Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DH720/DH720HP
7575
< IC >
IC101 8-759-710-97 IC NJM4565M-D
IC151 6-600-768-01 IC PNA4823M03S0
IC152 6-701-729-01 IC PT6315
< JACK >
J101 1-819-189-11 PIN JACK 3P (VIDEO 2 IN VIDEO/AUDIO L/R)
< COIL >
L142 1-481-781-21 INDUCTOR 47UH
< FLUORESCENT INDICATOR TUBE >
ND151 1-483-110-11 VACUUM FLOURESCENT DISPLAY
< TRANSISTOR >
Q141 6-550-065-01 TRANSISTOR CPH5504-TL-E
< RESISTOR >
R101 1-216-821-11 METAL CHIP 1K 5% 1/10W
R102 1-216-841-11 METAL CHIP 47K 5% 1/10W
R103 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R108 1-216-821-11 METAL CHIP 1K 5% 1/10W
R111 1-216-821-11 METAL CHIP 1K 5% 1/10W
R112 1-216-841-11 METAL CHIP 47K 5% 1/10W
R113 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R115 1-218-285-11 METAL CHIP 75 5% 1/10W
R141 1-216-809-11 METAL CHIP 100 5% 1/10W
R142 1-216-839-11 METAL CHIP 33K 5% 1/10W
R143 1-216-821-11 METAL CHIP 1K 5% 1/10W
R155 1-249-393-11 CARBON 10 5% 1/4W
R156 1-216-809-11 METAL CHIP 100 5% 1/10W
R159 1-216-809-11 METAL CHIP 100 5% 1/10W
R160 1-216-809-11 METAL CHIP 100 5% 1/10W
R161 1-216-809-11 METAL CHIP 100 5% 1/10W
R162 1-216-844-11 METAL CHIP 82K 5% 1/10W
R164 1-249-381-11 CARBON 1 5% 1/4W
R165 1-249-381-11 CARBON 1 5% 1/4W
R166 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R167 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R168 1-216-821-11 METAL CHIP 1K 5% 1/10W
R169 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R170 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R171 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R172 1-216-833-11 METAL CHIP 10K 5% 1/10W
R173 1-216-837-11 METAL CHIP 22K 5% 1/10W
R174 1-216-841-11 METAL CHIP 47K 5% 1/10W
R176 1-216-837-11 METAL CHIP 22K 5% 1/10W
R177 1-216-833-11 METAL CHIP 10K 5% 1/10W
R196 1-216-837-11 METAL CHIP 22K 5% 1/10W
R197 1-216-833-11 METAL CHIP 10K 5% 1/10W
< SWITCH >
S100 1-771-410-21 SWITCH, TACTILE (MUTING)
S101 1-771-410-21 SWITCH, TACTILE (DIMMER)
S102 1-771-410-21 SWITCH, TACTILE (DISPLAY)
S103 1-771-410-21 SWITCH, TACTILE (MUSIC)
S104 1-771-410-21 SWITCH, TACTILE (MOVIE/HD-D.C.S.)
S105 1-771-410-21 SWITCH, TACTILE (A.F.D.)
S106 1-771-410-21 SWITCH, TACTILE (2CH/A.DIRECT)
S107 1-771-410-21 SWITCH, TACTILE (MEMORY/ENTER)
S108 1-771-410-21 SWITCH, TACTILE (TUNING +)
S109 1-771-410-21 SWITCH, TACTILE (TUNING −)
S110 1-771-410-21 SWITCH, TACTILE (TUNING MODE)
S111 1-771-410-21 SWITCH, TACTILE (INPUT MODE)
< TRANSFORMER >
T141 1-445-778-11 D.C-D.C. CONVERTER TRANSFORMER
************************************************************
9
A-1794-689-A D-VIDEO BOARD, COMPLETE (for SERVICE)
***********************
< CAPACITOR >
C3000 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3004 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3005 1-128-994-21 ELECT CHIP 47uF 20% 10V
C3006 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3007 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C3008 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C3009 1-128-994-21 ELECT CHIP 47uF 20% 10V
C3010 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3011 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3012 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3013 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3014 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3018 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C3019 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3020 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C3021 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C3022 1-128-994-21 ELECT CHIP 47uF 20% 10V
C3023 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C3024 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C3025 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3026 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3027 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C3028 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C3029 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C3030 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C3201 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3202 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3203 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3204 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3206 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3207 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3208 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3209 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3210 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3211 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3212 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3213 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3214 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3221 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3222 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C3224 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3225 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3226 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3241 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3243 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
DISPLAY D-VIDEO
Ver. 1.1
