Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DH720/DH720HP
7777
C3573 1-128-994-21 ELECT CHIP 47uF 20% 10V
C3574 1-165-492-21 ELECT CHIP 100uF 20% 10V
C3575 1-165-492-21 ELECT CHIP 100uF 20% 10V
C3578 1-164-935-11 CERAMIC CHIP 470PF 10% 50V
C3583 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C3584 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3585 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C3590 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C3591 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C3592 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C3593 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C3600 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C3601 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C3602 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C3603 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C3604 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C3605 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C3606 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C3607 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C3608 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C3612 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C3613 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C3614 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C3615 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C3616 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C3617 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C3643 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3646 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
< CONNECTOR >
CN3000 1-784-859-51 CONNECTOR, FFC (LIF (NON-ZIF)) 7P
CN3003 1-764-867-41 CONNECTOR, BOARD TO BOARD 20P
CN3004 1-784-031-41 CONNECTOR, BOARD TO BOARD 8P
CN3007 1-817-097-21 PIN, CONNECTOR (1.5MM) (SMD) 13P
CN3200 1-779-992-11 PIN, CONNECTOR (PWB) 8P
CN3500 1-821-398-31 HDMI CONNECTOR
(HDMI ASSIGNABLE (INPUT ONLY) TV OUT ARC)
CN3501 1-821-398-31 HDMI CONNECTOR
(HDMI ASSIGNABLE (INPUT ONLY) VIDEO 1)
CN3502 1-821-398-31 HDMI CONNECTOR
(HDMI ASSIGNABLE (INPUT ONLY) SAT/CATV)
CN3503 1-821-398-31 HDMI CONNECTOR
(HDMI ASSIGNABLE (INPUT ONLY) GAME)
CN3504 1-821-398-31 HDMI CONNECTOR
(HDMI ASSIGNABLE (INPUT ONLY) BD/DVD)
CN3510 1-778-227-41 CONNECTOR, BOARD TO BOARD 6P
< DIODE >
D3000 8-719-049-09 DIODE 1SS367-T3SONY
D3001 8-719-049-09 DIODE 1SS367-T3SONY
D3003 8-719-049-09 DIODE 1SS367-T3SONY
D3004 8-719-049-09 DIODE 1SS367-T3SONY
D3201 6-502-398-01 DI SA10QA04
D3202 6-502-398-01 DI SA10QA04
D3511 6-502-398-01 DI SA10QA04
D3513 6-502-398-01 DI SA10QA04
D3514 6-502-398-01 DI SA10QA04
D3515 6-502-398-01 DI SA10QA04
D3516 6-502-398-01 DI SA10QA04
< FERRITE BEAD >
FB3000 1-400-862-11 BEAD, FERRITE
FB3001 1-400-862-11 BEAD, FERRITE
FB3002 1-469-139-21 FERRITE, EMI (SMD) (2012)
FB3003 1-469-139-21 FERRITE, EMI (SMD) (2012)
FB3004 1-400-862-11 BEAD, FERRITE
FB3201 1-400-862-11 BEAD, FERRITE
FB3202 1-400-862-11 BEAD, FERRITE
FB3203 1-400-862-11 BEAD, FERRITE
*
FB3206 1-400-973-21 INDUCTOR (EMI FERRITE)
FB3502 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3503 1-414-234-22 INDUCTOR, FERRITE BEAD
*
FB3504 1-400-973-21 INDUCTOR (EMI FERRITE)
FB3505 1-400-862-11 BEAD, FERRITE
FB3510 1-400-862-11 BEAD, FERRITE
FB3514 1-400-862-11 BEAD, FERRITE
FB3516 1-469-139-21 FERRITE, EMI (SMD) (2012)
FB3558 1-469-139-21 FERRITE, EMI (SMD) (2012)
< COIL >
*
FL3501 1-457-685-11 COMMON MODE CHOKE COIL
*
FL3502 1-457-685-11 COMMON MODE CHOKE COIL
< IC >
IC3000 A-1794-690-A IC MB91F627PMC-GE1 (for SERVICE)
IC3001 6-707-870-01 IC TC74VHC157FT (EKJ)
IC3002 6-711-185-01 IC TC74VCX257FT (EL)
IC3003 6-702-913-01 IC S-80929CNMC-G8ZT2G
IC3004 6-707-879-01 IC TC74VHC541FT (EKJ)
IC3005 6-713-362-01 IC MFI341S2164
IC3201 6-714-071-01 IC FLI30502AC
IC3203 6-711-239-01 IC NJM2878F3-18 (TE2)
IC3204 8-759-592-47 IC TC7SZ08FU (TE85R)
IC3205 6-705-673-01 IC TC7PA53FU (TE85L.F)
IC3206 6-707-856-01 IC TC74LCX74FT (EKJ)
IC3207 A-1795-794-A IC W25Q16BVSSIG (for SERVICE)
IC3208 6-712-526-01 IC CAT24C32WI-GT3 (E)
IC3210 6-706-838-01 IC MM1661JHBE
9
IC3500 (Not supplied) IC SII9233ACTU
9
IC3501 (Not supplied) IC SII9134CTU
IC3502 6-709-888-01 IC TC7WHU04FK
IC3515 6-706-838-01 IC MM1661JHBE
IC3516 6-711-116-01 IC NJM2878F3-05 (TE2)
IC3517 6-708-913-01 IC TK73400AU3G0L-C
IC3519 6-714-020-01 IC TK63812AMHGHL-C
IC3521 6-711-116-01 IC NJM2878F3-05 (TE2)
< COIL >
L3501
1-469-525-91 INDUCTOR 10UH
L3502 1-469-525-91 INDUCTOR 10UH
L3505 1-469-525-91 INDUCTOR 10UH
L3506 1-469-525-91 INDUCTOR 10UH
L3507 1-469-525-91 INDUCTOR 10UH
L3508 1-469-525-91 INDUCTOR 10UH
L3509 1-469-525-91 INDUCTOR 10UH
L3510 1-469-525-91 INDUCTOR 10UH
< RESISTOR >
R3000 1-218-933-11 METAL CHIP 22 5% 1/16W
D-VIDEO
Note 1:
IC3500 and IC3501 on the D-VIDEO board cannot exchange
with single. When these parts on the D-VIDEO board
are damaged, exchange the entire mounted board.
Note 2: When the D-VIDEO board (Suffi x-11) is replaced, refer
to “NOTICE OF BOARD VERSION CHECK” (page 4).
Ver. 1.2
