Sony KV-HW21N63 Group A12 (GB)_4-094-461-11 (1)
Trinitron Color TV
Operating Instructions
Before operating the unit, please read this manual thoroughly and
retain it for future reference.
KV-HW21
© 2003 Sony Corporation
4-094-461-11 (1)
N63
N60
GB
01GB01COV-PHI.p65 29/08/03, 3:00 PM1

Questions and Answers

  • B
    Brandon TuckerAug 16, 2025
    What to do if my Sony Color TV has no picture and no sound?
    • N
      Nancy BurnsAug 16, 2025
      If your Sony Color TV shows no picture and produces no sound, ensure that the power cord, antenna, and VCR are properly connected. Also, verify that the TV is turned on by pressing the POWER button. If it still doesn't work, try turning off the TV using the main power button for about five seconds, then turn it back on.
  • C
    Christina SmithAug 18, 2025
    How to fix snowy picture and noisy sound on Sony Color TV?
    • J
      Jason MillerAug 19, 2025
      If you're experiencing a snowy picture and noisy sound on your Sony Color TV, start by checking the antenna cable and its connections at the TV, VCR, and wall. Ensure your antenna setup is correct, and preset the channels again. If the signal transmission is weak, consider using a booster.
  • S
    Steven DeckerAug 21, 2025
    What to do if Sony Color TV picture is distorted with noisy sound?
    • M
      Mark CarterAug 21, 2025
      If your Sony Color TV picture is distorted and the sound is noisy, the broadcast signals might be too strong. If you are using a booster, try turning it off or disconnecting it.
  • C
    cwilliamsAug 25, 2025
    How to fix double images or “ghosts” on Sony Color TV?
    • O
      omunozAug 26, 2025
      If your Sony Color TV is showing double images or “ghosts”, try using a highly directional antenna. Also, if you are using a booster, turn it off or disconnect it.
  • K
    kelly62Aug 28, 2025
    How to restore color on my Sony Color TV?
    • M
      marymercadoAug 28, 2025
      If your Sony Color TV has no color, display the “Video” menu and select the desired picture mode, then adjust the “Color” level in “Picture Controls.”
  • S
    Susan BowmanAug 30, 2025
    Why does my Sony Color TV have good picture but no sound?
    • E
      Emily CannonAug 30, 2025
      If your Sony Color TV has a good picture but no sound, first increase the volume level by pressing the VOL + button. If that doesn't work, check if the sound is muted and, if so, press the MUTING button to cancel it.
  • K
    kathryn27Sep 2, 2025
    Why is stereo sound not working on my Sony Color TV?
    • J
      Jordan PhillipsSep 3, 2025
      If your Sony Color TV cannot receive stereo broadcast sound, or if the stereo broadcast sound switches on and off or is distorted, press MTS/SAP until “Stereo” appears on the screen. Also check the antenna cable and connection on the TV, VCR and at the wall.
  • W
    wilsondonaldSep 5, 2025
    What causes dotted lines or stripes on my Sony Color TV?
    • L
      Lisa GarciaSep 6, 2025
      If you see dotted lines or stripes on your Sony Color TV, it might be due to local interference from equipment like cars, neon signs, hair dryers, or power generators. Try not to use such equipment near the TV.
  • R
    Robert TapiaSep 8, 2025
    Why is the picture slanted on my Sony Color TV?
    • L
      Laurie WilliamsSep 8, 2025
      If the picture on your Sony Color TV is slanted, it could be due to magnetic disturbance from external speakers or other equipment, or the direction of the earth’s magnetic field. Try keeping external speakers or other electrical equipment away from the TV.
  • S
    scott48Sep 12, 2025
    What causes abnormal color patches on my Sony Color TV?
    • E
      Elizabeth PowersSep 12, 2025
      If your Sony Color TV displays abnormal color patches, it could be due to magnetic disturbance from external speakers or other equipment, or the direction of the earth’s magnetic field. Keep external speakers or other electrical equipment away from the TV. Do not move the TV while the TV is turned on. Turn off the TV for about 15 minutes, then turn it on again to demagnetize the TV.

Summary

Trinitron Color TV

Operating Instructions

Instructions for operating the Trinitron Color TV unit.

Safety Warnings

General Safety Precautions

Essential safety guidelines for operating the TV, including electrical hazards and handling.

Visual Safety Instructions

Pictorial warnings illustrating safe usage and potential hazards to avoid.

Securing the TV

Anti-Tip Installation

Instructions for securing the TV to prevent it from falling using supplied hardware.

Installation

Getting Started

Initial steps for setting up the TV, including remote and power connections.

Setting up your TV

Guide for the initial setup process, including language and channel presetting.

Overview of Controls

Menu Adjustment

Troubleshooting

Troubleshooting Guide

A guide to diagnose and solve common TV viewing problems like snowy pictures or no sound.

Sony Trinitron Specifications

Display IconDisplay
picture tube typeHi-Black Trinitron
picture tube size55 cm (21 inches)
deflection100°
Audio IconAudio
music power output5 W
RMS power output4 W
headphones jack typeminijack (mono)
Power IconPower
power consumption58 W
Weight and Dimensions IconWeight and Dimensions
weight20 kg
dimensions518x474x488 mm

Related product manuals
