130
US
FLAC:
8 kHz – 192 kHz, 16 bit FLAC
44.1 kHz – 192 kHz, 24 bit FLAC
* Compatibility with all encoding/writing
software, recording devices and recording
media cannot be guaranteed.
Transfer speed
High-speed
Supported USB device
Mass Storage Class
Maximum current
500 mA
NETWORK section
Ethernet LAN
10BASE-T/100BASE-TX
Wireless LAN
Compatible standards:
IEEE 802.11 b/g
Security:
WEP 64 bit, WEP 128 bit, WPA/
WPA2-PSK (AES), WPA/WPA2-
PSK (TKIP)
Radio frequency:
2.4 GHz
Bluetooth section
Communication system
Bluetoot h Specification version 3.0
Output
Bluetoot h Specification Power Class 2
Maximum communication range
Line of sight approx. 10 m
1)
Frequency band
2.4 GHz band (2.4000 GHz –
2.4835 GHz)
Modulation method
FHSS (Freq Hopping Spread Spectrum)
Compatible Bluetooth profiles
2)
A2DP (Advanced Audio Distribution
Profile)
AVRCP 1.3 (Audio Video Remote
Control Profile)
Supported Codecs
3)
SBC
4)
, AAC
Transmission range (A2DP)
20 Hz – 20,000 Hz (Sampling frequency
44.1 kHz)
1)
The actual range will vary depending on factors
such as obstacles between devices, magnetic
fields around a microwave oven, static
electricity, cordless phone, reception
sensitivity, antenna’s performance, operating
system, software application, etc.
2)
Bluetooth standard profiles indicate the purpose
of Bluetooth communication between devices.
3)
Codec: Audio signal compression and
conversion format
4)
Subband Codec
General
Power requirements
Power consumption
240 W
Power consumption (during standby mode)
0.3 W (When “Control for HDMI”,
“Pass Through”, “Network Standby”,
and “Bluetooth Standby” are set to
“Off”, and the receiver in zone 2 is
turned off.)
Dimensions (width/height/depth) (Approx.)
430 mm × 172 mm × 329.4 mm
(17 in × 6 7/8 in × 13 in) including
projecting parts and controls
Mass (Approx.)
10.0 kg (22 lb 1 oz)
Design and specifications are subject to
change without notice.
Area Power
requirements
USA, Canada 120 V AC, 60 Hz
Mexico 127 V AC, 60 Hz
Brazil 127/220 V AC,
60 Hz
