Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
23
TA-S9D
FRONT AMP
C955 1-136-165-00 FILM 0.1uF 5% 50V
C956 1-136-165-00 FILM 0.1uF 5% 50V
C961 1-128-563-11 ELECT 100uF 20% 100V
C962 1-128-563-11 ELECT 100uF 20% 100V
C963 1-104-665-11 ELECT 100uF 20% 10V
C964 1-119-943-91 ELECT 47uF 20% 50V
C987 1-164-159-11 CERAMIC 0.1uF 50V
C990 1-164-159-11 CERAMIC 0.1uF 50V
C991 1-126-940-11 ELECT 330uF 20% 25V
C992 1-113-342-11 CERAMIC 0.1uF 50V
C993 1-126-935-11 ELECT 470uF 20% 16V
C994 1-126-934-11 ELECT 220uF 20% 10V
< CONNECTOR >
CN103 1-778-981-11 CONNECTOR, BOARD TO BOARD 13P
CN104 1-784-784-11 CONNECTOR, FFC 23P (AEP, UK)
CN104 1-784-786-11 CONNECTOR, FFC 25P (EXCEPT AEP, UK)
CN105 1-564-506-11 PLUG, CONNECTOR 3P
CN106 1-573-846-11 CONNECTOR, BOARD TO BOARD 14P
CN107 1-794-498-21 SOCKET, CONNECTOR 20P
(SYSTEM CONTROL 1 FROM ST-S9)
CN108 1-770-721-11 CONNECTOR, BOARD TO BOARD 4P
CN113 1-770-594-21 CONNECTOR, BOARD TO BOARD 5P
< DIODE >
D801 8-719-911-19 DIODE 1SS133T-72
D802 8-719-911-19 DIODE 1SS133T-72
D821 8-719-911-19 DIODE 1SS133T-72
D831 8-719-911-19 DIODE 1SS133T-72
D851 8-719-911-19 DIODE 1SS133T-72
D871 8-719-911-19 DIODE 1SS133T-72
D881 8-719-911-19 DIODE 1SS133T-72
D911 8-719-510-68 DIODE D5SBA204101
D923 8-719-024-99 DIODE 11ES2-NTA2B
D924 8-719-024-99 DIODE 11ES2-NTA2B
D925 8-719-911-19 DIODE 1SS133T-72
D926 8-719-911-19 DIODE 1SS133T-72
D951 8-719-510-68 DIODE D5SBA204101
D963 8-719-911-19 DIODE 1SS133T-72
D970 8-719-024-99 DIODE 11ES2-NTA2B
D971 8-719-024-99 DIODE 11ES2-NTA2B
D972 8-719-024-99 DIODE 11ES2-NTA2B
D973 8-719-024-99 DIODE 11ES2-NTA2B
D974 8-719-024-99 DIODE 11ES2-NTA2B
D975 8-719-024-99 DIODE 11ES2-NTA2B
D980 8-719-024-99 DIODE 11ES2-NTA2B
D981 8-719-024-99 DIODE 11ES2-NTA2B
D990 8-719-024-99 DIODE 11ES2-NTA2B
D991 8-719-024-99 DIODE 11ES2-NTA2B
D992 8-719-024-99 DIODE 11ES2-NTA2B
D993 8-719-024-99 DIODE 11ES2-NTA2B
D994 8-719-024-99 DIODE 11ES2-NTA2B
D995 8-719-024-99 DIODE 11ES2-NTA2B
D996 8-719-024-99 DIODE 11ES2-NTA2B
D997 8-719-024-99 DIODE 11ES2-NTA2B
< GROUND TERMINAL >
EPT901 1-537-770-21 TERMINAL BOARD, GROUND
EPT902 1-537-770-21 TERMINAL BOARD, GROUND
< IC >
IC310 6-800-467-01 IC PT8300-S
IC801 8-749-016-96 IC STK402-120S
IC923 8-759-595-88 IC NJM78L12A-T3
IC924 8-759-708-05 IC NJM78L05A-T3
< COIL >
L811 1-420-872-00 COIL, AIR-CORE
L831 1-420-872-00 COIL, AIR-CORE
L832 1-420-872-00 COIL, AIR-CORE
L833 1-420-872-00 COIL, AIR-CORE
L861 1-420-872-00 COIL, AIR-CORE
< TRANSISTOR >
Q801 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q821 8-729-231-55 TRANSISTOR 2SC2878AB-TPE2
Q822 8-729-900-63 TRANSISTOR BN1F4M-TP
Q851 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q871 8-729-231-55 TRANSISTOR 2SC2878AB-TPE2
Q881 8-729-119-76 TRANSISTOR 2SA1175TP-HFE
Q883 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q891 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q892 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q893 8-729-119-76 TRANSISTOR 2SA1175TP-HFE
Q894 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q895 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q896 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q897 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q902 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q903 8-729-140-04 TRANSISTOR 2SB1116-TP-LK
Q904 8-729-142-46 TRANSISTOR 2SC2001TP-LK
Q905 8-729-900-80 TRANSISTOR BA1A4M-TP
(EXCEPT AEP, UK)
Q906 8-729-111-29 TRANSISTOR 2SD1616-TP-LK
(EXCEPT AEP, UK)
Q961 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q962 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q963 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
< RESISTOR/DIODE >
R801 1-249-417-11 CARBON 1K 5% 1/4W
R802 1-249-438-11 CARBON 56K 5% 1/4W
R803 1-249-410-11 CARBON 270 5% 1/4W
R804 1-249-438-11 CARBON 56K 5% 1/4W
0 R805 1-234-499-21 ENCAPSULATED COMPONENT 0.22 5W
R806 1-249-417-11 CARBON 1K 5% 1/4W
R807 1-249-431-11 CARBON 15K 5% 1/4W
R808 1-249-441-11 CARBON 100K 5% 1/4W
R809 1-260-076-11 CARBON 10 5% 1/2W
R811 1-260-076-11 CARBON 10 5% 1/2W
(EXCEPT AEP, UK, KR)
R812 1-260-076-11 CARBON 10 5% 1/2W
(EXCEPT AEP, UK, KR)
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
