Specifications
System
Recording system
4-track 2-channel stereo
Fast-winding time (approx.}
90 sec. (with Sony C-60 cassette)
High-speed fast-winding time (approx.) (TC-WA8ESA, TC-WA7ESA, TC-
WE805S and TC-WE7055 only)
45 sec. (with Sony C-60 cassette)
AC bias
Signal-to-noise ratio (at peak level and weighted with Dolby NR off)
Type I tape, Sony Type I (NORMAL): 55 dB
Type II tape, Sony Type II (HIGH): 57 dB
Type IV tape, Sony Type [V (METAL): 58 dB
S/N ratio improvement (approximate values)
With Dolby B NR on: 5 dB at 1 kHz, 10 dB at 5 kHz
With Dolby C NR on: 15 dB at 500 Hz, 20 dB at 1 kHz
With Dolby S NR on (unavailable on the TC-WE505):
10 dB at 100 Hz, 24 dB at 1 kHz
Harmonic distortion
0.4% (with Type I tape, Sony Type I (NORMAL):
160 nWb/m 315 Hz, 3rd H.D.)
1.8% (with Type IV tape, Sony Type IV (METAL):
250 nWb/m 315 Hz, 3rd H.D.)
Frequency response (Dolby NR off)
Tape type
30 - 16,000 Hz (+3 dB, IEC),
20 - 17,000 Hz (#6 dB)
Type I tape, Sony Type |
(NORMAL)
30 - 17,000 Hz (#3 dB, IEC),
20 - 18,000 Hz (+6 dB)
Type II tape, Sony Type II (HIGH)
Type IV tape, Sony Type IV 30 - 19,000 Hz (+3 dB, IEC),
(METAL) 20 - 20,000 Hz (+6 dB),
30 - 13,000 Hz (+3 dB, -4 dB
recording)
Wow and flutter
TC-WA8E'S A/WA7ESAIWE805S/ TC-WE505
WE7OSS/VVE605S/WR550Z
+0.14% W. Peak (IEC)
0.08% W. RMS (NAB)
+0.19% W. Peak (DIN)
+0.13% W. Peak (IEC)
0.07% W_ RMS (NAB)
0.18% W 7 Peak (DIN)
Variable pitch range {approx.) (TC-WE805S, TC-WE705S and TC-WES05
only)
—30 to +30%
Inputs
Line inputs (phono jacks}
Sensitivity : 0.16 V
Input impedance : 47 kilohms
Outputs
Line outputs (phono jacks)
Rated output level: 0.5 V at a load impedance of
47 kilohms
Load impedance : Over 10 kilohms
Headphones (stereo phone jack)
Output level : 0.25 mW at a load impedance of
32 ohms
General
Power requirements
Where purchased Power requirements
U.S.A. and Canada 120 V AC, 60 Hz
U.K., Continental Europe, 220 - 230 V AC, 50/60 Hz
China and certain countries
in Asia
Australia 240 V AC, 50/60 Hz
Other countries 120/220/240 V AC,
50/60 Hz
Power consumption
26W (TC-WA7ESA, TC-WE705S, TC-WE605S, TC-
WR550Z and TC-WE505)
28W (TC-WA8ESA and TC-WE805S)
Dimensions (approx) (w/h/d)
Model for U.K. and Australia:
430 x 120 x 303 mm (w/h/d)
(17 x 43/4 x 12 inches)
Model for other countries:
430 x 120 x 290 mm (w/h/d)
(17x 43/4 11'/2 inches)
including projecting parts and controls
Mass (approx.)
4.2 kg (9 Ibs 5 oz)
Supplied accessories
Audio connecting cords (2 phono plugs - 2 phono
plugs) (2)
Optional accessory
Remote commander RM-J910
For more information on the availability of the remote
commander, contact your nearest Sony dealer.
Design and specifications are subject to change without
notice.
