Sony STR-KM5500 - Electrical Parts List - Headphone Board Components; Headphone Board Capacitors and ICs List

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-KM5500
6565
HEADPHONE BOARD
*****************
< CAPACITOR >
C791 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
*
CNP790 1-564-507-11 PLUG, CONNECTOR 4P
< JACK >
J790 1-817-629-11 JACK (LARGE TYPE) (PHONES)
< LEAD >
*
TP790 1-690-880-31 LEAD (WITH CONNECTOR)
*************************************************************
A-1660-430-A MAIN BOARD, COMPLETE (EXCEPT E51, EA)
A-1707-435-A MAIN BOARD, COMPLETE (E51, EA)
*********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C320 1-126-923-91 ELECT 220uF 20% 10V
C323 1-126-923-91 ELECT 220uF 20% 10V
C325 1-126-964-11 ELECT 10uF 20% 50V
C335 1-126-934-11 ELECT 220uF 20% 16V
C350 1-137-980-91 CERAMIC CHIP 0.47uF 10% 50V
C351 1-126-933-11 ELECT 100uF 20% 16V
C352 1-137-980-91 CERAMIC CHIP 0.47uF 10% 50V
C353 1-126-933-11 ELECT 100uF 20% 16V
C400 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C403 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C405 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C408 1-126-963-11 ELECT 4.7uF 20% 50V
C409 1-126-963-11 ELECT 4.7uF 20% 50V
C430 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C431 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C449 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C450 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C458 1-126-963-11 ELECT 4.7uF 20% 50V
C459 1-126-963-11 ELECT 4.7uF 20% 50V
C471 1-126-964-11 ELECT 10uF 20% 50V
C489 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C499 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C523 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C524 1-126-963-11 ELECT 4.7uF 20% 50V
C525 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C526 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C527 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C532 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C534 1-126-963-11 ELECT 4.7uF 20% 50V
C537 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C546 1-126-960-11 ELECT 1uF 20% 50V
C547 1-126-960-11 ELECT 1uF 20% 50V
C548 1-100-152-91 CERAMIC CHIP 100PF 5% 100V
C549 1-100-152-91 CERAMIC CHIP 100PF 5% 100V
C550 1-100-152-91 CERAMIC CHIP 100PF 5% 100V
C551 1-100-152-91 CERAMIC CHIP 100PF 5% 100V
C602 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C603 1-101-810-00 CERAMIC 100PF 5% 500V
C604 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C605 1-107-583-11 CERAMIC 3PF 0.25PF 500V
C607 1-126-947-11 ELECT 47uF 20% 35V
C608 1-114-989-81 CERAMIC 47PF 5% 1KV
C609 1-114-989-81 CERAMIC 47PF 5% 1KV
C610 1-126-964-11 ELECT 10uF 20% 50V
C611 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C612 1-126-923-91 ELECT 220uF 20% 10V
C629 1-136-157-00 FILM 0.022uF 5% 50V
C652 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C653 1-101-810-00 CERAMIC 100PF 5% 500V
C654 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C655 1-107-583-11 CERAMIC 3PF 0.25PF 500V
C657 1-126-947-11 ELECT 47uF 20% 35V
C658 1-114-989-81 CERAMIC 47PF 5% 1KV
C659 1-114-989-81 CERAMIC 47PF 5% 1KV
C660 1-126-964-11 ELECT 10uF 20% 50V
C661 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C662 1-126-923-91 ELECT 220uF 20% 10V
C679 1-136-157-00 FILM 0.022uF 5% 50V
C702 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C703 1-101-810-00 CERAMIC 100PF 5% 500V
C704 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C705 1-107-583-11 CERAMIC 3PF 0.25PF 500V
C707 1-126-947-11 ELECT 47uF 20% 35V
C708 1-114-989-81 CERAMIC 47PF 5% 1KV
C709 1-114-989-81 CERAMIC 47PF 5% 1KV
C710 1-126-964-11 ELECT 10uF 20% 50V
C711 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C712 1-126-923-91 ELECT 220uF 20% 10V
C725 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C729 1-136-157-00 FILM 0.022uF 5% 50V
C752 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C753 1-101-810-00 CERAMIC 100PF 5% 500V
C754 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C755 1-107-583-11 CERAMIC 3PF 0.25PF 500V
C757 1-126-947-11 ELECT 47uF 20% 35V
C758 1-114-989-81 CERAMIC 47PF 5% 1KV
C759 1-114-989-81 CERAMIC 47PF 5% 1KV
C760 1-126-964-11 ELECT 10uF 20% 50V
C761 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C762 1-126-923-91 ELECT 220uF 20% 10V
C775 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C779 1-136-157-00 FILM 0.022uF 5% 50V
C802 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C803 1-101-810-00 CERAMIC 100PF 5% 500V
C804 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C805 1-107-583-11 CERAMIC 3PF 0.25PF 500V
C807 1-126-947-11 ELECT 47uF 20% 35V
C808 1-162-815-11 CERAMIC 47PF 5% 500V
C809 1-162-815-11 CERAMIC 47PF 5% 500V
C810 1-126-964-11 ELECT 10uF 20% 50V
C811 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C812 1-126-923-91 ELECT 220uF 20% 10V
C829 1-136-157-00 FILM 0.022uF 5% 50V
C852 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C853 1-101-810-00 CERAMIC 100PF 5% 500V
C854 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
MAINHEADPHONE
Ver. 1.2
