72
STR-K995
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
VIDEO3
< CONNECTOR >
CNS206 1-568-826-11 CONNECTOR, FFC 7P
< DIODE >
D203 8-719-991-33 DIODE 1SS133T-77
D204 8-719-991-33 DIODE 1SS133T-77
< IC >
IC203 6-701-890-01 IC NJM2595D
IC304 6-707-363-01 IC NJM2586AL
0 IC804 8-759-245-79 IC TA79005S
0 IC807 8-759-231-53 IC TA7805S
< JACK >
J200 1-794-978-11 JACK, PIN 3P(DVD,VIDEO 1,SAT)
J201 1-815-043-11 JACK, PIN 2P(VIDEO 1,MONITOR)
J301 1-816-592-11 JACK, PIN 9P(COMPONENT VIDEO)
J302 1-815-360-11 JACK, PIN 3P(MONITOR OUT)
< RESISTOR >
R200 1-247-804-11 CARBON 75 5% 1/4W
R201 1-247-804-11 CARBON 75 5% 1/4W
R218 1-247-804-11 CARBON 75 5% 1/4W
R219 1-247-804-11 CARBON 75 5% 1/4W
R220 1-247-804-11 CARBON 75 5% 1/4W
R221 1-247-804-11 CARBON 75 5% 1/4W
R301 1-247-804-11 CARBON 75 5% 1/4W
R302 1-247-804-11 CARBON 75 5% 1/4W
R303 1-247-804-11 CARBON 75 5% 1/4W
R304 1-247-804-11 CARBON 75 5% 1/4W
R305 1-247-804-11 CARBON 75 5% 1/4W
R306 1-247-804-11 CARBON 75 5% 1/4W
R307 1-247-804-11 CARBON 75 5% 1/4W
R308 1-247-804-11 CARBON 75 5% 1/4W
R309 1-247-804-11 CARBON 75 5% 1/4W
R310 1-247-804-11 CARBON 75 5% 1/4W
R311 1-247-804-11 CARBON 75 5% 1/4W
R312 1-247-804-11 CARBON 75 5% 1/4W
************************************************************
VIDEO3 BOARD
************
< CAPACITOR >
C293 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C294 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C298 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C299 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
< CONNECTOR >
CN201 1-564-721-11 PIN, CONNECTOR (SMALL TYPE) 5P
* CN202 1-690-880-31 LEAD (WITH CONNECTOR)
< JACK >
J298 1-819-187-11 PIN JACK 3P (VIDEO3 IN / PORTABLE AV IN)
< RESISTOR >
R298 1-216-821-11 METAL CHIP 1K 5% 1/10W
R299 1-216-821-11 METAL CHIP 1K 5% 1/10W
************************************************************
MISCELLANEOUS
**************
8 1-828-994-11 WIRE (FLAT TYPE) (17 CORE)
0 57 1-783-820-11 CORD, POWER
59 1-828-946-11 WIRE (FLAT TYPE) (7 CORE)
60 1-828-953-11 WIRE (FLAT TYPE) (9 CORE)
63 1-828-560-11 WIRE (FLAT TYPE) (7 CORE)
0 F901 1-533-453-12 FUSE, GLASS TUBE (DIA. 5)(5A/125V)
0 F4001 1-532-465-33 FUSE (T3.15AL/250V)
0 F4002 1-532-465-33 FUSE (T3.15AL/250V)
0 Q503 6-702-390-01 IC MN2488-OPY-MK
0 Q504 6-702-391-01 IC MP1620-OPY-MK
0 Q603 6-702-390-01 IC MN2488-OPY-MK
0 Q604 6-702-391-01 IC MP1620-OPY-MK
0 Q653 6-702-390-01 IC MN2488-OPY-MK
0 Q654 6-702-391-01 IC MP1620-OPY-MK
0 Q703 6-702-390-01 IC MN2488-OPY-MK
0 Q704 6-702-391-01 IC MP1620-OPY-MK
0 Q753 6-702-390-01 IC MN2488-OPY-MK
0 Q754 6-702-391-01 IC MP1620-OPY-MK
0 T901 1-443-524-11 POWER TRANSFORMER
TN1 1-693-728-11 TUNER (FM/AM)
