Sony Trinitron CPD-E400 - Page 43

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified ¡ marked are
critical for safety.
Replace only with the part number specified.
Les composants identifiés par la marque ¡
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
CPD-E400/E400E/E400P
7-6
D
C927 1-106-351-00 MYLAR 0.0022uF 20% 200V
C929 1-126-965-11 ELECT 22uF 20% 50V
C930 1-137-370-11 MYLAR 0.01uF 5% 50V
C931 1-164-005-11 CERAMIC CHIP 0.47uF 25V
C1006 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C1013 1-126-926-11 ELECT 1000uF 20% 10V
C1024 1-163-227-11 CERAMIC CHIP 10pF 0.5pF 50V
C1025 1-163-227-11 CERAMIC CHIP 10pF 0.5pF 50V
C1026 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C1030 1-164-222-11 CERAMIC CHIP 0.22uF 25V
C1031 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C1036 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C1037 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C1038 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C1042 1-163-243-11 CERAMIC CHIP 47pF 5% 50V
C1046 1-163-243-11 CERAMIC CHIP 47pF 5% 50V
C1047 1-163-243-11 CERAMIC CHIP 47pF 5% 50V
C1050 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C1056 1-163-243-11 CERAMIC CHIP 47pF 5% 50V
C1057 1-163-243-11 CERAMIC CHIP 47pF 5% 50V
C1061 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C1062 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C1063 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C1064 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
<CONNECTOR>
CN501*1-580-798-11 CONNECTOR PIN (DY) 6P
CN600*1-691-960-11 PIN, CONNECTOR (PC BOARD) 3P
CN601*1-580-689-11 PIN, CONNECTOR (PC BOARD) 4P
CN603*1-564-510-11 PLUG, CONNECTOR 7P
CN701*1-564-511-11 PLUG, CONNECTOR 8P
CN702*1-564-506-11 PLUG, CONNECTOR 3P
CN901 1-695-915-11 TAB (CONTACT)
CN1001* 1-508-879-11 BASE POST
CN1002* 1-564-511-11 PLUG, CONNECTOR 8P
CN1003* 1-564-515-11 PLUG, CONNECTOR 12P
CN1004* 1-564-509-11 PLUG, CONNECTOR 6P
<DIODE>
D401 8-719-979-58 DIODE EGP10D
D402 8-719-158-15 ZENER DIODE RD5.6SB
D405 8-719-061-42 DIODE 1N4148S-26TP
D501 8-719-110-47 ZENER DIODE RD18ESB
D502 8-719-981-00 DIODE ERC81-004
D503 8-719-110-47 ZENER DIODE RD18ESB
D504 8-719-061-21 DIODE FMQ-G5FMS
D505 8-719-052-86 DIODE D2L40-TA
D506 8-719-976-96 ZENER DIODE DTZ4.7C
D507 8-719-073-01 DIODE MA111-(K8).S0
D508 8-719-073-01 DIODE MA111-(K8).S0
D509 8-719-073-01 DIODE MA111-(K8).S0
D510 8-719-073-01 DIODE MA111-(K8).S0
D511 8-719-073-01 DIODE MA111-(K8).S0
D512 8-719-073-01 DIODE MA111-(K8).S0
D514 8-719-109-81 ZENER DIODE RD4.7ESB2
D515 8-719-073-01 DIODE MA111-(K8).S0
D516 8-719-951-30 DIODE ERA91-02
D517 8-719-978-65 ZENER DIODE DTZ-TT11-15B
D518 8-719-110-17 ZENER DIODE RD10ESB2
D519 8-719-109-81 ZENER DIODE DTZ4.7C
D607 8-719-073-01 DIODE MA111-(K8).S0 [E400P]
D608 8-719-061-42 DIODE 1N4148S-26TP
D609 8-719-053-19 DIODE UF4007G23
D610 8-719-921-40 DIODE MTZJ-4.7C
D611 8-719-053-19 DIODE UF4007G23
D612 8-719-110-49 ZENER DIODE RD18ESB2
D613 8-719-300-76 DIODE RH-1A
D614 8-719-067-68 DIODE FMC-26UA
D615 8-719-053-19 DIODE UF4007G23
D616 8-719-076-20 DIODE BT149G-412-OT359
D617 8-719-061-42 DIODE 1N4148S-26TP
D618 8-719-069-63 DIODE ERB38-06V1
D619 8-719-058-38 DIODE FMN-G12S
D620 8-719-510-41 DIODE D10SC9M
D621 8-719-979-58 DIODE EGP10D
D622 8-719-074-79 DIODE YG911S2R
D623 8-719-979-58 DIODE EGP10D
D624 8-719-979-58 DIODE EGP10D
D6250 8-719-510-63 DIODE D4SB60L-F
D626 8-719-061-42 DIODE 1N4148S-26TP
D627 8-719-110-08 ZENER DIODE RD8.2ESB2
D628 8-719-061-42 DIODE 1N4148S-26TP
D629 8-719-073-01 DIODE MA111-(K8).S0
D630 8-719-110-41 ZENER DIODE RD15ESB2
D634 8-719-061-42 DIODE 1SS119
D635 8-719-061-42 DIODE 1SS119
D701 8-719-061-42 DIODE 1N4148S-26TP
D702 8-719-061-42 DIODE 1N4148S-26TP
D703 8-719-061-42 DIODE 1N4148S-26TP
D705 8-719-158-49 ZENER DIODE RD12SB2
D901 8-719-073-01 DIODE MA111-(K8).S0
D903 8-719-073-01 DIODE MA111-(K8).S0
D904 8-719-073-01 DIODE MA111-(K8).S0
D906 8-719-978-65 ZENER DIODE DTZ-TT11-15B
D907 8-719-052-86 DIODE D2L40-TA
D908 8-719-073-01 DIODE MA111-(K8).S0
D909 8-719-978-65 ZENER DIODE DTZ-TT11-15B
D910 8-719-028-72 DIODE RGP02-17EL-6433
D911 8-719-028-72 DIODE RGP02-17EL-6433
D912 8-719-110-46 ZENER DIODE RD16ESB3
D913 8-719-110-46 ZENER DIODE RD16ESB3
D914 8-719-970-83 DIODE HSS82
D915 8-719-109-85 ZENER DIODE RD5.1ESB2
D916 8-719-158-49 ZENER DIODE RD12SB2
D917 8-719-929-15 ZENER DIODE HZS9.1NB2
D920 8-719-158-15 ZENER DIODE RD5.6SB
D921 8-719-158-15 ZENER DIODE RD5.6SB
D1001 8-719-158-15 ZENER DIODE RD5.6SB
D1003 1-218-772-11 METAL CHIP 680K 0.5% 1/10W
D1007 8-719-158-15 ZENER DIODE RD5.6SB
