Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DH720/DH720HP
84
R766 1-216-843-11 METAL CHIP 68K 5% 1/10W
R770 1-216-841-11 METAL CHIP 47K 5% 1/10W
R772 1-216-845-11 METAL CHIP 100K 5% 1/10W
R778 1-249-389-11 CARBON 4.7 5% 1/4W
R779 1-249-393-11 CARBON 10 5% 1/4W
R780 1-216-841-11 METAL CHIP 47K 5% 1/10W
R801 1-216-821-11 METAL CHIP 1K 5% 1/10W
R802 1-216-843-11 METAL CHIP 68K 5% 1/10W
R803 1-208-445-41 RES-CHIP 2.2K 2% 1/10W
R804 1-208-826-11 METAL CHIP 68K 0.5% 1/10W
R806 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R807 1-216-844-11 METAL CHIP 82K 5% 1/10W
R808 1-216-818-11 METAL CHIP 560 5% 1/10W
R809 1-249-405-11 CARBON 100 5% 1/4W
R810 1-249-405-11 CARBON 100 5% 1/4W
R811 1-216-214-00 RES-CHIP 4.7K 2% 1/8W
R812 1-240-855-91 CARBON 6.2K 5% 1/4W
R813 1-234-182-11 ENCAPSULATED COMPONENT
R814 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R815 1-216-835-11 METAL CHIP 15K 5% 1/10W
R816 1-216-843-11 METAL CHIP 68K 5% 1/10W
R820 1-216-841-11 METAL CHIP 47K 5% 1/10W
R822 1-216-845-11 METAL CHIP 100K 5% 1/10W
R828 1-249-389-11 CARBON 4.7 5% 1/4W
R829 1-249-393-11 CARBON 10 5% 1/4W
R830 1-216-841-11 METAL CHIP 47K 5% 1/10W
R851 1-216-821-11 METAL CHIP 1K 5% 1/10W
R852 1-216-843-11 METAL CHIP 68K 5% 1/10W
R853 1-208-445-41 RES-CHIP 2.2K 2% 1/10W
R854 1-208-826-11 METAL CHIP 68K 0.5% 1/10W
R856 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R857 1-216-844-11 METAL CHIP 82K 5% 1/10W
R858 1-216-818-11 METAL CHIP 560 5% 1/10W
R859 1-249-405-11 CARBON 100 5% 1/4W
R860 1-249-405-11 CARBON 100 5% 1/4W
R861 1-216-214-00 RES-CHIP 4.7K 2% 1/8W
R862 1-240-855-91 CARBON 6.2K 5% 1/4W
R863 1-234-182-11 ENCAPSULATED COMPONENT
R864 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R865 1-216-835-11 METAL CHIP 15K 5% 1/10W
R866 1-216-843-11 METAL CHIP 68K 5% 1/10W
R870 1-216-841-11 METAL CHIP 47K 5% 1/10W
R872 1-216-845-11 METAL CHIP 100K 5% 1/10W
R878 1-249-389-11 CARBON 4.7 5% 1/4W
R879 1-249-393-11 CARBON 10 5% 1/4W
R880 1-216-841-11 METAL CHIP 47K 5% 1/10W
R920 1-249-399-11 CARBON 33 5% 1/4W
R921 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R925 1-216-841-11 METAL CHIP 47K 5% 1/10W
RR11 1-249-393-11 CARBON 10 5% 1/4W
(ECE)
RR12 1-249-393-11 CARBON 10 5% 1/4W
(ECE)
RR13 1-249-393-11 CARBON 10 5% 1/4W
(ECE)
RR14 1-249-393-11 CARBON 10 5% 1/4W
(ECE)
RR15 1-249-393-11 CARBON 10 5% 1/4W
(ECE)
RR17 1-249-393-11 CARBON 10 5% 1/4W
(ECE)
RR18 1-249-393-11 CARBON 10 5% 1/4W
(ECE)
< RELAY >
RY301 1-755-267-11 RELAY
RY350 1-755-416-12 RELAY
RY355 1-755-416-12 RELAY
RY360 1-755-416-12 RELAY
RY365 1-755-416-12 RELAY
RY375 1-755-416-12 RELAY
RY920 1-755-593-11 RELAY
< TERMINAL BOARD >
TB502 1-694-785-11 TERMINAL BOARD
(SPEAKERS SURROUND BACK/FRONT HIGH)
TB503 1-694-805-11 TERMINAL BOARD
(SPEAKERS SURROUND/CENTER)
TB504 1-780-746-11 TERMINAL BOARD (SP) (4P)
(SPEAKERS FRONT)
************************************************************
POWER KEY BOARD
****************
< CAPACITOR >
C195 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C197 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
< CONNECTOR >
*
CNP180 1-564-508-11 PLUG, CONNECTOR 5P
< ROTARY ENCODER >
EN180 1-418-817-21 ENCODER, ROTARY (TONE)
< RESISTOR >
R181 1-216-833-11 METAL CHIP 10K 5% 1/10W
R182 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R191 1-216-837-11 METAL CHIP 22K 5% 1/10W
R192 1-216-833-11 METAL CHIP 10K 5% 1/10W
< SWITCH >
S180 1-771-410-21 SWITCH, TACTILE (TONE MODE)
S181 1-771-410-21 SWITCH, TACTILE (SPEAKERS)
S183 1-771-410-21 SWITCH, TACTILE (I/
1
)
************************************************************
STANDBY-A VIDEO MT PC BOARD (US, CND)
STANDBY-A VIDEO PC BOARD (ECE)
***********************
7-685-646-71 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C201 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C202 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C203 1-126-947-11 ELECT 47uF 20% 25V
C204 1-126-947-11 ELECT 47uF 20% 25V
C205 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C207 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C208 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C210 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C211 1-126-964-11 ELECT 10uF 20% 50V
MAIN POWER KEY STANDBY-A VIDEO PC
Ver. 1.1
To Next Page
