Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
ā 82 ā
< COIL >
L601 1-411-906-11 COIL, AIR-CORE
L701 1-411-906-11 COIL, AIR-CORE
L751 1-411-906-11 COIL, AIR-CORE
< RESISTOR >
R634 1-249-389-11 CARBON 4.7 5% 1/4W F
R734 1-249-389-11 CARBON 4.7 5% 1/4W F
R784 1-249-389-11 CARBON 4.7 5% 1/4W F
RR48 1-249-393-11 CARBON 10 5% 1/4W F
RR49 1-249-393-11 CARBON 10 5% 1/4W F
RR98 1-249-393-11 CARBON 10 5% 1/4W F
RR99 1-249-393-11 CARBON 10 5% 1/4W F
RR101 1-216-049-91 RES,CHIP 1K 5% 1/10W
RR102 1-216-049-91 RES,CHIP 1K 5% 1/10W
RR103 1-216-077-00 METAL CHIP 15K 5% 1/10W
RR151 1-216-049-91 RES,CHIP 1K 5% 1/10W
RR152 1-216-049-91 RES,CHIP 1K 5% 1/10W
RR153 1-216-077-00 METAL CHIP 15K 5% 1/10W
RR201 1-216-049-91 RES,CHIP 1K 5% 1/10W
RR202 1-216-049-91 RES,CHIP 1K 5% 1/10W
RR203 1-216-077-00 METAL CHIP 15K 5% 1/10W
RR251 1-216-049-91 RES,CHIP 1K 5% 1/10W
RR301 1-216-049-91 RES,CHIP 1K 5% 1/10W
RR302 1-216-049-91 RES,CHIP 1K 5% 1/10W
RR303 1-216-077-00 METAL CHIP 15K 5% 1/10W
RR351 1-216-049-91 RES,CHIP 1K 5% 1/10W
RR352 1-216-049-91 RES,CHIP 1K 5% 1/10W
RR353 1-216-077-00 METAL CHIP 15K 5% 1/10W
< TERMINAL >
* TM501 1-694-454-21 TERMINAL BOARD (SP)(FRONT SPEAKERS)
TM701 1-694-432-21 TERMINAL BOARD (SP)(REAR SPEAKERS)
************************************************************
1-673-363-11 SP-SW BOARD
************
< CONNECTOR >
* CNP102 1-695-808-11 CONNECTOR, PC BOARD 8P
< DIODE >
D105 8-719-820-05 DIODE 1SS181-TE85L
< RESISTOR >
R155 1-216-041-00 METAL CHIP 470 5% 1/10W
R156 1-216-045-00 METAL CHIP 680 5% 1/10W
R157 1-216-049-91 RES,CHIP 1K 5% 1/10W
< SWITCH >
S101 1-771-349-21 SWITCH, KEYBOARD (POWER)
S102 1-762-268-11 SWITCH, ROTARY (SPEAKERS)
S122 1-771-349-21 SWITCH, KEYBOARD (PRESET TUNING+)
S123 1-771-349-21 SWITCH, KEYBOARD (PRESET TUNING-)
S124 1-771-349-21 SWITCH, KEYBOARD (SHIFT)
S125 1-771-349-21 SWITCH, KEYBOARD (FM/AM)
************************************************************
A-4419-368-A S-VIDEO BOARD, COMPLETE (DB830:US)
***********************
A-4419-369-A S-VIDEO BOARD, COMPLETE (DB830:AEP)
***********************
A-4419-371-A S-VIDEO BOARD, COMPLETE
***********************
(DB930:AEP,MY,SP,AUS/V929X)
A-4419-370-A S-VIDEO BOARD, COMPLETE (DB930:US,CND)
***********************
< CAPACITOR >
C214 1-104-664-11 ELECT 47uF 20% 16V
C251 1-136-165-00 FILM 0.1uF 5% 50V
C252 1-136-165-00 FILM 0.1uF 5% 50V
C253 1-126-964-11 ELECT 10uF 20% 50V
C254 1-136-165-00 FILM 0.1uF 5% 50V
C255 1-136-165-00 FILM 0.1uF 5% 50V
C256 1-126-964-11 ELECT 10uF 20% 50V
C257 1-136-165-00 FILM 0.1uF 5% 50V
C258 1-126-964-11 ELECT 10uF 20% 50V
C259 1-126-964-11 ELECT 10uF 20% 50V
C260 1-136-165-00 FILM 0.1uF 5% 50V
C261 1-104-664-11 ELECT 47uF 20% 16V
C262 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C263 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C264 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C265 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C266 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C267 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C268 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C269 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C270 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C271 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
(DB830:US/DB930:US,CND)
C272 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
(DB830:US/DB930:US,CND)
C273 1-126-964-11 ELECT 10uF 20% 50V
(DB830:US/DB930:US,CND)
C274 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
(DB830:US/DB930:US,CND)
C275 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
(DB830:US/DB930:US,CND)
< CONNECTOR >
* CNS210 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
CNS211 1-695-094-11 SOCKET, CONNECTOR 11P
CNS215 1-784-776-11 CONNECTOR, FFC 15P
< DIODE >
D251 8-719-801-78 DIODE 1SS184-TE85L
< IC >
IC202 8-759-245-79 IC M5F7905L
IC251 8-759-536-24 IC NJM-2296M-TE2
IC252 8-759-536-24 IC NJM-2296M-TE2
IC253 8-759-356-27 IC NJM2129M-TE2
(DB830:US/DB930:US,CND)
IC254 8-759-135-80 IC LM358P (DB830:US/DB930:US,CND)
S-VIDEO
SP
SP-SW
