REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified ¡ marked are
critical for safety.
Replace only with the part number specified.
Les composants identifiés par la marque ¡
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
CPD-E400/E400E/E400P
7-4
R304 1-216-009-91 RES,CHIP 22 5% 1/10W
R306 1-216-071-00 RES,CHIP 8.2K 5% 1/10W
R307 1-216-675-91 METAL CHIP 10K 0.5% 1/10W
R308 1-216-049-91 RES,CHIP 1K 5% 1/10W
R309 1-216-041-00 RES,CHIP 470 5% 1/10W
R310 1-216-071-00 RES,CHIP 8.2K 5% 1/10W
R311 1-249-403-11 CARBON 68 5% 1/4W F
R315 1-216-107-00 RES,CHIP 270K 5% 1/10W
R317 1-216-025-91 RES,CHIP 100 5% 1/10W
R318 1-216-019-00 RES,CHIP 56 5% 1/10W
R319 1-216-113-00 RES,CHIP 470K 5% 1/10W
R320 1-216-113-00 RES,CHIP 470K 5% 1/10W
R322 1-216-113-00 RES,CHIP 470K 5% 1/10W
R323 1-216-037-00 RES,CHIP 330 5% 1/10W
R330 1-216-025-91 RES,CHIP 100 5% 1/10W
R333 1-216-295-91 SHORT 0
R351 1-219-742-11 CARBON 47 5% 1/2W
R361 1-215-394-00 METAL 75 1% 1/4W
<SPARK GAP>
SG001 1-519-422-11 GAP, SPARK
SG002 1-576-354-21 GAP, DISCHARGE
SG101 1-576-354-21 GAP, DISCHARGE
SG201 1-576-354-21 GAP, DISCHARGE
SG301 1-576-354-21 GAP, DISCHARGE
<CRYSTAL>
X001 1-781-472-21 VIBRATOR, CERAMIC (8MHz)
*******************************************************************************
D BOARD, COMPLETE
****************************
1-533-223-11 HOLDER, FUSE (F601)
3-710-578-01 COVER, VOLUME, 6 MOLD (RV901)
4-061-192-11 SHEET, INSULATING (Q505)
4-382-854-01 SCREW (M3X8), P, SW (+) (D614, D619,
IC401, IC502, IC604, IC605, IC609, IC610,
IC703, Q506, Q511, Q512, Q513, Q605,
Q704, Q705, Q901, Q902, R510)
4-382-854-11 SCREW (M3X10), P, SW (+)
(D504, D620, D622, Q505)
4-382-854-21 SCREW (M3X14), P, SW (+) (IC702)
7-685-881-09 SCREW +BVTT 4X8 (S)
<CAPACITOR>
C401 1-128-730-91 ELECT 470uF 20% 25V
C402 1-106-228-00 MYLAR 0.22uF 10% 100V
C403 1-128-749-91 ELECT 220uF 20% 50V
C404 1-128-730-91 ELECT 470uF 20% 25V
C406 1-137-366-11 MYLAR 0.0022uF 5% 50V
C407 1-164-182-11 CERAMIC CHIP 0.0033uF 10% 50V
C409 1-126-968-11 ELECT 100uF 20% 50V
C500 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C501 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C503 1-137-370-11 MYLAR 0.01uF 5% 50V
C504 1-137-368-11 MYLAR 0.0047uF 5% 50V
C505 1-128-729-91 ELECT 330uF 20% 25V
C506 1-127-810-51 ELECT MELF 22uF 20% 250V
C507 1-136-187-11 MYLAR 0.047uF 10% 250V
C508 1-117-959-11 FILM 4700pF 3% 1.8KV
C509 1-107-444-11 CERAMIC 100pF 5% 2KV
C510 1-136-684-51 MYLAR 0.0022uF 10% 100V
C511 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C512 1-102-114-00 CERAMIC 470pF 10% 50V
C513 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C514 1-137-368-11 MYLAR 0.0047uF 5% 50V
C515 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C516 1-126-382-11 ELECT 100uF 20% 16V
C517 1-163-263-11 CERAMIC CHIP 330pF 5% 50V
C518 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C520 1-163-024-00 CERAMIC CHIP 0.018uF 10% 50V
C521 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
C522 1-126-965-11 ELECT 22uF 20% 50V
C523 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C524 1-126-382-11 ELECT 100uF 20% 16V
C525 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C527 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
C528 1-130-489-00 MYLAR 0.033uF 5% 50V
C529 1-137-370-11 MYLAR 0.01uF 5% 50V
C530 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C531 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C532 1-107-906-11 ELECT 10uF 20% 50V
C533 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
C534 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C535 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C536 1-107-665-11 ELECT 0.47uF 20% 400V
C537 1-107-770-11 FILM 0.16uF 3% 400V
C538 1-107-651-11 ELECT 4.7uF 20% 250V
C539 1-117-673-11 FILM 1.5uF 5% 250V
C540 1-107-888-11 ELECT 47uF 20% 25V
C541 1-109-844-11 FILM 0.68uF 5% 250V
C542 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C543 1-117-665-11 FILM 0.33uF 5% 250V
C544 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C545 1-117-661-21 FILM 0.15uF 5% 250V
C546 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C547 1-119-860-11 FILM 0.082uF 5% 250V
C548 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C549 1-117-953-91 FILM 0.033uF 5% 400V
C550 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C551 1-163-251-11 CERAMIC CHIP 100pF 5% 50V
C553 1-163-017-00 CERAMIC CHIP 0.0047uF 10% 50V
C554 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C555 1-137-194-81 MYLAR 0.47uF 5% 50V
C556 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C557 1-126-935-11 ELECT 470uF 20% 16V
C558 1-163-007-11 CERAMIC CHIP 680pF 10% 50V
C559 1-163-038-91 CERAMIC CHIP 0.1uF 25V
