Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
25
TA-S9D
A-4727-056-A PANEL BOARD, COMPLETE (TH)
A-4727-061-A PANEL BOARD, COMPLETE (AEP, UK)
A-4727-073-A PANEL BOARD, COMPLETE
(EXCEPT AEP, UK, KR)
**********************
< CAPACITOR >
C701 1-162-306-11 CERAMIC 0.01uF 30% 16V
C702 1-162-306-11 CERAMIC 0.01uF 30% 16V
C703 1-162-306-11 CERAMIC 0.01uF 30% 16V
C704 1-162-306-11 CERAMIC 0.01uF 30% 16V
C705 1-162-306-11 CERAMIC 0.01uF 30% 16V
C706 1-162-306-11 CERAMIC 0.01uF 30% 16V
C710 1-162-294-31 CERAMIC 0.001uF 10% 50V
C711 1-162-306-11 CERAMIC 0.01uF 30% 16V
C712 1-162-294-31 CERAMIC 0.001uF 10% 50V
C723 1-162-306-11 CERAMIC 0.01uF 30% 16V
(EXCEPT AEP, UK)
C724 1-115-868-11 ELECT 0.22uF 20% 50V
(EXCEPT AEP, UK)
C725 1-162-294-31 CERAMIC 0.001uF 10% 50V
(EXCEPT AEP, UK)
C726 1-162-215-31 CERAMIC 47PF 5% 50V
(EXCEPT AEP, UK)
C727 1-162-290-31 CERAMIC 470PF 10% 50V
(EXCEPT AEP, UK)
C728 1-115-867-11 ELECT 0.1uF 20% 50V
(EXCEPT AEP, UK)
C729 1-115-872-11 ELECT 2.2uF 20% 50V
(EXCEPT AEP, UK)
C730 1-162-287-31 CERAMIC 270PF 10% 50V
(EXCEPT AEP, UK)
C731 1-115-872-11 ELECT 2.2uF 20% 50V
(EXCEPT AEP, UK)
C732 1-126-382-11 ELECT 100uF 20% 10V
(EXCEPT AEP, UK)
C733 1-126-791-11 ELECT 10uF 20% 16V
(EXCEPT AEP, UK)
C734 1-162-215-31 CERAMIC 47PF 5% 50V
(EXCEPT AEP, UK)
C735 1-126-791-11 ELECT 10uF 20% 16V
(EXCEPT AEP, UK)
C751 1-164-159-11 CERAMIC 0.1uF 50V
(EXCEPT AEP, UK)
C752 1-126-791-11 ELECT 10uF 20% 16V
(EXCEPT AEP, UK)
C781 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
CN700 1-784-745-11 CONNECTOR, FFC 23P (AEP, UK)
CN700 1-784-747-11 CONNECTOR, FFC 25P (EXCEPT AEP, UK)
< LED >
D701 8-719-058-04 LED SEL5223S-TP15 (I/1)
D702 8-719-057-97 LED SEL5923A-TP15 (SUR)
D703 8-719-057-97 LED SEL5923A-TP15 (EQ)
D704 8-719-057-97 LED SEL5923A-TP15 (CINEMA STUDIO A)
D705 8-719-057-97 LED SEL5923A-TP15 (CINEMA STUDIO B)
D706 8-719-057-97 LED SEL5923A-TP15 (CINEMA STUDIO C)
D781 8-719-084-07 LED SEL5E20CTP15
(MULTI CHANNEL DECODING)
< COIL >
FB707 1-412-473-21 INDUCTOR 0uH (EXCEPT AEP, UK)
< IC >
IC702 8-759-167-88 IC NJM4565D (EXCEPT AEP, UK)
< JACK >
J702 1-815-603-11 JACK (MIC) (EXCEPT AEP, UK)
J703 1-691-293-21 JACK (PHONES)
< TRANSISTOR >
Q701 8-729-900-80 TRANSISTOR BA1A4M-TP
Q702 8-729-900-63 TRANSISTOR BN1F4M-TP
Q710 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
(EXCEPT AEP, UK)
< RESISTOR >
R707 1-249-411-11 CARBON 330 5% 1/4W
R708 1-247-807-31 CARBON 100 5% 1/4W
R709 1-249-410-11 CARBON 270 5% 1/4W
R710 1-249-413-11 CARBON 470 5% 1/4W
R711 1-249-414-11 CARBON 560 5% 1/4W
R712 1-249-416-11 CARBON 820 5% 1/4W
R713 1-249-417-11 CARBON 1K 5% 1/4W
R714 1-249-418-11 CARBON 1.2K 5% 1/4W
R715 1-249-419-11 CARBON 1.5K 5% 1/4W
R716 1-249-421-11 CARBON 2.2K 5% 1/4W
R717 1-249-422-11 CARBON 2.7K 5% 1/4W
R718 1-249-424-11 CARBON 3.9K 5% 1/4W
R719 1-249-426-11 CARBON 5.6K 5% 1/4W
R720 1-249-428-11 CARBON 8.2K 5% 1/4W
R721 1-249-431-11 CARBON 15K 5% 1/4W
R722 1-249-434-11 CARBON 27K 5% 1/4W
R723 1-249-439-11 CARBON 68K 5% 1/4W
R728 1-249-429-11 CARBON 10K 5% 1/4W
(EXCEPT AEP, UK)
R729 1-249-417-11 CARBON 1K 5% 1/4W
(EXCEPT AEP, UK)
R730 1-249-441-11 CARBON 100K 5% 1/4W
(EXCEPT AEP, UK)
R731 1-249-417-11 CARBON 1K 5% 1/4W
(EXCEPT AEP, UK)
R732 1-249-433-11 CARBON 22K 5% 1/4W
(EXCEPT AEP, UK)
R733 1-247-807-31 CARBON 100 5% 1/4W
(EXCEPT AEP, UK)
R734 1-249-429-11 CARBON 10K 5% 1/4W
(EXCEPT AEP, UK)
R735 1-247-883-00 CARBON 150K 5% 1/4W
(EXCEPT AEP, UK)
R736 1-247-807-31 CARBON 100 5% 1/4W
(EXCEPT AEP, UK)
R737 1-249-417-11 CARBON 1K 5% 1/4W
(EXCEPT AEP, UK)
R738 1-249-428-11 CARBON 8.2K 5% 1/4W
(EXCEPT AEP, UK)
R739 1-249-430-11 CARBON 12K 5% 1/4W
(EXCEPT AEP, UK)
PANEL
