Sony Trinitron CPD-E400 - Page 45

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified ¡ marked are
critical for safety.
Replace only with the part number specified.
Les composants identifiés par la marque ¡
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
CPD-E400/E400E/E400P
7-8
D
L607 1-414-158-11 INDUCTOR 2.2uH
L608 1-414-488-21 INDUCTOR 1.5uH
L901 1-412-537-31 INDUCTOR 100uH
L902 1-406-659-11 INDUCTOR 10uH
<FILTER>
LF6020 1-429-180-11 TRANSFORMER, LINE FILTER
<TRANSISTOR>
Q501 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q502 8-729-901-87 TRANSISTOR 2SC2411K-CQ
Q503 8-729-026-50 TRANSISTOR 2SA1037AK-T146-QR
Q504 8-729-042-34 TRANSISTOR IRFU110A
Q505 8-729-050-12 TRANSISTOR 2SC5445(LBSONY1)
Q506 8-729-043-63 TRANSISTOR IRFI9634G-LF35
Q507 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q508 8-729-901-87 TRANSISTOR 2SC2411K-CQ
Q509 8-729-901-97 TRANSISTOR 2SA1036K-Q
Q510 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q511 8-729-043-41 TRANSISTOR 2SK2098-01MR-F119
Q512 8-729-043-41 TRANSISTOR 2SK2098-01MR-F119
Q513 8-729-043-41 TRANSISTOR 2SK2098-01MR-F119
Q514 8-729-043-41 TRANSISTOR 2SK2098-01MR-F119
Q515 8-729-043-41 TRANSISTOR 2SK2098-01MR-F119
Q516 8-729-043-41 TRANSISTOR 2SK2098-01MR-F119
Q517 8-729-140-50 TRANSISTOR 2SC3209LK
Q519 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q605 8-729-050-14 TRANSISTOR 2SK3265 (LB2SONY)
Q606 8-729-043-27 TRANSISTOR PDTC114EK-115
Q607 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q608 8-729-029-92 TRANSISTOR DTC143ESA
Q609 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q701 8-729-800-32 TRANSISTOR 2SC2362K-G
Q702 8-729-178-43 TRANSISTOR 2SC2784-E
Q703 8-729-204-91 TRANSISTOR 2SA1049-GR
Q704 8-729-207-82 TRANSISTOR 2SC3421-Y
Q705 8-729-207-89 TRANSISTOR 2SA1358-Y
Q706 8-729-031-89 TRANSISTOR 2SC3941A-Q (TA)
Q901 8-729-043-63 TRANSISTOR IRFI9634G-LF35
Q902 8-729-041-45 TRANSISTOR FS5KM-16A
Q903 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q904 8-729-901-97 TRANSISTOR 2SA1036K-Q
<RESISTOR>
R401 1-249-383-11 CARBON 1.5 5% 1/4W F
R402 1-215-866-11 METAL OXIDE 330 5% 1W F
R403 1-214-796-00 METAL 1.5 1% 1/2W
R404 1-215-449-00 METAL 15K 1% 1/4W
R405 1-214-796-00 METAL 1.5 1% 1/2W
R406 1-216-663-11 METAL CHIP 3.3K 0.5% 1/10W
R407 1-249-397-11 CARBON 22 5% 1/4W F
R409 1-216-679-11 METAL CHIP 15K 0.5% 1/10W
R410 1-216-663-11 METAL CHIP 3.3K 0.5% 1/10W
R416 1-216-073-00 RES,CHIP 10K 5% 1/10W
R417 1-216-113-00 RES,CHIP 470K 5% 1/10W
R418 1-216-105-91 RES,CHIP 220K 5% 1/10W
R501 1-216-049-91 RES,CHIP 1K 5% 1/10W
R502 1-216-025-91 RES,CHIP 100 5% 1/10W
R503 1-216-033-00 RES,CHIP 220 5% 1/10W
R504 1-216-073-00 RES,CHIP 10K 5% 1/10W
R505 1-216-081-00 RES,CHIP 22K 5% 1/10W
R506 1-247-807-31 CARBON 100 5% 1/4W
R507 1-247-863-91 CARBON 22K 5% 1/4W
R508 1-215-861-00 METAL OXIDE 47 5% 1W F
R509 1-249-381-11 CARBON 1 5% 1/4W F
R510 1-219-677-11 METAL 1.8 5% 10W
R511 1-249-377-11 CARBON 0.47 5% 1/4W F
R512 1-214-842-11 METAL 120 1% 1/2W
R513 1-216-423-11 METAL OXIDE 27 5% 1W F
R514 1-249-397-11 CARBON 22 5% 1/4W F
R515 1-249-425-11 CARBON 4.7K 5% 1/4W
R516 1-249-425-11 CARBON 4.7K 5% 1/4W
R517 1-216-089-91 RES,CHIP 47K 5% 1/10W
R518 1-216-033-00 RES,CHIP 220 5% 1/10W
R519 1-216-025-91 RES,CHIP 100 5% 1/10W
R520 1-216-033-00 RES,CHIP 220 5% 1/10W
R521 1-247-807-31 CARBON 100 5% 1/4W
R522 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R523 1-216-683-11 METAL CHIP 22K 0.5% 1/10W
R524 1-216-663-11 METAL CHIP 3.3K 0.5% 1/10W
R525 1-216-657-11 METAL CHIP 1.8K 0.5% 1/10W
R526 1-216-691-11 METAL CHIP 47K 0.5% 1/10W
R527 1-216-683-11 METAL CHIP 22K 0.5% 1/10W
R528 1-216-683-11 METAL CHIP 22K 0.5% 1/10W
R529 1-216-099-00 RES,CHIP 120K 5% 1/10W
R530 1-216-663-11 METAL CHIP 3.3K 0.5% 1/10W
R531 1-216-661-11 METAL CHIP 2.7K 0.5% 1/10W
R532 1-216-073-00 RES,CHIP 10K 5% 1/10W
R533 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R535 1-216-683-11 METAL CHIP 22K 0.5% 1/10W
R536 1-216-683-11 METAL CHIP 22K 0.5% 1/10W
R537 1-216-683-11 METAL CHIP 22K 0.5% 1/10W
R538 1-216-691-11 METAL CHIP 47K 0.5% 1/10W
R539 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R540 1-216-691-11 METAL CHIP 47K 0.5% 1/10W
R541 1-216-687-11 METAL CHIP 33K 0.5% 1/10W
R542 1-214-842-11 METAL 120 1% 1/2W
R543 1-214-842-11 METAL 120 1% 1/2W
R544 1-249-393-11 CARBON 10 5% 1/4W F
R545 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R546 1-215-909-11 METAL OXIDE 47 5% 3W F
R547 1-215-387-00 METAL 39 1% 1/4W
R548 1-260-318-71 CARBON 150 5% 1/2W
R549 1-260-314-11 CARBON 68 5% 1/2W
R550 1-247-903-00 CARBON 1M 5% 1/4W
R552 1-249-437-11 CARBON 47K 5% 1/4W
R553 1-249-437-11 CARBON 47K 5% 1/4W
R555 1-249-437-11 CARBON 47K 5% 1/4W
R557 1-249-437-11 CARBON 47K 5% 1/4W
