52
STR-K995
Pin No. Pin Name I/O Description
1 VSYNC O Vertical synchronize signal output for HDMI TX.
2 to 5 QO23 to QO20 — Not used. (Open)
6 IOGND — Ground pin
7IOVCC — Power supply pin (+3.3 V)
8 to 11 QO19 to QO16 — Not used. (Open)
12 CVCC18 — Power supply pin (+1.8 V)
13 CGND — Ground pin
14 to 17 QO15 to QO12 — Not used. (Open)
18 IOGND — Ground pin
19 IOVCC — Power supply pin (+3.3 V)
20 to 23 QO11 to QO8 — Not used. (Open)
24 CVCC18 — Power supply pin (+1.8 V)
25 CGND — Ground pin
26 to 29 QO7 to QO4 — Not used. (Open)
30 IOGND — Ground pin
31 IOVCC — Power supply pin (+3.3 V)
32 to 35 QO3 to QO0 — Not used. (Open)
36 CVCC18 — Power supply pin (+1.8 V)
37 CGND — Ground pin
38 CI2CA — Not used. (Fixed to “L”)
39 CSDA I/O I
2
C two-way data bus with HDMI section.
40 CSCL I I
2
C clock signal input from HDMI controller.
41 DSDA I/O I
2
C two-way data bus with HDMI input select.
42 DSDL I I
2
C clock signal input from HDMI input select.
43 NC — Not used. (Open)
44 PWR5V I HDMI DVD IN, VIDEO 2/BD IN, OUT connector detect signal input
45 CVCC18 — Power supply pin (+1.8 V)
46 PGND — Ground pin
47 PVCC — Power supply pin (+3.3 V)
48 RSVD — Not used. (Open)
49 AVCC — Power supply pin (+3.3 V)
50 RXC– I TMDS clock signal input from HDMI DVD IN, VIDEO 2/BD IN, OUT connector.
51 RXC+ I TMDS clock signal input from HDMI DVD IN, VIDEO 2/BD IN, OUT connector.
52 AGND — Ground pin
53 AVCC — Power supply pin (+3.3 V)
54 RX0– I TMDS data input 0 from HDMI DVD IN, VIDEO 2/BD IN, OUT connector.
55 RX0+ I TMDS data input 0 from HDMI DVD IN, VIDEO 2/BD IN, OUT connector.
56 AGND — Ground pin
57 AVCC — Power supply pin (+3.3 V)
58 RX1– I TMDS data input 1 from HDMI DVD IN, VIDEO 2/BD IN, OUT connector.
59 RX1+ I TMDS data input 1 from HDMI DVD IN, VIDEO 2/BD IN, OUT connector.
60 AGND — Ground pin
61 AVCC — Power supply pin (+3.3 V)
62 RX2– I TMDS data input 2 from HDMI DVD IN, VIDEO 2/BD IN, OUT connector.
63 RX2+ I TMDS data input 2 from HDMI DVD IN, VIDEO 2/BD IN, OUT connector.
64 AGND — Ground pin
65 DGND — Ground pin
66 DVCC18 — Power supply pin (+1.8 V)
HDMI RE BOARD IC3511 SII9011CLU (RX)
