19
TA-WR2
SECTION 4
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . , uPA. . , µPA. . ,
uPB. . : µPB. . , uPC. . , µPC. . ,
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
•Abbreviation
RU : Russian model
CND : Canadian model
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference number,
please include the board name.
A-1111-680-A DIAT POWER BOARD, COMPLETE
(AEP, UK, RU)
A-1111-681-A DIAT POWER BOARD, COMPLETE
(US, CND)
***************************
7-685-871-01 SCREW +BVTT 3X6 (S)
< CAPACITOR >
0 C901 1-165-529-11 MYLAR 0.22uF 10 275V
0 C903 1-113-900-11 CERAMIC 470PF 10% 250V
(AEP, UK, RU)
0 C903 1-113-907-51 CERAMIC 0.0022uF 99% 250V
(US, CND)
0 C904 1-165-528-11 MYLAR 0.1uF 10 275V
0 C906 1-100-923-11 ELECT 100uF 20% 450V
(AEP, UK, RU)
0 C906 1-100-922-11 ELECT 330uF 20% 200V
(US, CND)
0 C907 1-165-886-11 CERAMIC CHIP 3300PF 10% 630V
(AEP, UK, RU)
0 C907 1-165-883-11 CERAMIC CHIP 10000PF 10% 630V
(US, CND)
0 C908 1-125-893-11 FILM 680PF 3% 1.5KV
(AEP, UK, RU)
0 C908 1-117-631-31 FILM 3300PF 3% 1.2KV
(US, CND)
0 C909 1-107-906-11 ELECT 10uF 20% 50V
0 C910 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
0 C911 1-164-162-11 CERAMIC CHIP 100PF 5% 100V
0 C912 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
0 C913 1-107-907-11 ELECT 22uF 20% 50V
0 C914 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
0 C915 1-107-909-11 ELECT 47uF 20% 35V
C916 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
0 C917 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
0 C918 1-165-886-11 CERAMIC CHIP 3300PF 10% 630V
(AEP, UK, RU)
0 C925 1-117-699-11 CERAMIC 0.001uF 99% 250V
C931 1-125-782-91 CERAMIC 4700PF 10% 1KV
C932 1-128-959-21 ELECT 1000uF 20% 35V
C933 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C934 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C935 1-126-933-11 ELECT 100uF 20% 16V
C936 1-126-948-11 ELECT 100uF 20% 35V
C937 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C938 1-126-933-11 ELECT 100uF 20% 16V
C940 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C941 1-135-372-31 ELECT 470uF 20% 10V
C942 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
< CONNECTOR >
CN903 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
< DIODE >
0D901 8-719-077-77 DIODE D3SB60F3
0D902 6-500-241-01 DIODE SARS03
0D904 8-719-200-91 DIODE 11EQS10-TA1
0D905 8-719-982-26 DIODE MTZJ-T-77-33B
0D906 8-719-110-53 DIODE MTZJ-T-77-20B
0D907 8-719-988-61 DIODE 1SS355TE-17
0D908 8-719-200-91 DIODE 11EQS10-TA1
0D909 8-719-988-61 DIODE 1SS355TE-17
0D910 8-719-069-60 DIODE UDZSTE-179.1B
0D911 6-500-593-31 DIODE 10EDB60-TA1B2
0D913 8-719-069-56 DIODE UDZSTE-176.2B
0D914 8-719-977-28 DIODE UDZSTE-1710B
0D915 8-719-982-26 DIODE MTZJ-T-77-33B
D921 8-719-313-14 DIODE FML-22S
D922 8-719-210-21 DIODE 11EQS04-TA1B
D933 8-719-977-28 DIODE UDZSTE-1710B
D934 8-719-083-66 DIODE UDZSTE-1718B
< GROUND TERMINAL BOARD >
EB901 1-537-770-21 TERMINAL BOARD, GROUND
EB902 1-537-770-21 TERMINAL BOARD, GROUND
< FUSE HOLDER >
FH901 1-533-313-11 FUSE HOLDER
FH902 1-533-313-11 FUSE HOLDER
< IC >
0IC901 6-706-347-01 IC STR-W6735N (US, CND)
0IC901 6-706-348-01 IC STR-W6765N (AEP, UK, RU)
IC903 8-759-231-58 IC TA7812S
IC904 6-703-978-01 IC NJM2374AE (TE2)
IC905 6-707-799-01 IC NJM1431AU (TE2)
< COIL >
L901 1-456-509-11 INDUCTOR 10uH
L903 1-416-040-11 INDUCTOR 220uH
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque 0
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant le
numéro spécifié.
DIAT POWER
