIP 0
FB2033 1-400-862-11 BEAD, FERRITE
FB2043 1-400-862-11 BEAD, FERRITE
FB2101 1-400-862-11 BEAD, FERRITE
FB2311 1-400-862-11 BEAD, FERRITE
FB2501 1-400-862-11 BEAD, FERRITE
FB2502 1-400-862-11 BEAD, FERRITE
FB2603 1-469-139-21 FERRITE, EMI (SMD) (2012)
FB2604 1-469-139-21 FERRITE, EMI (SMD) (2012)
FB2608 1-469-139-21 FERRITE, EMI (SMD) (2012)
FB2801 1-400-862-11 BEAD, FERRITE
*
FB2884 1-400-973-21 INDUCTOR (EMI FERRITE)
*
FB2885 1-400-973-21 INDUCTOR (EMI FERRITE)
*
FB2886 1-400-973-21 INDUCTOR (EMI FERRITE)
FB2887 1-400-862-11 BEAD, FERRITE
FB2889 1-400-862-11 BEAD, FERRITE
FB2890 1-400-862-11 BEAD, FERRITE
FB2891 1-400-862-11 BEAD, FERRITE
DIGITAL
Note 1: IC2106 on the DIGITAL board cannot exchange with
single. When this part on the DIGITAL board is damaged,
exchange the entire mounted board.
Note 2: When the DIGITAL board (Suffi x-11) is replaced, refer
to “NOTICE OF BOARD VERSION CHECK” (page 4).
Ver. 1.2
