Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 81 —
Q756 8-749-010-25 IC MN2488-OPY-M
Q757 8-749-010-26 IC MP1620-OPY-M
Q758 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q798 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q799 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
< RESISTOR >
R701 1-249-417-11 CARBON 1K 5% 1/4W F
R702 1-247-881-00 CARBON 120K 5% 1/4W
R703 1-249-439-11 CARBON 68K 5% 1/4W
R704 1-249-418-11 CARBON 1.2K 5% 1/4W F
R705 1-247-807-31 CARBON 100 5% 1/4W
R712 1-249-439-11 CARBON 68K 5% 1/4W
R720 1-249-429-11 CARBON 10K 5% 1/4W
R721 1-249-422-11 CARBON 2.7K 5% 1/4W F
R722 1-249-433-11 CARBON 22K 5% 1/4W
R723 1-249-442-11 CARBON 510 5% 1/4W
! R724 1-249-408-11 CARBON 180 5% 1/4W F
! R725 1-249-408-11 CARBON 180 5% 1/4W F
! R726 1-234-182-11 ENCAPSULATED COMPONENT
R727 1-240-855-91 CARBON 6.2K 5% 1/4W
R728 1-249-425-11 CARBON 4.7K 5% 1/4W F
R729 1-247-866-11 CARBON 30K 5% 1/4W
R730 1-249-421-11 CARBON 2.2K 5% 1/4W F
R731 1-249-433-11 CARBON 22K 5% 1/4W
R732 1-249-437-11 CARBON 47K 5% 1/4W
! R733 1-249-393-11 CARBON 10 5% 1/4W F
R735 1-249-431-11 CARBON 15K 5% 1/4W
R749 1-249-393-11 CARBON 10 5% 1/4W F
! R751 1-249-417-11 CARBON 1K 5% 1/4W F
R752 1-247-881-00 CARBON 120K 5% 1/4W
R753 1-249-439-11 CARBON 68K 5% 1/4W
R754 1-249-418-11 CARBON 1.2K 5% 1/4W F
R755 1-247-807-31 CARBON 100 5% 1/4W
R762 1-249-439-11 CARBON 68K 5% 1/4W
R770 1-249-429-11 CARBON 10K 5% 1/4W
R771 1-249-422-11 CARBON 2.7K 5% 1/4W F
R772 1-249-433-11 CARBON 22K 5% 1/4W
R773 1-249-442-11 CARBON 510 5% 1/4W
! R774 1-249-408-11 CARBON 180 5% 1/4W F
! R775 1-249-408-11 CARBON 180 5% 1/4W F
! R776 1-234-182-11 ENCAPSULATED COMPONENT
R777 1-240-855-91 CARBON 6.2K 5% 1/4W
R778 1-249-425-11 CARBON 4.7K 5% 1/4W F
R782 1-249-437-11 CARBON 47K 5% 1/4W
! R783 1-249-393-11 CARBON 10 5% 1/4W F
R790 1-249-433-11 CARBON 22K 5% 1/4W
R795 1-249-419-11 CARBON 1.5K 5% 1/4W F
R796 1-249-431-11 CARBON 15K 5% 1/4W
R798 1-249-419-11 CARBON 1.5K 5% 1/4W F
R799 1-249-431-11 CARBON 15K 5% 1/4W
< VARIABLE RESISTOR >
RV701 1-238-595-11 RES, ADJ, CARBON 220
RV751 1-238-595-11 RES, ADJ, CARBON 220
SPREAR-AMP ROTARY
< RELAY >
RY701 1-515-920-11 RELAY (24V)
< TEST PIN >
* TP701 1-560-060-00 PIN, CONNECTOR 2P
* TP751 1-560-060-00 PIN, CONNECTOR 2P
************************************************************
1-673-364-11 ROTARY BOARD
*************
< LED >
D108 8-719-046-39 LED SEL5821A-TP15 (MUTING)
< RESISTOR >
R102 1-216-037-00 METAL CHIP 330 5% 1/10W
R159 1-216-037-00 METAL CHIP 330 5% 1/10W
R160 1-216-041-00 METAL CHIP 470 5% 1/10W
< VARIABLE RESISTOR >
RV101 1-467-808-21 ENCODER, ROTARY (FUNCTION)
< SWITCH >
S126 1-771-349-21 SWITCH, KEYBOARD (MODE)
S127 1-771-349-21 SWITCH, KEYBOARD (MUTING)
************************************************************
* 1-673-355-11 SP BOARD
********
< CAPACITOR >
CC41 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
CC42 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
CC43 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
CC47 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
CC48 1-136-153-00 FILM 0.01uF 5% 50V
CC49 1-136-153-00 FILM 0.01uF 5% 50V
CC97 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
CC98 1-136-153-00 FILM 0.01uF 5% 50V
CC99 1-136-153-00 FILM 0.01uF 5% 50V
CC101 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
CC151 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
CC201 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
CC251 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
CC301 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
CC351 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
< JACK >
JJ101 1-784-935-21 JACK, PIN 6P (PRE OUT) (DB930/V929X)
JJ101 1-784-935-11 JACK, PIN 6P (PRE OUT) (DB830)
JJ102 1-785-298-11 JACK, PIN 1P (CENTER) (DB930/V929X)
JJ102 1-774-785-11 JACK, PIN 1P (CENTER) (DB830)
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
