54
STR-K995
Pin No. Pin Name I/O Description
1 HSYNC I Horizontal synchronize signal input from HDMI RX.
2 VSYNC I Vertical synchronize signal input from HDMI RX.
3 CGND — Ground pin
4 CVCC18 — Power supply pin (+1.8 V)
5 SPDIF I SPDIF signal input from HDMI RX.
6 MCLK I Audio master clock signal input from HDMI RX.
7 to 10 SD3 to SD0 I Serial data input from HDMI RX.
11 WS I Word select signal input from HDMI RX.
12 SCK I Serial clock signal input from HDMI RX.
13 IOVCC — Power supply pin (+3.3 V)
14 IOGND — Ground pin
15 CGND — Ground pin
16 CVCC18 — Power supply pin (+1.8 V)
17 INT O Interrupt signal output for HDMI controller.
18 HPD I Hot plug detect signal input from HDMI OUT connector.
19 DSDA I/O I
2
C two-way data bus with HDMI OUT connector.
20 DSCL O I
2
C clock signal output for HDMI OUT connector.
21 RSVDL — Not used. (Fixed to “L”)
22 PGND1 — Ground pin
23 PVCC1 — Power supply pin (+3.3 V)
24 EXT_SWING — Not used. (Fixed to “H” (+3.3V))
25 AGND — Ground pin
26 TXC– O TMDS clock signal output for HDMI OUT connector.
27 TXC+ O TMDS clock signal output for HDMI OUT connector.
28 AVCC — Power supply pin (+3.3 V)
29 TX0– O TMDS data output 0 for HDMI OUT connector.
30 TX0+ O TMDS data output 0 for HDMI OUT connector.
31 AGND — Ground pin
32 TX1– O TMDS data output 1 for HDMI OUT connector.
33 TX1+ O TMDS data output 1 for HDMI OUT connector.
34 AVCC — Power supply pin (+3.3 V)
35 TX2– O TMDS data output 2 for HDMI OUT connector.
36 TX2+ O TMDS data output 2 for HDMI OUT connector.
37 AGND — Ground pin
38 PVCC2 — Power supply pin (+3.3 V)
39 PGND2 — Ground pin
40 NC — Not used. (Open)
41 CI2CA — Not used. (Fixed to “L”)
42 RESET I Reset signal input from HDMI controller. (L: Reset)
43 CSCL I I
2
C clock signal input from HDMI controller.
44 CSDA I/O I
2
C two-way data bus with HDMI section.
45 CVCC18 — Power supply pin (+1.8 V)
46 CGND — Ground pin
47 IOGND — Ground pin
48 IOVCC — Power supply pin (+3.3 V)
49 to 58 D23 to D14 I Serial data input 23 to 14 from HDMI RX
59 CVCC18 — Power supply pin (+1.8 V)
60 CGND — Ground pin
HDMI RE BOARD IC3513 SII9030CTU-7 (TX)
