46
STR-K5900P/K9900P
SECTION 6
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-1087-685-A DIGITAL BOARD, COMPLETE (K5900P)
A-1091-819-A DIGITAL BOARD, COMPLETE (K9900P)
***********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C1001 1-126-925-11 ELECT 470uF 20% 10V
C1002 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1004 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C1021 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1022 1-126-925-11 ELECT 470uF 20% 10V
C1031 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1032 1-126-925-11 ELECT 470uF 20% 10V
C1100 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1102 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1103 1-126-947-11 ELECT 47uF 20% 35V
C1107 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1108 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1118 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1119 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1120 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1121 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1122 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1123 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1124 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1126 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C1129 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1130 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1137 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1138 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1139 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1140 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1142 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1149 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C1251 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1252 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1253 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1254 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C1255 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C1299 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1301 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1302 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1303 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1304 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1305 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1306 1-126-947-11 ELECT 47uF 20% 35V
C1308 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1309 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C1310 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C1312 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1313 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1314 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1315 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1351 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1354 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1355 1-104-662-11 ELECT 22uF 20% 25V
C1356 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1357 1-162-905-11 CERAMIC CHIP 1PF 0.25PF 50V
C1358 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1359 1-126-916-11 ELECT 1000uF 20% 6.3V
C1360 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C1361 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1362 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1401 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1402 1-126-947-11 ELECT 47uF 20% 35V
C1403 1-126-964-11 ELECT 10uF 20% 50V
C1404 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1405 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C1406 1-126-963-11 ELECT 4.7uF 20% 50V
C1407 1-126-963-11 ELECT 4.7uF 20% 50V
C1408 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C1409 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1411 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C1413 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C1418 1-126-964-11 ELECT 10uF 20% 50V
C1422 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C1423 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C1428 1-126-964-11 ELECT 10uF 20% 50V
C1432 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C1433 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C1438 1-126-964-11 ELECT 10uF 20% 50V
C1441 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C1442 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C1448 1-126-964-11 ELECT 10uF 20% 50V
C1450 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1451 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C1453 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C1454 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C1457 1-126-964-11 ELECT 10uF 20% 50V
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
When indicating parts by reference
number, please include the board.
DIGITAL
