STR-K995
SECTION 6
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• COILS
uH: µH
• CAPACITORS
uF: µF
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
DCAC BOARD
***********
< CAPACITOR >
C2001 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C2002 1-126-160-11 ELECT 1uF 20% 50V
C2003 1-164-373-11 CERAMIC CHIP 0.033uF 25V
C2005 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C2006 1-126-160-11 ELECT 1uF 20% 50V
C2008 1-162-924-11 CERAMIC CHIP 56PF 5% 50V
C2010 1-164-373-11 CERAMIC CHIP 0.033uF 25V
C2011 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C2012 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C2013 1-126-160-11 ELECT 1uF 20% 50V
C2014 1-124-465-00 ELECT 0.47uF 20% 50V
C2018 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C2205 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< DIODE >
D2013 8-719-988-61 DIODE 1SS355TE-17
D2014 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC2000 8-759-710-97 IC NJM4565M-D
< JACK >
J2000 1-820-056-11 SMALL TYPE JACK(AUTO CAL MIC)
< RESISTOR >
R2000 1-216-821-11 METAL CHIP 1K 5% 1/10W
R2001 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2003 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2005 1-216-857-11 METAL CHIP 1M 5% 1/10W
R2006 1-216-821-11 METAL CHIP 1K 5% 1/10W
R2007 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2008 1-216-854-11 METAL CHIP 560K 5% 1/10W
R2010 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2015 1-216-839-11 METAL CHIP 33K 5% 1/10W
R2016 1-216-835-11 METAL CHIP 15K 5% 1/10W
R2017 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R2018 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R2019 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
When indicating parts by reference number,
please include the board name.
DCAC DCDC
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
< TEST PIN >
* TP2000 1-690-880-31 LEAD (WITH CONNECTOR)
************************************************************
DCDC BOARD
***********
HS4100 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C4002 1-128-549-11 ELECT 3300uF 20% 35V
C4003 1-115-814-11 ELECT 0.001F 20% 35V
C4004 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C4005 1-128-950-21 ELECT 1000uF 20% 16V
C4006 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C4007 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C4010 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C4100 1-115-814-11 ELECT 0.001F 20% 35V
C4102 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C4103 1-128-950-21 ELECT 1000uF 20% 16V
< CONNECTOR >
CN4101 1-779-977-11 PIN, CONNECTOR 6P
< DIODE >
D4001 8-719-081-52 DIODE D5SBA20-4003
D4803 8-719-080-53 DIODE RK36LF-B3
D4804 8-719-080-53 DIODE RK36LF-B3
< FUSE HOLDER >
FH4001 1-533-313-11 FUSE HOLDER 0A 0V
FH4002 1-533-313-11 FUSE HOLDER 0A 0V
FH4003 1-533-313-11 FUSE HOLDER 0A 0V
FH4004 1-533-313-11 FUSE HOLDER 0A 0V
< IC >
IC4001 8-759-474-09 IC SI-8050S-LF1101
IC4100 8-759-659-28 IC SI-8033S
< COIL >
L4000 1-456-545-11 INDUCTOR 100uH
L4001 1-456-545-11 INDUCTOR 100uH
L4100 1-456-545-11 INDUCTOR 100uH
L4101 1-456-545-11 INDUCTOR 100uH
