22
TA-WR2
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< CONNECTOR >
CN101 1-784-366-21 CONNECTOR, FFC/FPC 7P
CN102 1-691-768-11 PLUG (MICRO CONNECTOR) 6P
CN103 1-779-977-11 PIN, CONNECTOR 6P
CN104 1-564-704-11 PIN, CONNECTOR (SMALL TYPE) 2P
< DIODE >
D100 8-719-920-55 DIODE SPR-54MVW
D102 8-719-988-61 DIODE 1SS355TE-17
D103 8-719-988-61 DIODE 1SS355TE-17
D104 6-500-260-01 DIODE P6SMB39AT3
D105 6-500-260-01 DIODE P6SMB39AT3
D106 6-500-260-01 DIODE P6SMB39AT3
D107 6-500-260-01 DIODE P6SMB39AT3
D115 8-719-421-15 DIODE MA8027-H-TX
< GROUND TERMINAL BOARD >
EB101 1-537-770-21 TERMINAL BOARD, GROUND
EB102 1-537-770-21 TERMINAL BOARD, GROUND
EB103 1-537-770-21 TERMINAL BOARD, GROUND
EB104 1-537-770-21 TERMINAL BOARD, GROUND
EB105 1-537-770-21 TERMINAL BOARD, GROUND
< FERRITE BEAD >
FB101 1-500-283-11 INDUCTOR, FERRITE BEAD
FB102 1-500-283-11 INDUCTOR, FERRITE BEAD
FB103 1-500-283-11 INDUCTOR, FERRITE BEAD
FB104 1-500-283-11 INDUCTOR, FERRITE BEAD
FB105 1-469-760-21 FERRITE, EMI (SMD) (2012)
FB106 1-469-760-21 FERRITE, EMI (SMD) (2012)
FB107 1-469-760-21 FERRITE, EMI (SMD) (2012)
FB108 1-469-760-21 FERRITE, EMI (SMD) (2012)
FB109 1-469-760-21 FERRITE, EMI (SMD) (2012)
< IC >
IC101 6-701-851-01 IC XC62HR1502MR
IC102 8-752-425-06 IC CXD4017R
IC103 8-759-548-99 IC SN74LV08APWR
IC104 6-704-261-01 IC TK11225CMCL-G
IC105 6-701-680-01 IC PST3629NR
IC106 8-759-679-55 IC SN74LVC08APWR
IC107 6-805-378-01 IC MB89537APFM-G-654-BNDE1
IC108 6-707-487-01 IC NJM2885DL1-33 (TE2)
IC109 8-759-679-55 IC SN74LVC08APWR
IC110 6-705-695-01 IC CXD9775M
IC111 6-707-939-01 IC CXD9843AR
IC112 6-705-695-01 IC CXD9775M
IC113 6-702-300-01 IC TK11118CSCL-G
IC114 8-759-649-50 IC SN74AHC1GU04DCKR
< JACK >
J100 1-818-633-11 JACK, PIN 1P (DIR-R2)
< COIL >
L101 1-400-305-11 INDUCTOR 47uH
L102 1-469-525-91 INDUCTOR 10uH
L103 1-469-525-91 INDUCTOR 10uH
L104 1-469-525-91 INDUCTOR 10uH
L105 1-469-525-91 INDUCTOR 10uH
L106 1-469-525-91 INDUCTOR 10uH
L107 1-469-525-91 INDUCTOR 10uH
L108 1-469-525-91 INDUCTOR 10uH
L109 1-469-525-91 INDUCTOR 10uH
L110 1-469-525-91 INDUCTOR 10uH
L111 1-469-525-91 INDUCTOR 10uH
L112 1-456-680-11 INDUCTOR 10uH
L115 1-456-680-11 INDUCTOR 10uH
L116 1-469-525-91 INDUCTOR 10uH
L118 1-456-680-11 INDUCTOR 10uH
L121 1-456-680-11 INDUCTOR 10uH
L122 1-412-939-11 INDUCTOR 1uH
L123 1-457-078-11 AIR-CORE COIL
L124 1-457-077-11 AIR-CORE COIL
L125 1-457-078-11 AIR-CORE COIL
L126 1-457-077-11 AIR-CORE COIL
< TRANSISTOR >
Q102 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q103 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q104 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q105 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q106 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q107 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q108 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q109 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q110 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q111 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q112 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q113 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q117 6-550-702-01 TRANSISTOR 2SC3243-TP-E
< RESISTOR >
R100 1-216-811-11 METAL CHIP 150 5% 1/10W
R101 1-216-833-11 METAL CHIP 10K 5% 1/10W
R102 1-216-820-11 METAL CHIP 820 5% 1/10W
R103 1-216-815-11 METAL CHIP 330 5% 1/10W
R104 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R105 1-216-841-11 METAL CHIP 47K 5% 1/10W
R106 1-216-809-11 METAL CHIP 100 5% 1/10W
R108 1-216-809-11 METAL CHIP 100 5% 1/10W
R109 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R110 1-216-821-11 METAL CHIP 1K 5% 1/10W
R111 1-216-813-11 METAL CHIP 220 5% 1/10W
R112 1-216-809-11 METAL CHIP 100 5% 1/10W
R113 1-216-809-11 METAL CHIP 100 5% 1/10W
R114 1-216-809-11 METAL CHIP 100 5% 1/10W
R115 1-216-809-11 METAL CHIP 100 5% 1/10W
R116 1-216-807-11 METAL CHIP 68 5% 1/10W
R117 1-216-833-11 METAL CHIP 10K 5% 1/10W
R118 1-216-821-11 METAL CHIP 1K 5% 1/10W
R119 1-216-821-11 METAL CHIP 1K 5% 1/10W
R120 1-216-821-11 METAL CHIP 1K 5% 1/10W
R122 1-216-833-11 METAL CHIP 10K 5% 1/10W
R123 1-216-837-11 METAL CHIP 22K 5% 1/10W
R124 1-216-841-11 METAL CHIP 47K 5% 1/10W
