Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DH720/DH720HP
8787
FB4101 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB4102 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB4161 1-481-218-21 FERRITE, EMI (SMD) (1608)
< IC >
IC4100 6-714-684-01 IC BU81459KV-E2
IC4101 8-759-338-95 IC NJM2903V (TE2)
IC4102 6-717-006-01 IC BD00HC5WEFJ-E2
IC4121 8-759-710-97 IC NJM4565M-D
IC4160 8-759-591-61 IC TC7WHU04FU (TE12R)
IC4161 6-705-468-01 IC BA33BC0FP-E2
< JACK >
J4000 1-819-866-11 CONNECTOR, USB (A) (iPhone/iPod )
J4100 1-822-453-11 SMALL TYPE JACK (3.5MM) (AUTO CAL MIC)
< TRANSISTOR >
Q4121 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q4123 6-551-693-01 TRANSISTOR RT3T11M-TP-1
<RESISTOR>
R4111 1-218-965-11 METAL CHIP 10K 5% 1/16W
R4112 1-218-941-81 METAL CHIP 100 5% 1/16W
R4114 1-218-990-81 SHORT CHIP 0
R4115 1-218-941-81 METAL CHIP 100 5% 1/16W
R4116 1-218-941-81 METAL CHIP 100 5% 1/16W
R4117 1-218-941-81 METAL CHIP 100 5% 1/16W
R4118 1-218-941-81 METAL CHIP 100 5% 1/16W
R4119 1-218-941-81 METAL CHIP 100 5% 1/16W
R4120 1-218-941-81 METAL CHIP 100 5% 1/16W
R4121 1-218-941-81 METAL CHIP 100 5% 1/16W
R4122 1-218-965-11 METAL CHIP 10K 5% 1/16W
R4123 1-218-965-11 METAL CHIP 10K 5% 1/16W
R4124 1-218-965-11 METAL CHIP 10K 5% 1/16W
R4125 1-218-965-11 METAL CHIP 10K 5% 1/16W
R4126 1-218-965-11 METAL CHIP 10K 5% 1/16W
R4127 1-218-965-11 METAL CHIP 10K 5% 1/16W
R4129 1-218-873-11 METAL CHIP 12K 0.5% 1/10W
R4130 1-218-989-11 METAL CHIP 1M 5% 1/16W
R4131 1-218-945-11 METAL CHIP 220 5% 1/16W
R4132 1-218-941-81 METAL CHIP 100 5% 1/16W
R4133 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R4134 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R4135 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R4136 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R4137 1-218-973-11 METAL CHIP 47K 5% 1/16W
R4138 1-218-953-11 METAL CHIP 1K 5% 1/16W
R4139 1-218-973-11 METAL CHIP 47K 5% 1/16W
R4141 1-218-965-11 METAL CHIP 10K 5% 1/16W
R4142 1-218-973-11 METAL CHIP 47K 5% 1/16W
R4143 1-208-702-11 METAL CHIP 6.2K 0.5% 1/16W
R4144 1-218-974-11 METAL CHIP 56K 5% 1/16W
R4145 1-218-963-11 METAL CHIP 6.8K 5% 1/16W
R4146 1-218-953-11 METAL CHIP 1K 5% 1/16W
R4147 1-218-977-11 METAL CHIP 100K 5% 1/16W
R4148 1-218-965-11 METAL CHIP 10K 5% 1/16W
R4149 1-218-965-11 METAL CHIP 10K 5% 1/16W
R4150 1-218-977-11 METAL CHIP 100K 5% 1/16W
R4161 1-218-985-11 METAL CHIP 470K 5% 1/16W
R4162 1-218-947-11 METAL CHIP 330 5% 1/16W
R4163 1-218-949-11 METAL CHIP 470 5% 1/16W
R4164 1-218-973-11 METAL CHIP 47K 5% 1/16W
R4174 1-216-864-11 SHORT CHIP 0
R4175 1-216-864-11 SHORT CHIP 0
R4180 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R4181 1-218-883-11 METAL CHIP 33K 0.5% 1/10W
R4182 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R4183 1-218-868-11 METAL CHIP 7.5K 0.5% 1/10W
R4184 1-245-984-21 RES-CHIP 0.1 1% 1/2W
R4185 1-218-868-11 METAL CHIP 7.5K 0.5% 1/10W
R4186 1-218-965-11 METAL CHIP 10K 5% 1/16W
R4187 1-218-965-11 METAL CHIP 10K 5% 1/16W
R4188 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R4189 1-218-868-11 METAL CHIP 7.5K 0.5% 1/10W
R4190 1-218-873-11 METAL CHIP 12K 0.5% 1/10W
< VIBRATOR >
X4102 1-814-482-11 QUARTZ CRYSTAL UNIT (16.9344MHz)
************************************************************
MISCELLANEOUS
**************
51 1-500-082-11 CLAMP, SLEEVE FERRITE
108 1-828-391-51 WIRE (FLAT TYPE) (25 CORE)
0
152 1-777-071-83 CORD, POWER (ECE)
0
152 1-837-308-11 CORD, POWER-SUPPLY (US, CND)
153 1-693-737-21 TUNER (FM/AM) (ECE)
153 1-693-779-11 TUNER (FM/AM) (US, CND)
154 1-827-731-51 WIRE (FLAT TYPE) (11 CORE) (ECE)
154 1-828-957-51 WIRE (FLAT TYPE) (9 CORE) (US, CND)
0
F901 1-532-465-33 FUSE, T3.15AL 250V (ECE)
0
F901 1-533-311-12 FUSE, GLASS (DIA.5) 8A 125V (US, CND)
Q503 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q504 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q553 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q554 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q603 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q604 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q653 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q654 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q703 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q704 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q753 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q754 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q853 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q854 6-702-391-01 TRANSISTOR MP1620-OPY-MK
0
T901 1-445-652-31 POWER TRANSFORMER (MAIN) (ECE)
0
T901 1-697-117-11 POWER TRANSFORMER (MAIN) (US)
0
T901 1-445-824-21 POWER TRANSFORMER (MAIN) (CND)
************************************************************
ACCESSORIES
************
1-489-345-11 REMOTE COMMANDER (RM-AAU106)
(including BATTERY LID) (US, CND)
1-489-346-11 REMOTE COMMANDER (RM-AAU107)
(including BATTERY LID) (ECE)
1-501-374-12 ANTENNA, LOOP (AM loop antenna (aerial))
1-542-830-11 MEASUREMENT MIC (MONO)
(Optimizer microphone (ECM-AC2))
USB
Note:
If wire (fl at type) is replaced, install it after bending it in the same
form as that before replacement.
Ver. 1.2
