Sony STR-K995 - Rear Panel

6
STR-K995
Rear panel
2
5
6
43
1
DIGITAL
(ASSIGNABLE)
DMPORT
OPTICAL
SAT
IN
DVD
IN
COAXIAL
ANTENNA
VIDEO 2/
BD IN
AM
HDMI
DVD IN
VIDEO 2/BD IN
OUT
SA-CD/CD/CD-R
TV
L
R
OUT IN
IN
SAT
AUDIO IN
VIDEO IN
DVD
AUDIO IN
VIDEO IN
VIDEO 1
AUDIO OUT
VIDEO OUT
VIDEO OUT
AUDIO IN
AUDIO OUT
VIDEO IN
L
R
L
R
L
R
SUB
WOOFER
MONITOR
SAT IN
COMPONENT VIDEO
DVD IN VIDEO 1 IN
Y
P
B /C B
P R /C R
MONITOR OUT
SPEAKERS
FRONT B
FRONT A
LR
R
SURROUND
LL
R
CENTER
A DIGITAL INPUT/OUTPUT section
OPTICAL
IN jack
Connects to a DVD
player, etc. The
COAXIAL jack
provides a better
quality of loud
sound (page 23,
25).
COAXIAL IN
jack
HDMI IN/
OUT jack
a)
Connects to a DVD
player, or a Blu-ray
disc player. The
image and the
sound are output to
a TV or a projector
(page 20).
DMPORT
jack
Connect to a
DIGITAL MEDIA
PORT adapter
(page 60).
B COMPONENT VIDEO INPUT/
OUTPUT section
COMPONENT
VIDEO
INPUT/
OUTPUT
jack
a)
Connects to a DVD
player, TV,
satellite tuner, etc.
You can enjoy high
quality image
(page 22, 23, 25).
Green
(Y)
Blue
(P
B/CB)
Red
(P
R/CR)
C SPEAKERS section
Connects to
speakers (page 17).
Connects to sub
woofer (page 17).
D VIDEO/AUDIO INPUT/OUTPUT
section
AUDIO IN/
OUT jack
Connects the video
and audio jacks of a
VCR, a DVD
player, etc.
(page 22–26).
VIDEO IN/
OUT jack
a)
White (L)
Red (R)
Yellow
