Sony TA-S9D - Page 24

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
24
TA-S9D
FRONT AMP
R812 1-260-300-11 CARBON 4.7 5% 1/2W
(AEP, UK, KR)
R814 1-249-437-11 CARBON 47K 5% 1/4W
R815 1-249-437-11 CARBON 47K 5% 1/4W
0 R821 1-215-891-11 METAL OXIDE 680 5% 2W F
R825 1-249-402-11 CARBON 56 5% 1/4W
R826 1-249-417-11 CARBON 1K 5% 1/4W
R827 1-249-433-11 CARBON 22K 5% 1/4W
R831 1-260-076-11 CARBON 10 5% 1/2W
R832 1-260-076-11 CARBON 10 5% 1/2W
R833 1-260-076-11 CARBON 10 5% 1/2W
R834 1-260-076-11 CARBON 10 5% 1/2W
R835 1-260-076-11 CARBON 10 5% 1/2W
R836 1-260-076-11 CARBON 10 5% 1/2W
R837 1-249-437-11 CARBON 47K 5% 1/4W
R838 1-249-437-11 CARBON 47K 5% 1/4W
R839 1-249-437-11 CARBON 47K 5% 1/4W
R851 1-249-417-11 CARBON 1K 5% 1/4W
R852 1-249-438-11 CARBON 56K 5% 1/4W
R853 1-249-410-11 CARBON 270 5% 1/4W
R854 1-249-438-11 CARBON 56K 5% 1/4W
0 R855 1-234-499-21 ENCAPSULATED COMPONENT 0.22 5W
R856 1-249-417-11 CARBON 1K 5% 1/4W
R857 1-249-431-11 CARBON 15K 5% 1/4W
R858 1-249-441-11 CARBON 100K 5% 1/4W
R859 1-260-076-11 CARBON 10 5% 1/2W
R861 1-260-076-11 CARBON 10 5% 1/2W
(EXCEPT AEP, UK, KR)
R862 1-260-076-11 CARBON 10 5% 1/2W
(EXCEPT AEP, UK, KR)
R862 1-260-300-11 CARBON 4.7 5% 1/2W
(AEP, UK, KR)
0 R871 1-215-891-11 METAL OXIDE 680 5% 2W F
R875 1-249-402-11 CARBON 56 5% 1/4W
R876 1-249-417-11 CARBON 1K 5% 1/4W
R877 1-249-433-11 CARBON 22K 5% 1/4W
R878 1-249-425-11 CARBON 4.7K 5% 1/4W
R879 1-249-441-11 CARBON 100K 5% 1/4W
R880 1-247-903-00 CARBON 1M 5% 1/4W
0 R881 1-215-888-00 METAL OXIDE 220 5% 2W F
R883 1-249-437-11 CARBON 47K 5% 1/4W
R885 1-249-429-11 CARBON 10K 5% 1/4W
R887 1-249-441-11 CARBON 100K 5% 1/4W
R889 1-249-429-11 CARBON 10K 5% 1/4W
R891 1-249-438-11 CARBON 56K 5% 1/4W
R892 1-249-439-11 CARBON 68K 5% 1/4W
R894 1-249-429-11 CARBON 10K 5% 1/4W
R895 1-249-429-11 CARBON 10K 5% 1/4W
R896 1-249-435-11 CARBON 33K 5% 1/4W
R897 1-249-433-11 CARBON 22K 5% 1/4W
R898 1-249-425-11 CARBON 4.7K 5% 1/4W
R903 1-249-429-11 CARBON 10K 5% 1/4W
R904 1-249-441-11 CARBON 100K 5% 1/4W
R905 1-249-421-11 CARBON 2.2K 5% 1/4W
R906 1-247-843-11 CARBON 3.3K 5% 1/4W
(EXCEPT AEP, UK)
R906 1-249-417-11 CARBON 1K 5% 1/4W
(AEP, UK)
R907 1-249-421-11 CARBON 2.2K 5% 1/4W
(AEP, UK)
R907 8-719-947-64 DIODE MTZJ-T-72-16A (EXCEPT AEP, UK)
R908 1-249-421-11 CARBON 2.2K 5% 1/4W
R910 1-247-807-31 CARBON 100 5% 1/4W
R911 1-247-807-31 CARBON 100 5% 1/4W
R912 1-247-807-31 CARBON 100 5% 1/4W
R913 1-249-437-11 CARBON 47K 5% 1/4W
R914 1-247-807-31 CARBON 100 5% 1/4W
R915 1-249-437-11 CARBON 47K 5% 1/4W
R916 1-247-807-31 CARBON 100 5% 1/4W
R917 1-249-411-11 CARBON 330 5% 1/4W
R918 1-249-411-11 CARBON 330 5% 1/4W
R919 1-249-411-11 CARBON 330 5% 1/4W
R920 1-249-411-11 CARBON 330 5% 1/4W
R921 1-249-411-11 CARBON 330 5% 1/4W
R923 1-249-417-11 CARBON 1K 5% 1/4W
R924 1-249-437-11 CARBON 47K 5% 1/4W
R925 1-249-437-11 CARBON 47K 5% 1/4W
R926 1-249-429-11 CARBON 10K 5% 1/4W
R927 1-249-437-11 CARBON 47K 5% 1/4W
R951 1-249-441-11 CARBON 100K 5% 1/4W
R952 1-249-441-11 CARBON 100K 5% 1/4W
R953 1-249-441-11 CARBON 100K 5% 1/4W
R954 1-249-441-11 CARBON 100K 5% 1/4W
0 R960 1-215-887-00 METAL OXIDE 150 5% 2W F
(EXCEPT AEP, UK)
R961 1-249-421-11 CARBON 2.2K 5% 1/4W
(EXCEPT AEP, UK)
R962 1-249-441-11 CARBON 100K 5% 1/4W
(EXCEPT AEP, UK)
0 R963 1-212-881-11 FUSIBLE 100 5% 1/4W F
0 R964 1-212-881-11 FUSIBLE 100 5% 1/4W F
R965 1-249-431-11 CARBON 15K 5% 1/4W
R966 1-249-435-11 CARBON 33K 5% 1/4W
R967 1-249-429-11 CARBON 10K 5% 1/4W
0 R968 1-202-972-61 FUSIBLE 1 5% 1/4W F
R969 1-249-433-11 CARBON 22K 5% 1/4W
R970 1-249-441-11 CARBON 100K 5% 1/4W
R971 1-249-421-11 CARBON 2.2K 5% 1/4W
R972 1-249-433-11 CARBON 22K 5% 1/4W
R973 1-249-421-11 CARBON 2.2K 5% 1/4W
R974 1-249-429-11 CARBON 10K 5% 1/4W
R991 1-249-417-11 CARBON 1K 5% 1/4W
R992 1-249-417-11 CARBON 1K 5% 1/4W
< RELAY >
RY881 1-515-920-11 RELAY
< TERMINAL >
TM101 1-694-677-12 TERMINAL BOARD (4P)
(FRONT SPEAKER IMPEDANCE USE 6-16Ω)
TM102 1-694-674-12 TERMINAL BOARD (6P) (REAR/CENTER
SPEAKER IMPEDANCE USE 8-16Ω)
**************************************************************
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
