Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
ā 83 ā
< JACK >
J251 1-779-800-11 TERMINAL, S (S-VIDEO OUT)(DB930/V929X)
J251 1-537-943-11 TERMINAL, S (S-VIDEO OUT)(DB830)
J252 1-779-801-11 CONNECTOR (ROUND TYPE) (S-VIDEO IN/OUT)
(DB930/V929X)
J252 1-764-676-11 CONNECTOR (ROUND TYPE) (S-VIDEO IN/OUT)
(DB830)
J253 1-779-801-11 CONNECTOR (ROUND TYPE) (S-VIDEO IN)
(DB930/V929X)
J253 1-537-943-11 TERMINAL, S(S-VIDEO IN)(DB830)
J255 1-563-330-11 JACK (CONTROL S OUT)
(DB830:US/DB930:US,CND)
J256 1-563-330-11 JACK (CONTROL S OUT)
(DB830:US/DB930:US,CND)
J257 1-563-330-11 JACK (CONTROL S IN)
(DB830:US/DB930:US,CND)
J258 1-563-330-11 JACK (CONTROL S IN)
(DB830:US/DB930:US,CND)
< TRANSISTOR >
Q251 8-729-216-22 TRANSISTOR 2SA1162-YG-TE85L
(DB830:US/DB930:US,CND)
Q252 8-729-216-22 TRANSISTOR 2SA1162-YG-TE85L
(DB830:US/DB930:US,CND)
Q253 8-729-216-22 TRANSISTOR 2SA1162-YG-TE85L
(DB830:US/DB930:US,CND)
Q254 8-729-230-49 TRANSISTOR 2SC2712-YG-TE85L
(DB830:US/DB930:US,CND)
Q255 8-729-230-49 TRANSISTOR 2SC2712-YG-TE85L
(DB830:US/DB930:US,CND)
Q256 8-729-216-22 TRANSISTOR 2SA1162-YG-TE85L
(DB830:US/DB930:US,CND)
Q257 8-729-216-22 TRANSISTOR 2SA1162-YG-TE85L
(DB830:US/DB930:US,CND)
Q258 8-729-230-49 TRANSISTOR 2SC2712-YG-TE85L
(DB830:US/DB930:US,CND)
< RESISTOR >
R251 1-216-022-00 METAL CHIP 75 5% 1/10W
R252 1-216-073-00 METAL CHIP 10K 5% 1/10W
R253 1-216-022-00 METAL CHIP 75 5% 1/10W
R254 1-216-022-00 METAL CHIP 75 5% 1/10W
R255 1-216-022-00 METAL CHIP 75 5% 1/10W
R256 1-216-073-00 METAL CHIP 10K 5% 1/10W
R257 1-216-022-00 METAL CHIP 75 5% 1/10W
R258 1-216-022-00 METAL CHIP 75 5% 1/10W
R259 1-216-022-00 METAL CHIP 75 5% 1/10W
R260 1-216-022-00 METAL CHIP 75 5% 1/10W
R261 1-216-022-00 METAL CHIP 75 5% 1/10W
R262 1-216-022-00 METAL CHIP 75 5% 1/10W
R263 1-216-073-00 METAL CHIP 10K 5% 1/10W
(DB830:US/DB930:US,CND)
R264 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
(DB830:US/DB930:US,CND)
R265 1-216-049-91 RES,CHIP 1K 5% 1/10W
(DB830:US/DB930:US,CND)
R266 1-216-049-91 RES,CHIP 1K 5% 1/10W
(DB830:US/DB930:US,CND)
R267 1-216-049-91 RES,CHIP 1K 5% 1/10W
(DB830:US/DB930:US,CND)
R268 1-216-089-91 RES,CHIP 47K 5% 1/10W
(DB830:US/DB930:US,CND)
R269 1-216-081-00 METAL CHIP 22K 5% 1/10W
(DB830:US/DB930:US,CND)
R270 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
(DB830:US/DB930:US,CND)
R271 1-216-049-91 RES,CHIP 1K 5% 1/10W
(DB830:US/DB930:US,CND)
R272 1-216-049-91 RES,CHIP 1K 5% 1/10W
(DB830:US/DB930:US,CND)
R273 1-216-043-91 RES,CHIP 560 5% 1/10W
(DB830:US/DB930:US,CND)
R274 1-216-041-00 METAL CHIP 470 5% 1/10W
(DB830:US/DB930:US,CND)
R275 1-216-049-91 RES,CHIP 1K 5% 1/10W
(DB830:US/DB930:US,CND)
R276 1-216-049-91 RES,CHIP 1K 5% 1/10W
(DB830:US/DB930:US,CND)
R277 1-216-041-00 METAL CHIP 470 5% 1/10W
(DB830:US/DB930:US,CND)
R278 1-216-043-91 RES,CHIP 560 5% 1/10W
(DB830:US/DB930:US,CND)
R279 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
(DB830:US/DB930:US,CND)
R280 1-216-073-00 METAL CHIP 10K 5% 1/10W
(DB830:US/DB930:US,CND)
************************************************************
* 1-673-358-11 TUNER BOARD
************
< CAPACITOR >
C1 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
(DB830:AEP/DB930:AEP)
C2 1-126-961-11 ELECT 2.2uF 20% 50V
(DB830:AEP/DB930:AEP)
C3 1-126-964-11 ELECT 10uF 20% 50V
(DB830:AEP/DB930:AEP)
C4 1-165-319-11 CERAMIC CHIP 0.1uF 50V
(DB830:AEP/DB930:AEP)
C5 1-163-135-00 CERAMIC CHIP 560PF 5% 50V
(DB830:AEP/DB930:AEP)
C6 1-163-249-11 CERAMIC CHIP 82PF 5% 50V
(DB830:AEP/DB930:AEP)
C7 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
(DB830:AEP/DB930:AEP)
C381 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C382 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C399 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CNS303 1-569-306-11 SOCKET, CONNECTOR (L TYRE) 15P
CNS305 1-774-289-11 PIN, CONNECTOR (PC BOARD) 15P
< IC >
IC1 8-759-557-36 IC BU1924F-E2 (DB830:AEP/DB930:AEP)
IC399 8-759-708-12 IC NJM78L12A-T3
TUNER
S-VIDEO
